Summary of Contents for MASTERTHERM pGDx
- Page 1 Catalog: Manual Documentation: 4768_pGDx_Graphical_user_interface Revision: pGDx SW version: 1107 pGDx Graphical user interface (GUI) MANUAL MASTERTHERM tepelná čerpadla s.r.o. Václavské Náměstí 819/43, 110 00 Praha 1 Czech Republic e-mail: info@mastertherm.cz www.mastertherm.cz...
-
Page 2: Table Of Contents
Advanced access ........................ 19 Advanced settings ..........................19 pGD emulator ........................20 Located on the heat pump ....................20 HW Settings ........................20 pGDx: Heating circuit selection ..................21 Network ..............................22 10.1 Wi-Fi connection ....................... 23 10.2 Ethernet connection ......................24 10.3... - Page 3 Figure 43 - Located on the heat pump ......................20 Figure 44 - pGDx: Heating circuit selection, main ..................21 Figure 45 - pGDx: Heating circuit selection, HP located ................21 Figure 46 - Network, icons on main screen to enter this page ..............22...
- Page 4 4768_pGDx – Graphical user interface manual Figure 47 - Network menu ..........................22 Figure 48 - WiFi connection........................... 23 Figure 49 - WiFi connection, advanced settings .................... 23 Figure 50 - Ethernet connection ........................24 Figure 51 – API settings ..........................24 Figure 52 - API, Octopus Agile 01 ........................
-
Page 5: Home Screen
Figure 1 - Home screen, Light mode pGDx also has built-in eye-saving function for darker display at night (or according to the user's choice). Figure 2 - Home screen, Dark mode Checked by: Ing. J. Jiránek, Created by: J. Jahoda... -
Page 6: Description Of Home Screen Icons
Heating water temperature (main heating circuit) Sanitary hot water temperature Outdoor air temperature Indoor relative humidity (from pGDx) Indoor air temperature (from pGDx) Figure 3 - Home screen, description of icons 01 Indicates (if available) activity of Ethernet connection and/or activity + signal strength of WiFi connection (after pressing this icon, user is redirected to connection settings page). -
Page 7: Description Of Home Screen Buttons
4768_pGDx – Graphical user interface manual Below you can find status icons well known from pGD. Please see OEM manual on page 8, chapter 3.1. for detailed description. Figure 5 - Main screen, HP status icons Current heat pump mode is also displayed on the home screen. Figure 6 - Current heat pump mode 1.2 Description of home screen buttons There are two groups of buttons on the left and right of the home screen. -
Page 8: Hot Water
Press INFO button from home screen. This screen contains information about the heat pump (entered on our website) located in the scroll menu. You can find information such as name, surname, pGDx ID, heating circuits labels etc. Figure 9 – Info Checked by: Ing. -
Page 9: Counters
4768_pGDx – Graphical user interface manual 3 Counters Press COUNTERS button from home screen. This page shows status of the basic counters and if the unit is equipped with an electric meter then button for entering its menu is displayed here. Figure 10 - Counters 3.1 Counters –... -
Page 10: Help
4768_pGDx – Graphical user interface manual 4 Help Press HELP button from home screen. Description of basic icons for end-users. In the first version of SW, there will be approximately 20 icons with descriptions. Help section will gradually expand in future releases. Figure 12 - Help 01 Figure 13 - Help 02 Checked by: Ing. -
Page 11: Settings
4768_pGDx – Graphical user interface manual 5 Settings SHORT Press HEAT PUMP button from home screen. Here it is possible to turn ON / OFF the heat pump and enter other submenus such as: Mode, Function, Heating + Cooling curve Figure 14 - Settings 5.1 Mode (enter from settings) -
Page 12: Function
4768_pGDx – Graphical user interface manual 5.2 Function (enter from settings) On this page, you can change function of the heat pump (only if unit is equipped with a cooling function). To confirm changes, it is necessary to press "Save" button at the top right. Figure 16 –... -
Page 13: Heating Curve
