- Page 1 Operating and Installation Manual Battery pack for EASYLAB expansion modules EM-TRF and EM-TRF-USV The art of handling air Battery Pack Operating and Installation Manual / Leaflet no. M375EV6 (3/2013)
-
Page 2: Table Of Contents
Contents General information __________________ 3 Installation __________________________ 7 Other applicable documentation ________ 3 Installing the EM-TRF and EM-TRF-USV __ 7 Symbols used in this manual ____________ 3 Installing the EM-TRF-USV - contd. ______ 8 Attaching the warning stickers __________ 8... -
Page 3: General Information
1 General information This operating and installation manual describes Symbols used in this manual the EM-TRF and EM-TRF-USV expansion modules that are used to connect TCU3 EASYLAB Danger! controllers and TAM adapter modules to a 230 V AC Designates danger to life and limb due to supply voltage. -
Page 4: Safety And Correct Use
Condensation can damage the electronics Uninterruptible power supply is provided only beyond repair. If the expansion module has been with the EM-TRF-USV being connected to a fully kept in an unheated area, wait at least two hours charged battery pack. For maximum operating... -
Page 5: Product Description
5 Socket for battery pack 6 Battery pack L N PE Functional description Additional function of the EM-TRF-USV The expansion module is connected to the If the supply voltage (mains voltage) fails, the 230 V AC supply voltage (mains voltage). The... -
Page 6: Technical Data
Protection level IP 20 Dimensions B × H × T 78 × 65 × 100 mm Additional data for the EM-TRF-USV USP operation Approx. 4.5 h for maintaining normal operation One controller (TCU3 or TAM) with a Approx. 6 h for defined blade position and indication of mains voltage... -
Page 7: Transport, Storage And Packaging
• Operating and installation manual • Temperature: –10°C to +70°C Maximum humidity: 90% (non-condensing) • Battery pack (only for EM-TRF-USV) Packaging Transport on site Properly dispose of packaging material. • If possible, take the expansion module in the transport packaging up to the installation location. -
Page 8: Installing The Em-Trf-Usv - Contd
PCB and the main PCB are aligned. 3.Fix the expansion module using the four fixing screws. Tighten the screws only hand-tight. The EM-TRF expansion module is now ready for wiring, and the warning sticker can be attached. Installing the EM-TRF-USV - contd. Step 3 Mounting the battery pack. -
Page 9: Wiring
• Switch off the power supply before working on any electrical equipment. Wiring the EM-TRF and EM-TRF-USV • Never connect two voltages! When the expansion module for 230 V AC is used, do not connect a 24 V AC/DC voltage to the main PCB. -
Page 10: Commissioning
• Hold the last damper blade position Mains operation; the battery pack is Green, blinking being charged Maintenance The EM-TRF and EM-TRF-USV expansion modules do not require any maintenance. Green-red, blin- USP operation; the battery pack is king being used (discharged) - Page 11 Battery Pack Operating and Installation Manual / Leaflet no. M375EV6 (3/2013)
- Page 12 Battery Pack Operating and Installation Manual / Leaflet no. M375EV6 (3/2013)
