Summary of Contents for Centro G21201
- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. Centro 85-1117-6 (2008) Owner's Manual Shop genuine replacement parts for Centro 85-1117-6 (2008) Find Your Centro Grill Parts - Select From 150 Models -------- Manual continues below --------...
- Page 2 Assembly Manual 85-1117-6 (G21201) Propane Limited 3-Year Warranty Read and save manual for future reference. Assemble your grill immediately. Missing or damaged parts should be claimed within 15 days of purchase. Call the Centro Hotline at 1-877-707-5463. Manual Revision #: 112907...
- Page 3 H E A V Y A R T I C L E N E E D S 2 T O L I F T THIS MANUAL MUST REMAIN WITH THE PRODUCT AT ALL TIMES To ORDER non-warranty replacement parts or accessories, or to register your warranty, please visit us on the web at www.centrobbqs.com.
-
Page 4: Hardware Pack
HARDWARE PACK TOOLS NEEDED FOR ASSEMBLY No. Description Part Number Quantity 1/4"×38mm Screw 20120-13038-250 • #2 Phillips screwdriver (long and short) 1/4"×13mm Screw 20120-13013-250 • ¼” Slotted screwdriver (long and short) • Adjustable wrench ø7 Lock Washer 41400-07000-250 • Pliers ø7 Washer 40300-07000-250 •... -
Page 5: Parts List
PARTS LIST FOR 85-1117-6 (G21201) Item Quantity Description Part No. Top Lid Cover G212-2000-01 Upper Hinge G508-8202-01 Upper Rear Panel G212-0013-01 Main Cart Frame G212-0004-01 Lower Hinge G508-8104-01 Cooking Grate, Sideburner G212-0012-01 Side Burner Assembly G212-0300-01 Sideburner Electrode Set G433-0047-01... - Page 6 EXPLOADED DIAGRAM FOR 85-1117-6 (G21201) Extras Manual Safety & Hardware Care Pack Manual...
- Page 7 ASSEMBLY INSTRUCTIONS Separate the 2 different types of wheels, 2 locking wheels (DD) and 2 regular wheels (EE). Attach the locking wheels (DD) to the back of the bottom shelf (CC) and the regular wheels (EE) to the front of the bottom shelf (CC).
- Page 8 ASSEMBLY INSTRUCTIONS Attach the left pillar (AA) and the right pillar (Z1) to the side panels (X & Y) and to the bottom shelf (CC), as shown in Figure A and B. #6 NO.10-24UNC x10 Screw (X6) #7 ø5 Lock washer (X6) Back view #8 ø5 Washer (X6) THIS STEP REQUIRES 2 OR MORE PEOPLE.
- Page 9 ASSEMBLY INSTRUCTIONS Attach the front brace (P) to the left and right pillars (Z1 & AA). TIP: One person should align the left side, while the second person assembles the right side. #6 NO.10-24UNC x10 Screw(X2) #7 ø 5 Lock Washer(X2) #8 ø...
- Page 10 ASSEMBLY INSTRUCTIONS TIP: Before attempting to assemble the door (BB) to the right pillar (AA), locate the two clasps on the door hinge. Next, locate the two small openings on the right side pillar. a. Hold the door perpendicular to the cart. Align the two clasps on the door hinge (BB), with the two holes on the right side pillar (AA).
- Page 11 ASSEMBLY INSTRUCTIONS a. Insert the grease tray (Q) into the opening in the upper back panel (B), making sure to engage tracks located under burner box. b. Place the grease cup (R) onto the tracks, located on the underside of the grease tray (Q). Back view Lift lid.
- Page 12 Attach the Regulator coupling nut to the LP cylinder valve. ATTENTION: For your families’ safety, do not attempt to light this BBQ until you have reviewed pages 4-7 of the CENTRO Safety & Care Manual. All Safety and Leak test MUST BE PERFORMED BY THE END-USER, prior to lighting this BBQ.
- Page 13 Step 1 o Extend your counter space Attach th to (A) by o Arrange your Centro BBQ and Centro Cuisine outdoor and #3 ( appliances at a 45° angle o Connect your Centro BBQ and Centro Cuisine outdoor PERFORMANCE AND...
