Installer: Leave this manual with the proud new owner
*
*
Renaissance Cooking Systems
Owner's Manual
America's Best Value in Outdoor Kitchen Equipment
Installation, Operation, Maintenance
Instructions & Parts List
REFR3 & REFR3A
Cubed & Nugget Ice Makers
We strongly recommend utilizing a water filter with this ice maker.
For the latest news, recipes and cooking tips for your new
Renaissance Cooking Systems , check out www.RCSGasGrills.com
Page 1
Advertisement
Summary of Contents for Renaissance Cooking Systems REFR3
- Page 1 Instructions & Parts List REFR3 & REFR3A Cubed & Nugget Ice Makers We strongly recommend utilizing a water filter with this ice maker. For the latest news, recipes and cooking tips for your new Renaissance Cooking Systems , check out www.RCSGasGrills.com Page 1...
- Page 2 Safety information Before using your ice machine, please read this manual thoroughly to ensure that you know how to operate the features and functions that the equipment offers safely and efficiently. Important safety symbols and precautions: Please read and always follow all safety instructions in this manual. This is the safety alert symbol.
-
Page 3: Installation Information
10- Do not install the ice machine in a damp location where it may come in contact. Deteriorated insulation on electrical parts may cause an electric shock or fire. 11- In order to keep the lubricant fully precipitated before start up, please keep the machine upright for 24 hours before plugging to prevent compressor damage. - Page 4 Water supply and ambient temperature 1- The water used for ice machine must be in accordance with local drinking water quality standards. We recommend installation of an in-line water filter to the ice machine, this will reduce lime and scale build up, improve efficiency and extend the overall lifespan of the machine.
- Page 5 Warning If the ice machine is turned off, please wait for at least 3 minutes before restarting to prevent damage to the compressor. 4- Electric Specification MODEL VOLTAGE WATTE CURRENT REFR3 & REFR3A 220 /50Hz, 110V/60Hz 160W 1.5A Page 5...
- Page 6 Pre-start up check list 1- Has the unit been connected to the proper water supply and no leaks? 2- Has the unit been connected to a drain and no leaks? 3- Has the unit connected to the proper electrical supply? 4- Has the unit been leveled? 5- Have all packing materials been removed from the ice machine? 6- Is there proper ventilation around all side of the ice machine?
- Page 7 REFR3 - Cubed Ice Machine Your ice machine features a touch control to operate the controls, please lightly tap the control button with your finger tip. The control panel also feature an easy read display which shows the status of the ice machine at all times.
-
Page 8: Major Functions
REFR3 - Cubed Ice Machine Ice Size Adjustment Guide: 1. Press and hold the “Adjust” button for at least 3 seconds. The unit will enter the Ice Size Adjustment mode. The “HARVEST” LED (yellow) will be blinking continuously during the ice size adjustment. Release the button when the LED blinks continuously to adjust the ice size. - Page 9 REFR3A - Nugget Ice Machine Operating Instructions Your ice machine features a touch control to operate the controls, please lightly tap the control button with your finger tip. The control panel also feature an easy read display which shows the status of the ice machine at all times. Digital&...
- Page 10 REFR3A - Nugget Ice Machine Note: The ice maker will automatically start the ice making cycle after plugging in the machine and powering it on. Note: The display window will appear “Co” while water inlet is filled by the water valve Note: During the ice making cycle, Pressing the set button 5 seconds will enforce the harvest cycle immediately.
- Page 11 REFR3A - Nugget Ice Machine Note: When first turning on the ice maker, the system will rinse itself before making ice. The rinsing process takes about 5 minute. Note: During the ice making cycle or ice harvest cycle, the water clean button does not work, the clean indicator will quickly flash.
- Page 12 Maintenance & Cleaning Periodic cleaning and proper maintenance will extend the life of your ice machine, ensure maximum efficiency, and deliver better ice. Warning: Disconnect the ice maker from the main electrical and the water source before preforming any cleaning or maintenance. Warning: Inspection, descaling and servicing should only be performed by a qualified technician.
- Page 13 Air filter cleaning The ice machine is equipped with a condenser dust filter to prevent dirt and dust from entering the condenser. It is important that the condenser and air filter is cleaned routinely to ensure efficient operation of the machine. We recommend this procedure is carried out every 30 days.
-
Page 14: Troubleshooting
Trouble shooting Before calling for service, review the error code, symptoms and recommended solution below, if none of the suggested solution resolve your problem, please contact your local distributor or authorized service company. Error Symptom Possible cause Solution code Ice damper Ice damper Check ice damper and or ice full... - Page 15 Shortage of Water supply Make sure the water Water is turned off or supply is turned on and no water has a good connection. Water pressure Make sure the water too low or water pressure is between leak 0.2psi to 0.8psi Water inlet valve Check the water inlet not opening...
- Page 16 Power Power Surge or Make sure all lights are on for REFR3 Restart the unit. After Power Outage unplugging make sure to wait 3 minutes before restarting the machine. (See page 7 for additional help with REFR3 Cubed Ice Maker)
- Page 17 Renaissance Cooking Systems Product Warranty RCS is proud to provide the industries most comprehensive warranty program. All RCS American Renaissance Grills, Cutlass Pro Series Grills and Cutlass Pro Series side burners, sinks, as well as ALL doors and drawers are warrantied to be free from manufacturer defects for the lifetime of the original owner.
