X Rocker NEO MOTION CONTROL PANEL Manual

2.1 BLUETOOTH WITH VIBRATION AND SYNC LED - EN
VIEW LATEST
INSTRUCTIONS ONLINE:
1. Power On/Off Press to toggle chair on/off
2. Vibration Rotate dial to adjust intensity of vibration
3. Power Input Plug your power supply into this socket
Rotate the dial to adjust the intensity of Bass
4. Bass
audio
5. Volume Rotate this dial to adjust the master volume
Use this to switch between wired or Bluetooth
6. Mode
audio
*For chat support, please use PS4 or Xbox One controller connection method to enable pass through.
CONSOLE CONNECTION: CONTROLLER CONNECTION METHOD (PS4/PS5, XBOX ONE/SERIES, SWITCH)
SWITCH CONNECTION GUIDE
TM
1. Connect the B1 cable to the bottom of the Switch
2. Connect the other end of the B1 cable to the chair via the green input port.
XBOX ONE /SERIES CONTROLLER GUIDE*
TM TM
1. Connect the B1 cable to the bottom of the Xbox
2. Connect the other end of the B1 cable to the chair via the green input port.
3. The Xbox TM will automatically recognize the connection and pass through to the product.
4. To increase volume, press the guide button, navigate to the speaker icon and increase the
headset volume setting.
* For headset and chat compatibility, you will need to place a CTIA compliant headset into the headphone socket of the X Rocker control panel. Please check with your device manufacturer to ensure that you have a CTIA
compliant headset. If you use an OMTP compliant headset, then you may experience issues with chat and audio functionality.
** You may need an Xbox One TM headset adapter if a headset socket is not available on your controller. These are available separately through any gaming retailer.
*** Voice-Chat compatibility for Switch may rely on a third-party mobile phone app rather than direct console connection fro certain games, please check the game developer's information if you encounter any
TM
compatibility issues.
2
1
3
4
7. USB
8. EQ
9. Light
10. Input
11. Output
12. Headset
TM via the headphone socket.***
controller via the headset socket.**
TM
6 8 9
5
10
11
7
Used to charge devices such as mobile phones. (5V/1A Output)
Chose between Movie, Music and Game audio profiles
Short press to change pattern | Double click to change mode |
Long press to switch light
Plug the 3.5mm cable into here for audio from your TV or your
controller
Allows you to connect multiple chairs for audio
Plug your headphones or gaming headset in here to play
quietly. Perfect for night-time play.
PS4 DUALSHOCK 4
TM TM
1. Connect the B1 cable to the bottom of the PS4
2. Connect the other end of the B1 cable to the chair via the green input port.
3. With the PS4 turned on, go to the main menu (or locate the main menu screen). Press and hold the
TM
PS button on the PS4 controller until the quick menu appears on screen.
TM
4. In this menu select [Adjust sound and devices].
5. Then select [Output to Headphones].
6. Change the setting from [Chat Only] to [All Audio].
7. Make sure the volume in the previous menu is set to the maximum.
PS5 DUALSENSE CONNECTION GUIDE*
TM TM
1. Connect the B1 cable to the bottom of the PS5
2. Connect the other end of the B1 cable to the chair via the green input port.
3. Press the PlayStation button once to bring up the control center.
TM
4. Select [Sound] > [Output Device] > [Headset (controller)].
5. Ensure that [Output to Headphones] is correctly set to [All Audio].
6. You can check this by going to [Settings] > [Sound] > [Audio Output] > [Output to headphones] > [All
Audio].
B1
12
B2
Missing parts?
Contact X Rocker Support:
WWW.XROCKERUK.COM
CONNECTION GUIDE*
controller via the headset socket.
TM
Dual sense controller via the headset socket.
TM
