OWNER'S MANUAL
WASHING MACHINE
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
F4X7009T*B
MFL72134415
Rev.00_072024
Copyright © 2024 LG Electronics. All Rights Reserved
www.lg.com
