- Page 1 Mineral & Salt Chlorinator INSTALLATION MANUAL...
- Page 2 WELCOME This is the instruction manual for your Madimack’s InverCHLOR Mineral & Salt Chlorinator. This guide will help you understand the operation and maintenance of your filter, ensuring clean and clear pool water for your enjoyment.
-
Page 3: Table Of Contents
CONTENTS 1 Safety Warnings 2 Specifications 3 Product Overview 3.1 pH Doser 3.2 Control Display Overview 3.3 Controller Commands and Functions 4 Installation 4.1 Pool Water Preparation 4.1.1 Adding salt before operation 4.1.2 Water Balance 4.2 Installing the InverCHLOR 4.2.1 Location 4.2.2 Mounting the InverCHLOR 4.3 Installing the Cell Housing 4.3.1 Cell housing installation... -
Page 4: Safety Warnings
4. Children must not play with this device. User maintenance and cleaning must not be carried out by unsupervised children. 5. Use only genuine Madimack spare parts. WARNING: Electrical Hazard This equipment is intended to be used on swimming pools only. -
Page 5: Specifications
SPECIFICATIONS MODEL inverCHLOR 10 inverCHLOR 20 inverCHLOR 30 inverCHLOR 40 100% Chlorine Production 10g/hr 20g/hr 30g/hr 40g/hr (salinity @ 3000ppm) Recommended Salinity 3000ppm (3g/L) Salinity Operating Range 12000-6000ppm Power Supply 220~240VAC 50/60Hz Cell Amps @3000ppm 105a Cell Voltage Water Flow Rate 80-400lpm Water Connections 40/50mm... -
Page 6: Product Overview
PRODUCT OVERVIEW PORT NAME PHOTO DESCRIPTION Power Input AC Power Connector (220~240V, 50/60Hz) Pump Pump power outlet connection (max 9amps) (Water Pump Socket) Connector for the optional pH Doser. Push in the plug end Doser (Optional) and hand tighten the locking nut. RS 485 **Future provision only Connect the lead from the Cell housing to the port labelled... -
Page 7: Ph Doser
pH Doser Roller Squeeze Tube Acid Intlet Acid Outlet Power Supply from inverCHLOR (Injection Tee, Spare squeeze tube, Lubricant, Suction screen, 5m Dosing tube) -
Page 8: Control Display Overview
Control Display Overview Marked Area Description Icon Pool Salt Type (mineral/salt) Low Salt Alarm Heater- pump call activated Air detected in cell Wi-Fi Connection status Error Notification Chlorine Production% Pool Volumem 3 Timers Enabled Time Display Timer Active or Inactive Chlorine Mode (Auto/Manual) Acid Dosing ml/day Settings/ Menu... -
Page 9: Controller Commands And Functions
Controller Commands And Functions INSTALLATION 4.1 Pool Water Preparation Before operating the InverCHLOR it is important to prepare the pool water. The water chemistry must be balanced, and salt added. Certain adjustments to the chemical balance of the pool can take several hours. NOTE: This procedure MUST be started well before the chlorinator is turned on. -
Page 10: Installing The Inverchlor
InverCHLOR controller. • Madimack advises that the power supply should not be placed within 3 metres of the pool water. • Connect the InverCHLOR power supply to an appropriate weatherproof power outlet/controller. -
Page 11: Installing The Ph Doser
Installing the pH Doser WARNINGS: If the following instructions are not followed, there can be damage to persons & products. This may also void warranties. • Suitable Personal Protective Equipment (PPE) should be worn during the process. Consult warnings on chemical containers where necessary. -
Page 12: First Time Start Up
FIRST TIME TO START UP These steps will automatically load when you first start the InverCHLOR or if you perform a factory reset. Tip: The instructions for these steps are found in this manual under the ‘operation’ section. 1. Set the 24hr clock 2. -
Page 13: Acid Dosing (With The Added Ph Doser)
Acid Dosing (with the added pH Doser) 6.5.1 Understanding the pH doser Maintaining a constant pH has many benefits including reducing the amount of chlorine required, saving on other chemicals and protecting the pool surface. • If you have added the pH Doser, you can set the daily dosage amount to assist in maintaining a consistent pH level. •... -
Page 14: Setting The Auto Mode Timers
Setting the Auto mode Timers • To access the timer settings. Press SETTINGS to show AUTO/ MANUAL. • Ensure AUTO is selected and press SETTINGS again to show the dosing amount flashing. • Press SETTINGS again to show the dosing amount flashing •... -
Page 15: Maintenance
MAINTENANCE 7.1 Adding Salt The InverCHLOR must remain OFF during this operation and until the additive is completely dissolved. Operating the InverCHLOR with non-dissolved salt could irreversibly damage the cell and the power supply, and lead to a void of the warranty. For any new pool builds please wait for four weeks before adding salt into any recently cement coated pool and discuss this with your pool builder. -
Page 16: Ph Doser Maintenance
pH Doser Maintenance Pool acid its fumes are corrosive. It must be handled safely and according to the manufacturer’s instructions. Not diluting the acid will result in premature deterioration of the dosing and squeeze tube potentially leading to leaks and voiding warranty. -
Page 17: Maintenance Mode For Authorised Personnel Only
Maintenance Mode for Authorised Personnel Only • Turn off the unit first with the power button, so the display says OFF. • Enter ‘Maintenance Mode’ by holding together for 3 seconds. -
Page 18: Warranty
Please visit www.madimack.com.au for all warranty terms and conditions Madimack will, at its discretion, repair or replace any product proven to be defective during the warranty period for either materials or manufacture. Alternatively, Madimack will pay the cost of repair or replacement within 90 days of receiving the defective product, subject to unforeseen delays.
