Page 1 User Manual RK200 CONTACT US FOR MORE TECH SUPPORT +1 (888)892-0155 Mon-Fri 7:00AM - 7:00PM (PST)
Page 2 CONTACT US FOR MORE TECH SUPPORT +1 (888)892-0155 Mon-Fri 7:00AM - 7:00PM (PST) +86 19129317359...
Page 3: Table Of Contents
200W solar panel generate? 4.3 Can it be connected in series with other brands of 200W panels? 4.4 Can it be connected in parallel with other brands of 200W panels? 5 FCC Compliance Statement Copyright ©2023 Ruko All Rights Reserved.
Page 4: Pre-Use Instructions
Please note that manufacturers or retailers do not assume responsibility for losses resulting from improper usage, so strictly adhere to the user manual for proper equipment functioning. Copyright ©2023 Ruko All Rights Reserved.
Page 5: Product Description
R K 2 00 User Manual 2 Product Description The foldable RK200 solar panel utilizes advanced ETFE layering technology and is equipped with 60 high-efﬁciency solar cells. While it offers 200W full nominal power generation, the actual output is subject to various factors, such as sunlight intensity, solar panel surface temperature, sunlight angle, and shading.
Page 7 BC1.2, Apple, Samsung, Qualcomm QC2.0 and QC3.0, PPS, PD2.0, PD3.0, PE2.0, Huawei Fast Charging Protocol FCP, Huawei Super Charge Protocol SCP. Note Power indicator lights on when the solar panel is powered and off when it's not. Copyright ©2023 Ruko All Rights Reserved.
Page 9: Specification
IP Rating IP67 Operating Voltage Operating Current 11.11A Open Circuit Voltage 21.6V Short Circuit Current 13.33A Operating Temperature Range 14 F-149 F Unfolded Dimensions 26.38x73.2x1.38in Folded Dimensions 26.38x20.1x2.75in Net Weight 19lb±1% Output Interface XT60H-F Copyright ©2023 Ruko All Rights Reserved.
Page 10: How To Use
RK2 00 User Manual 2.4 How to Use Open the storage bag and take out the solar charge cable. Stand up and then unfold the solar panel. Unfold and then ﬁx the support stands. Copyright ©2023 Ruko All Rights Reserved.
Page 11 R K 2 00 User Manual Ensure that the solar panel is placed securely. Charge solar generators by using the solar charger cable. Charge other devices by using the charging expansion box. Copyright ©2023 Ruko All Rights Reserved.
Page 12 Please choose a parallel exceed safe human touch cable that can support or your device's charging the current ﬂow. voltage. Notes Please proceed with caution to avoid the risk of electric shock and damage to the device. Copyright ©2023 Ruko All Rights Reserved.
Page 14 The adjustable stands should be used before 10:00 am or after 2:00 pm. To use the solar panel during midday, simply place the solar panel ﬂat on the ground. Noon Late Early Afternoon Morning Copyright ©2023 Ruko All Rights Reserved.
Page 16: Safety Instructions
It is necessary to utilize the provided charging expansion box to charge other devices. When charging the device, prevent short circuits between positive and negative terminals to avoid device damage or electrical shock hazards. Copyright ©2023 Ruko All Rights Reserved.
Page 17 Please understand circuit principles before operating. During use, it's a normal situation that the solar panel would bend slightly for a period of time with an increase in temperature. Normal Operating State High-Temperature Operating State Copyright ©2023 Ruko All Rights Reserved.
Page 18: Maintenance And Care
Please follow federal and state guidelines for proper disposal, locate local e-waste recycling centers for responsible disposal, and consider professional e-waste disposal services for compliance with regulations. Always prioritize recycling options over landﬁll disposal for electronic waste. Copyright ©2023 Ruko All Rights Reserved.
Page 19: Faq
A ±10 degree deviation from the 90° angle has minimal impact on panel power. 5.Panel Shading During use, the panel's surface should remain unblocked. Shadows, foreign objects, and even glass can considerably diminish power output. Copyright ©2023 Ruko All Rights Reserved.
Page 20: Under Normal Conditions, How Much Power Can
If you intend to connect multiple panels in series, it's advisable to use panels of the same speciﬁcations and sizes. Additionally, ensure that the voltage after the series connection remains within the limits supported by your equipment. Copyright ©2023 Ruko All Rights Reserved.
Page 21: Can It Be Connected In Parallel With Other Brands
If you intend to parallel more than two 200W panels, ensure that your equipment's maximum allowable current supports the input current after parallel connection and that the parallel connection cables are capable of handling the maximum combined current after paralleling. Copyright ©2023 Ruko All Rights Reserved.
Page 22: Fcc Compliance Statement
Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at your own expense. Copyright ©2023 Ruko All Rights Reserved.
Page 24 CONTACT US FOR MORE TECH SUPPORT +1 (888)892-0155 Mon-Fri 7:00AM - 7:00PM (PST) rukodrone@gmail.com +86 19129317359...
