- Page 1 IP NETWORK TALKBACK TERMINAL User Manual T-6702A Before using the system, please read this manual first...
-
Page 2: Important Instruction
● This machine can only be used for AC~220V/50Hz region, not for additional areas. ● Due to the continuous updating of appearance and function, please kindly see the models based on the entity, And the final interpretation of the product specification belongs to ITC. - 2 -... -
Page 3: Table Of Contents
Contents Foreword................................... 4 1. Product Overview..............................5 2. Features................................5 3. Components and Features..........................6 4. System connection diagram..........................7 5. Operation Instructions............................7 6. Block diagram..............................16 7. Performance Specifications..........................17 8. Common fault dealing............................18 - 3 -... -
Page 4: Foreword
Foreword ● "IP network talkback terminal products Manual" mainly describes the method of operation T-6702A IP network talkback terminal, as well as the main performance parameters, common faults solutions. ● This manual operation instruction is just as a user, not as a service purposes. from the date of issue, after which the feature or related specifications are subject to change, would otherwise add that detail to each dealer. -
Page 5: Product Overview
1. Product Overview The T-6702A is an ideal choice for the call center, alarm center, office, leading office, conference room etc. It can one-way paging for the different terminals. (To point, single zone or whole zones) intercom and monitor. 2. Features 1. -
Page 6: Components And Features
3. Parts name and function introduction Microphone Line IN/OUT 3.5mm MIC Input Build-in Monitor Speaker Short-Circuit IN/OUT LCD Screen Earphone Input Power IN Serial Data Power On/Off Interface Interface ● Microphone: MIC input. ● Build-in monitor speaker: to monitor the current voice environment. ●... -
Page 7: System Connection Diagram
1. Use the serial port cable to connect “TERMINAL” and “PC TERMINAL” or transfer to USB interface, open the computer “START”-- “ALL PROGRAMS”, find “ITC Intelligent Network Public Address” then choose “IP Public Address TERMINAL configuration program”, run the software, open the terminal configuration, dialog box as following picture: 2. - Page 8 picture: 3. Query (If add terminal) is done, make sure IP address is right, fill IP address you want into IP address bar (example: 192.168.1.100), showing dialog box as picture 3, as following picture: 4. Make sure IP address writing finished, click “Write”, after confirm the address is right, showing dialog box as picture 4 (Terminal configuration will get MAC automatically), as following picture: 5.
- Page 9 6. Click “Query”, after check is done, will show dialog box like picture 6, this IP address configuration is finish. 2) IP Network Broadcast System Setting In “Terminal Setting” set one piece IP machine code as machine calling center, press machine paging button will realize talk between two terminals.
-
Page 10: Display Screen Introduction
3) Display screen introduction After open up, the interface show: ① “LOGIN USER” button: when IP terminal doesn’t fill 001, if want machine to work, should logging in first, enter 001 and click OK, then this button will show: “cancel user” and then begin to dual talkback or signal speak, or it can not work. - Page 11 separate panel. ⑧ "TALKBACK" button, "CALL" one-way call button and "MONITOR" button: when to realize the corresponding function, there are two kinds of operation mode, for example: press CALL + numeric key + OK or numeric keys + CALL can do the same operation. ⑨...
- Page 12 "CANCEL" button, the display will prompt the current call has been hung up, then the red and green status lights microphone pole slow flash, the display screen shows as below: 5) Call On the condition of welcome, press the "CALL" button, enter the conference paging state, as shown below: Enter the set well terminal code and press "OK"...
- Page 13 If need to end the current paging broadcast, need to press the "CANCEL" button, the display will show the current call has hung up. 6) Monitor On the condition of welcome, press "MONITOR" button, enter dial monitor state, as shown below: Enter the set terminal code and press "OK"...
- Page 14 monitor running, as shown below: To cancel the current dial-up monitoring, need to press the terminal display "CANCEL" button, the display shows the current dial-up has been completed on the monitor screen, the display returns to the "welcome to use IP broadcast system" state. 7).
- Page 15 After this time, the status of the call microphone pole on the terminal lights green flash, wait about five seconds, the terminal will automatically connect, the terminal display will show is on, as shown below: To cancel the current broadcast of the whole zone, need to press the "CANCEL" button on the terminal, the display shows the current call has been hung up, as shown below: 9) one-key single zone broadcast Under the status of welcome interface, press "ZONE1"...
-
Page 16: Block Diagram
If the current broadcast required to cancel, press the "CANCEL" button on the terminal, the display will show the current call has been hung up, shown as below: 6. Equipment Schematic Diagram - 16 -... -
Page 17: Technical Parameters
7. Technical Parameters Model T-6702A Interface Standard RJ45 input Support Protocol TCP/IP, UDP, IGMP(multicast) Audio Format MP3/MP2 Sampling Rate 8K~48KHz Transmission Rate 100Mbps Audio Mode 16-bit stereo CD quality Display Size 7 inch Screen Resolution 800*480 pixels Screen Type 65K color screen DGUS... -
Page 18: Common Fault Dealing
8. Troubleshooting Dealing Methods ① Question: Why it cannot call or talk to other terminals? The reason for this situation is that the other intercom terminal is receiving a higher priority task, you can wait until the other terminal finished task, or you can contact the administrator to improve your task priority. - Page 19 IP Network Talk back Terminal VersionV0.2...
