Summary of Contents for Omcan DA-CN-0480
- Page 1 Dry Age Cabinet Model DA-CN-0480 Item 46689 Instruction Manual Revised - 06/17/2024 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Model DA-CN-0480 Section Page Disclaimer ----------------------------------------------------------------------------------------------------- 3 General Information --------------------------------------------------------------------------------- 4 - 5 Safety and Warranty --------------------------------------------------------------------------------- 5 - 8 Technical Specifications ------------------------------------------------------------------------------- 9 Operation ------------------------------------------------------------------------------------------------ 9 - 11 Maintenance ----------------------------------------------------------------------------------------------- 12 Troubleshooting ----------------------------------------------------------------------------------- 12 - 13... -
Page 3: Disclaimer
Disclaimer OMCAN IS NOT RESPONSIBLE FOR ANY DAMAGES DUE TO WATER LEAKS. WARRANTY FOR WATER LEAKS IS VOID IF THE WICKING PAD IS NOT REPLACED EVERY SIX MONTHS, AND IF THE AMBIENT ROOM TEMPERATURE EXCEEDS 75°F AND 55% RELATIVE HUMIDITY, AND THE APPLIANCE DRAIN IS NOT CONNECTED DIRECTLY TO THE FLOOR DRAIN. -
Page 4: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 5: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 6 Safety and Warranty Sufficient space To allow for proper air circulation and increased refrigeration capabilities, the refrigerator must have at least 3 inches of space between wall and unit. Proper ventilation Always place the refrigerator in an area with good ventilation. For first time use, wait at least 2 hours before plugging into wall socket.
- Page 7 Safety and Warranty Protect cables Extra caution should be used when handling cables, as broken or damaged cables can cause sparking and may result in a fire. No water flushing Never flush the refrigerator surface. This can cause leakage, which may result in electrical damage or fire.
- Page 8 1 YEAR PARTS AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally.
-
Page 9: Technical Specifications
Technical Specifications Model DA-CN-0480 Item Number 46689 Net Volume 480 L / 16.95 cu.ft. Power 200 W Electrical 110-120V / 60Hz / 1 Current 1.8A Temperature Range 0 - 25°C / 32 - 77°F Max Ambient Temp Rating 24°C / 75°F... - Page 10 Operation 5. Open the food package and remove the foil. Put the meat on the stainless steel plate and put the plate inside the device. Check whether there is water in the plate every 2-3 days. If there is any water, please clear the water.
- Page 11 Operation OPERATING AND CONTROL SETTINGS :Power ON/OFF :LED lights on and off. :View / change the temperature settings. :View / change humidity settings / select or confirm parameter settings. :Short press to increase temperature and humidity setting / long press UVC to turn on and off. :Short press to reduce temperature and humidity setting / long press to defrost manually.
-
Page 12: Maintenance
Regulate the temperature controller. Noisy. The refrigerator is not level. The refrigerator is making contact with the wall or other objects. There is a loose part in the refrigerator. Contact Omcan for help if simple trouble shooting does not solve the problems. - Page 13 Troubleshooting NOTE Following occurrences are not problems: • The murmur of water is heard when the refrigerator is working. It is a normal occurrence as the coolant is circulating in the system. • When the weather is damp, condensation might be found on the outside of the refrigerator. It is caused by high humidity.
-
Page 14: Parts Breakdown
Parts Breakdown Model DA-CN-0480 46689... - Page 15 Parts Breakdown Model DA-CN-0480 46689...
- Page 16 Parts Breakdown Model DA-CN-0480 46689 Item No. Description Position Item No. Description Position Item No. Description Position Switching Power Supply for Magnetron Probe Fixing Plate Door Handles-Guide Rail Spray AQ506 AQ529 AQ548 46689 Spray Paint for 46689 Paint for 46689...
- Page 17 Parts Breakdown Model DA-CN-0480 46689 Item No. Description Position Item No. Description Position Item No. Description Position The Door Frame Reinforcement Lower Door Shaft Sleeve for AQ571 AQ575 Add Popular Glass for 46689 AQ579 Plate for 46689 46689 Under-Door Border Decoration...
-
Page 18: Electrical Schematics
Electrical Schematics Model DA-CN-0480 46689... -
Page 19: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 20 à plus de 6500 produits provenant du monde entier. Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir a nuestro compromiso de fortalecer y desarrollar nuevas relaciones...
