01865 767676
sales@unicol.com
www.unicol.com
ODH
Screen Size: 30-86"
Guide Max. Weight: variable
Revised 15/08/24
*Please check model specific details before installing*
WARNING
Please carefully inspect the product before assembling. If you notice any apparent damage, call your
carrier claims agent and do not continue the installation until it has been reviewed. Please watch for pinch
points. Do not put your fingers between moveable parts. Do not tamper with or disassemble any spring
loaded parts. Before installing, make sure that the supporting surface will support five times the combined
load of the solution and the hardware. Never exceed the maximum load capacity. Please also layout all
components to ensure that you have all of the required parts before proceeding (see BOM list on following
page). Use of this product for anything other than its specified use may result in failure or personal
injury. This product is intended for indoor use only. We recommend using a qualified trades person for
installation. Use an assistant or lifting equipment to lift and position products.
For support, please call: +44 (0)1865 767676 or email: sales@unicol.com
Advertisement
Summary of Contents for Unicol ODH Series
- Page 1 Use of this product for anything other than its specified use may result in failure or personal injury. This product is intended for indoor use only. We recommend using a qualified trades person for installation. Use an assistant or lifting equipment to lift and position products. For support, please call: +44 (0)1865 767676 or email: sales@unicol.com...
- Page 2 01865 767676 sales@unicol.com www.unicol.com TOOLS REQUIRED INSTALLERS REQUIRED Security Allen Keys Pozi Head Screwdriver COMPONENTS DESCRIPTION Front Cover and Polycarbonate Screen ODH Main Body inc. Components Please Note: Power Cable Not Supplied Mount Back Plate Mounting Arms Main Connection Block...
- Page 3 01865 767676 sales@unicol.com www.unicol.com STEP 2 STEP 1 Remove both front cover retaining screws using the Lift off front cover by unhooking at top. Separate security allen key. Main Body from Screen rail by unbolting transport bolts from screen rail and main body.
- Page 4 01865 767676 sales@unicol.com www.unicol.com Blue cooling thermostat Red heating thermostat STEP 5 STEP 6 Connect the feed to the housing via the highlighted Locate the mounting holes on the back of your feed points, as shown in the BOM. screen. Line the two mounting arms up (position...