4768_pGDx – Graphical user interface manual 5.3 Heating curve (enter from settings) On this page, you can change values of equithermal curve for heating function. Values also change for text fields in image on the right. To confirm changes, it is necessary to press the "Save" button at the top right. The upper part also shows the current outdoor temperature and required water temperature according to curve settings. -
Page 14: Temperature
4768_pGDx – Graphical user interface manual 6 Temperature Press TEMPERATURE button from home screen. This page allows normal settings of the heating circuits (including circuits equipped with pAD) and the corresponding equithermal curves, main heating circuit (if no other is active), pool and solar. The button for selecting required circuit is only displayed if this function is enabled (for example HC 1 = enabled) in primary setting of heat pump. -
Page 15: Figure 23 - Temperature, Description Of The Top Icon Bar
4768_pGDx – Graphical user interface manual Description of the top icon bar ON / OFF ON / OFF Circulation Current heating Current pAD mode pump of circuit mode icon (heating / cooling) Button of Notification heating button with the selected (heating / cooling) icon circuit... -
Page 16: Pool
4768_pGDx – Graphical user interface manual Equitherm curve setting for heating circuits After pressing this button, menu with option to select heating curve or cooling curve (only if cooling function is available) will be expanded Heating Cooling curve curve Figure 25 - Temperature, HC eq. curve setting Description of icons in the middle of screen Real heating / cooling water temperature Requested heating / cooling water temperature... -
Page 17: Figure 28 - Temperatures, Description Of Pool Button
4768_pGDx – Graphical user interface manual Icon for Pool Real Pool water temperature Figure 28 - Temperatures, description of POOL button Figure 29 - Temperature, pool selected Description of icons in the middle of screen Real pool water temperature Pool water temperature setpoint Here it is possible to adjust pool water temperature setpoint using the + / - buttons and also to switch the pool heating function on / off Checked by: Ing. -
Page 18: Solar
4768_pGDx – Graphical user interface manual 6.3 Solar If "Solar" function is enabled, button with this icon will be displayed. Figure 30 - Temperature, solar icon Icon for Solar Real Solar water temperature Figure 31 - Temperature, description of SOLAR button Figure 32 - Temperature, solar selected Description of icons in the middle of screen Real Solar Panel temperature... -
Page 19: Sanitary Hot Water
8 pGDx settings Long press HEAT PUMP from main screen On this page, it is possible to change basic settings of pGDx device, restart pGDx runtime and enter "Advanced access" section (if you enter password for secure access). The current SW of the pGDx device (for example SW 1107) is displayed at the top right. -
Page 20: Languages
SW versions. In this case, we will probably need to help with translation from you. After selecting language as required, user is redirected to main screen. This completes language change. Figure 35 - pGDx settings, languages Checked by: Ing. J. Jiránek, Created by: J. Jahoda Page 16 of 31... -
Page 21: Date & Time
8.2 Date & Time Here you can change current time zone. Time zone is used for accurate online time synchronization. This is necessary when transferring data between server and pGDx to verify validity of communication and data. Currently set time zone (Prague) Figure 36 - Date &... -
Page 22: Restart
8.4 Restart pGDx It allows restart pGDx runtime. After pressing "Restart pGDx" button, a dialog will be displayed to confirm whether you really want to restart pGDx runtime. If you confirm pGDx will be restarted. Figure 39 - Restart pGDx Checked by: Ing. -
Page 23: Advanced Access
4768_pGDx – Graphical user interface manual 8.5 Advanced access For advanced access password is required. (password is identical to password for advanced access in the past – it was entered from pGD). After entering correct password, user is redirected to the advanced settings. -
Page 24: Pgd Emulator
Figure 42 - pGD emulator 9.2 Located on the heat pump If pGDx is not used as a reference device (for example for placement on a heat pump), it is possible to hide temperature and humidity values measured by device displayed on home screen. -
