Summary of Contents for WORKMASTER BATMAN BM-1700
- Page 1 BM-1700 BEACH CLEANING MACHINE Operation and Maintenance Manual PLEASE KEEP THIS MANUAL AND READ CAREFULLY...
- Page 2 Contents Preface ..............1-3 Warning Signs and Labels........4-5 Safety and Requirements Information.....6-7 Operating and Using Instructions......8 Explanation of Dashboard Icons.......9-10 Levers and Control Panel Descriptions.....11-12 Machine and Engine Maintenance Schedule....13-14 Lubrication Scheme.…………….………....15 Technical Data .………………….………....16...
-
Page 3: Operation
Preface Information About this Booklet This booklet should be placed in a folder where brochures are kept. This book contains safety information, operating instructions and maintenance recommendations. Some photos and illustrations in this book may differ from your vehicle's details or attachments. With the development and advancement of the product design, it may have undergone some changes that are not covered in this book. -
Page 4: Maintenance
Maintenance The Maintenance section is a guide to vehicle maintenance. An electrical panel warning. Low voltage in the panel. Keep clear the running machine and keep others away. Keep clear the running machine and keep others away. Maintenance-repair, cleaning, lubrication, etc. works should not beperformed while the machine is running where this warning is put. - Page 5 WARNING ! WARNING ! Do not operate or work on this machine Replace any missing or damaged safety until you have read and understood the signs with new ones. instructions and warnings in the Operation Always consider the safety of the and Maintenance Manuals.
- Page 6 Requirements of the Worksite Safety construction machine operator Only personnel holding G class driving license and having certified training from the Manufacturer can operate the machine. The operator who runs the machine Personel must maintain and operate occasionally or regularly should have the the vehicle in accordance with the instruction following qualifications.
-
Page 7: Training Requirements
Training Requirements He/she should carefully read and study this manual, attached graphics and diagrams,remarks and warning labels and signs. He/she must have sufficient skills and training in operation of the machine. The operator must have a driver's license (license) to drive the vehicle within the limits stipulated by the laws applicable in the country where this type of machine is operated, and must have been trained to... - Page 8 Operation and Usage İnstruction 18-While the vehicle is running, no maintenance, cleaning, adjustment should be 1- Only personnel who have a G class made and the vehicle should not be climbed license, trained and certified to operate the on. All of these operations should be done machine can use the machine.
- Page 9 1. It is the fuel indicator on the construction machine. 2. Trailer directional signal, it is an unused icon. 3. 4 WD, It is an unused icon. 4. Automatic lifting system. 5. Hydraulic filter. 6. Preheating. 7. Air filter. 8. Indicates the amount of vehicle in the construction machine. 9.
- Page 10 19. Brake system malfunction. 20. It is an unused icon. 21. It is an unused icon. 22. Hydraulic temperature. 23. Indicates that the parking brake is engaged. 24. Indicates that the vehicle's main beam is on. 25. Indicates that parking brakes are on. 26.
-
Page 11: Control Panel
VEHICLE DIRECTION AND SPEED LEVERS Gas: Manual It accelerates the vehicle and increases the engine speed. and Direction Control: Speed Allows the vehicle to go forward and backward. The middle position of the lever provides braking. In order to change the direction of movement of the vehicle, the lever is first taken in the middle position. - Page 12 Garbage Storage Emptying: Opens and closes the emptying cover of the filled garbage storage. Depth Control System: Laser sensing cleaning depth control system adjusts the beach cleaning depth. Depth adjustment is made by loosening the wing nut and tightened after adjustment.
- Page 13 ENGINE SERVICE FREQUENCIES Every 50 hours Checking fuel pipes and clamp bands Emptying the water separator Engine oil change 1” 250 hours or 1 year, whichever comes first Cleaning the air filter element Fuel filter change Battery electrolyte level check Every 250 hours Checking the fan belt tension Checking radiator hoses and clamp bands...
- Page 15 Lubrication Scheme...
-
Page 16: Technical Data
TECHNICAL DATA: Machine Description: Beach Cleaning Machine Machine Model: BM-1700 Engine Type : Kubota V-3600 Stage 3A Tiar 4 Fuel Type: EURODiesel Fuel Tank Capacity: 55 liter Total Weight: 2780 kg Hydraulic Tank Capacity: 95 liter Hydraulic To Use: SAE 46 Vehicle Dimensions: L=4200 mm W=2530 mm H=2500 Tire Pressures: 18 psi Tire Sizes: 400 / 60-15,5...
