Summary of Contents for Westport STAIRWAY 700
- Page 1 Technical User Guide STAIRWAY 700 USER GUIDE & SAFETY INFORMATION Scaffolding | Shoring | Safety...
-
Page 2: General Information
Co. Meath, A86 N882 Ireland. +353 1 223500 THE INFORMATION CONTAINED WITHIN THIS GUIDE REMAINS THE PROPERTY OF WESTPORT EQUIPMENT LTD AND IS NOT TO BE ALTERED OR REPRODUCED WITHOUT WRITTEN PERMISSION. WESTPORT EQUIPMENT LTD RESERVES THE RIGHT TO CHANGE ANY DATA WITHOUT GIVING PRIOR NOTICE. - Page 3 CHECK MATERIAL CHECK MATERIAL CHECK MATERIAL Check all parts for mounting. If in doubt, contact Westport Equipment and replace or discard damaged Check all parts for mounting. If in doubt, contact SafetyRespect and replace or discard damaged material. material. Check all parts for mounting. If in doubt, contact SafetyRespect and replace or discard damaged material.
- Page 4 Stairway, width 70 cm, 18 steps 174 kg 5061018 Stairway, widht 100 cm, 18 steps 200 kg 5061018 Stairway, width 100 cm, 18 steps 200 kg 4 | SAFETYRESPECT.COM Westport Equipment Ltd Tel: +353 1 2233500 LinkedIn: /westport-equipment Barstown Commercial Park Email: sales@westportequipment.com Twitter: /westportequip 4 | SAFETYRESPECT.COM...
- Page 5 Extension profile lower right 1 psc 1 pcs X18000636 Extension proofile lower left X18000637 Extension profile lower right 1 pcs SAFETYRESPECT.COM | 5 Westport Equipment Ltd Tel: +353 1 2233500 LinkedIn: /westport-equipment Barstown Commercial Park Email: sales@westportequipment.com Twitter: /westportequip Dunboyne, Co. Meath, Web: www.westportequipment.com...
-
Page 6: Additional Components
(for configuration 21–36 steps) 6,3 kg 0,2 kg 5061103 Scaffold Fix BT nector (for configuration 21–36 steps) 1,1 kg 0,2 kg 6 | SAFETYRESPECT.COM Westport Equipment Ltd Tel: +353 1 2233500 LinkedIn: /westport-equipment Barstown Commercial Park Email: sales@westportequipment.com Twitter: /westportequip Dunboyne, Co. - Page 7 NO. OF STEPS Stairway support middle piece 24 STEPS 27 STEPS Stairway support 30 STEPS connector 33 STEPS 36 STEPS Westport Equipment Ltd Tel: +353 1 2233500 LinkedIn: /westport-equipment Barstown Commercial Park Email: sales@westportequipment.com Twitter: /westportequip Dunboyne, Co. Meath, Web: www.westportequipment.com...
- Page 8 Stairway 15-steps Stairway 18-steps [mm] [mm] [mm] [mm] [mm] [mm] 8 | SAFETYRESPECT.COM 8 | SAFETYRESPECT.COM 8 | SAFETYRESPECT.COM Westport Equipment Ltd Tel: +353 1 2233500 LinkedIn: /westport-equipment Barstown Commercial Park Email: sales@westportequipment.com Twitter: /westportequip Dunboyne, Co. Meath, Web: www.westportequipment.com...
- Page 9 12-steps Stairway Distance: 2,55 m Height: 2,35 m Degree: 42,5° Distance: 2,55 m Height: 2,35 m Distance: 2,55 m Distance Distance Westport Equipment Ltd Tel: +353 1 2233500 LinkedIn: /westport-equipment SAFETYRESPECT.COM | 9 Barstown Commercial Park Email: sales@westportequipment.com Twitter: /westportequip SAFETYRESPECT.COM | 9...
- Page 10 Use the crane hooks to Use the crane hooks lift the stair at place. to lift the stair at place. SAFETYRESPECT.COM | 3 10 | SAFETYRESPECT.COM 10 | SAFETYRESPECT.COM Westport Equipment Ltd Tel: +353 1 2233500 LinkedIn: /westport-equipment Barstown Commercial Park Email: sales@westportequipment.com Twitter: /westportequip Dunboyne, Co.
- Page 11 Secure the locks SAFETYRESPECT.COM | 11 CHECK MATERIAL at both sides. Check all parts for mounting. If in doubt, contact SafetyRespect and replace or discard damaged mate Westport Equipment Ltd Tel: +353 1 2233500 LinkedIn: /westport-equipment SAFETYRESPECT.COM | 11 Barstown Commercial Park Email: sales@westportequipment.com...
- Page 12 ISO 10511 M10x60 8. (counting step from the bottom) Adjust the height. Adjust the height. 12 | SAFETYRESPECT.COM Adjust the height. 12 | SAFETYRESPECT.COM Westport Equipment Ltd Tel: +353 1 2233500 LinkedIn: /westport-equipment Barstown Commercial Park Email: sales@westportequipment.com Twitter: /westportequip Dunboyne, Co.
- Page 13 See table 2 (page 7) for total amount of middle pieces. for total amount of middle pieces. SAFETYRESPECT.COM | 13 Westport Equipment Ltd Tel: +353 1 2233500 LinkedIn: SAFETYRESPECT.COM | 13 /westport-equipment SAFETYRESPECT.COM | 13...
-
Page 14: Packing And Storage
Stairways 3-9 steps with maximum 10 pcs/pallet. 12-18 steps maxi- mum 5 pcs/2 pallets. 12-18 steps maxi- mum 5 pcs/2 pallets. 14 | SAFETYRESPECT.COM Westport Equipment Ltd Tel: +353 1 2233500 LinkedIn: /westport-equipment 14 | SAFETYRESPECT.COM Barstown Commercial Park Email: sales@westportequipment.com... -
Page 15: Maintenance
COMPETENT PERSON A competent person is someone who has been given the appropriate training and been authorized by Westport Equipment to perform inspections and repairs. Westport Equipment Ltd Tel: +353 1 2233500... - Page 16 Page 13 accordance with these instructions? Is the inclination of the Stairway within its Page 9 limitations? CHECKING THE ABOVE LIST CONDUCTED BY Date Signature Westport Equipment Ltd Tel: +353 1 2233500 LinkedIn: /westport-equipment Barstown Commercial Park Email: sales@westportequipment.com Twitter: /westportequip Dunboyne, Co.
