LIGHT OIL RUBBED BRONZE COMMERCIAL DECK MOUNT
HANDSFREE AUTOMATIC SENSOR FAUCET INSTALLATION
PRIOR TO INSTALLATION
Please read installation instructions below. All plumbing should be
installed in accordance with applicable building codes and regulations.
Unpack and inspect the items for any shipping damages. If you find
damages, do not install.
All products must be installed by a professional and certified plumber
otherwise warranty may be voided.
POSSIBLE TOOLS REQUIRED*
Plumbers Tape
Thread Sealant
Fontana Sensor Faucet
Fontana Sensor Faucets
INSTRUCTIONS
Tape Measure
Drill
Level
Adjustable Wrench
Pencil or Marker
1
©
Product code: FS1097B
Hex Wrench
Screwdriver
fontanasensorfaucets.com
Customer Service: 800-684-4489
*not included
