- Page 1 U-BRACKET SPEAKER BRACKET / SUPPORT D'ENCEINTE / SOPORTE DE ALTAVOZ КРЕПЛЕНИЕ ДЛЯ АКУСТИЧЕСКОЙ СИСТЕМЫ 音箱支架 / スピーカーブラケット Owner’s Manual Benutzerhandbuch Mode d’emploi Manual de instrucciones Manual do Proprietário Manuale di istruzioni Руководство пользователя 使用说明书 ZH-CN 使用說明書 ZH-TW 사용 설명서 取扱説明書...
-
Page 2: Table Of Contents
Check Before Installation ............3 Introduction Thank you for purchasing the Yamaha UB-DXRDHR12 or UB-DXRDHR10 U-BRACKET. This product is a bracket designed for use in installation of the following Yamaha speakers: UB-DXRDHR12: DXR12, DHR12, CHR12 UB-DXRDHR10: DXR10, DHR10, CHR10 This manual explains how installation personnel can attach a speaker to the bracket and install the speaker on a wall or ceiling. -
Page 3: Package Contents
If the wire is too long, and the speaker happens to fall, the wire may snap as a result of too much strain. Yamaha cannot be held responsible for damage or injury caused by insufficient strength of the support structure or improper installation. -
Page 4: Installation Instructions
The recommended torque is ate metal brackets and bolts. These metal brackets or 12.4 Nm. bolts are not included in the package. If you are not sure what to use to affix the U-bracket, consult a specialist. UB-DXRDHR12 UB-DXRDHR10 Owner’s Manual... -
Page 5: Horizontal Installation
M5 × 10 M5 × 10 Adjust the speaker angle, then tighten the bolts until the speaker is securely affixed. The recommended torque is For DXR For DHR and CHR 12.4 Nm. 10 mm 18 mm thick thick UB-DXRDHR12 UB-DXRDHR10 Owner’s Manual... -
Page 6: Specifications
* 본 설 명 서 의 내 용 은 발 행 일 현 재 최 신 사 양 을 기 준 으 로 하 고 있 습 니 다 . 최 신 설 명 서 를 가 져 오 려 면... -
Page 7: Dimensions
寸法図Dimensions (Abmessungen)DimensionsDimensions (Dimensiones)Dimensions (Dimensões)Dimensions (Dimensioni) Dimensions (Габаритные размеры)Dimensions ( 규 격 ) Dimensions / 外形尺寸 / 尺寸 UB-DXRDHR12 266.5 250.2 250.2 Unit: mm 単位：mm 125.1 125.1 UB-DXRDHR10 222.5 327.5 50.8 213.8 213.8 Unit: mm 単位：mm 213.8 UB-DXRDHR12 UB-DXRDHR10 Owner’s Manual... - Page 8 Wenden Sie sich für nähere Informationen zu Produkten an eine Yamaha-Vertretung oder einen autorisierten Händler in Ihrer Nähe. Diese finden Sie mithilfe des unten abgebildeten 2D-Strichodes. Français Pour obtenir des informations sur le ou les produits, contactez votre représentant ou revendeur agréé Yamaha le plus proche. Vous le trouverez à l'aide du code-barres 2D ci-dessous. Español Para ver información detallada sobre el producto, contacte con su representante o distribuidor autorizado Yamaha más cercano.
