SERVICE MANUAL
MICRO COMPONENT SYSTEM
Contents
Safety precautions
Important for laser products
Preventing static electricity
Disassembly method
Adjustment method
UX-T550
Flow of functional operation
1-2
1-4
Maintenance of laser pickup
1-5
Replacement of laser pickup
1-6
Description of major ICs
1-17
This service manual is printed on 100% recycled paper.
COPYRIGHT
2001 VICTOR COMPANY OF JAPAN, LTD.
Area Suffix
B ------------------------------- U.K.
E ----------- Continental Europe
EN ------------ Northern Europe
EV -------------- Eastern Europe
EE --------- Russian Federation
until TOC read
UX-T550
1-21
1-22
1-22
1-23
No.20908
Jan. 2001