Page 25: Pgdx: Heating Circuit Selection
9.4 pGDx: Heating circuit selection Here it is possible to assign values from the humidity and temperature sensors of pGDx to selected (required) heating circuit. At this time, it is only possible to assign to the MAIN circuit and only with the pCO5 / pCO5+ controller with SW60 or higher. -
Page 26: Network
4768_pGDx – Graphical user interface manual 10 Network On this page, it is possible to set up an Internet connection and manage APIs (applications for communication with remote servers). There are two ways to enter this setting: 1) From Advanced Settings -> Network 2) From Main screen by pressing one of the network icons: Figure 46 - Network, icons on main screen to enter this page... -
Page 27: Wi-Fi Connection
4768_pGDx – Graphical user interface manual 10.1 Wi-Fi connection On this page, it is possible to connect to a WiFi network. Advanced WiFi settings Refresh list WiFi settings Reverse list Figure 48 - WiFi connection Follow these instructions to connect: 1) Select (press) required WiFi network to connection from list on right (If WiFi network is not displayed, you can use refresh button to refresh WiFi list) 2) Enter password (press password text field to display graphic keyboard) -
Page 28: Ethernet Connection
4768_pGDx – Graphical user interface manual 10.2 Ethernet connection If you are using Internet connection via Ethernet cable and DHCP, just connect eth. cable and everything should work. On main screen ethernet icon will be displayed: If you want to configure ethernet connection manually press Ethernet button in Network menu. (after disabling DHCP, it will be possible to enter the parameters manually) Following screen will be displayed: Figure 50 - Ethernet connection... -
Page 29: Octopus Agile Api (Uk)
4768_pGDx – Graphical user interface manual 10.3.1 Octopus Agile API (UK) Application is in development phase for testing stability of communication with a remote server. Every day, query is made to remote server and then data (electricity tariff price list) is processed for 30 hours. Data can then be displayed from GUI (price list browsing), current tariff price is displayed on main screen according to time, etc. -
Page 30: Figure 54 - Api, Octopus Agile - Settings 1/3
4768_pGDx – Graphical user interface manual This page is used to identify what price of tariff is expensive, average or cheap according to user's choice. Price ranges can be changed when pressed. Figure 54 - API, Octopus Agile - settings 1/3 This page is used to determine air temperature offset... -
Page 31: Openweather Api
GPS coordinates and user key obtained from the server during registration. A default key from MasterTherm should be entered in each device (it can be changed if necessary). After enabling this function, outdoor air temperature value will be retrieved periodically (every hour) from server and transmitted to HP controller. -
Page 32: Sw Updater
SW Update is performed automatically after pressing button and after upgrade system will return to main screen. In case of problems during this process (eg: power failure of pGDx) system will start with the last known functional SW version before this upgrade. -
Page 33: Service Info
4768_pGDx – Graphical user interface manual 11 Service info LONG press from MAIN SCREEN and then LONG press Scroll table (horizontal) for displaying service values This screen is similar to the page available in classical pGD - "SERVICE INFO" Figure 61 - Service info 1/2 Figure 62 - Service info 2/2 Checked by: Ing. -
Page 34: Revision History Of This Document
4768_pGDx – Graphical user interface manual 12 Revision history of this document GUI changes according to the SW version of pGDx will be documented here. Rev000, pGDx SW1107, 13/05/2021 First official release. In case of questions, you can write directly to me: j.jahoda@mastertherm.cz or to my colleagues. - Page 35 4765_ pGDx – Installation manual NOTES: MASTERTHERM tepelná čerpadla s.r.o. Registered trade marks and logos used in the text are Václavské Náměstí 819/43, 110 00 Praha 1 owned by the appropriate companies. All rights are Czech Republic reserved. e-mail: info@mastertherm.cz Unauthorized modifications are not permitted.
