ROSSO E - BIKE X

ELECTRIC DIRT BIKE

OWNERS MANUAL

PRIOR TO FIRST USE, READ THIS MANUAL COMPLETELY AND ATTENTIVELY! IMPERATIVELY FOLLOW THE SAFETY INSTRUCTIONS!

NONOBSERVANCE CAN LEAD TO PERILOUS INJURIES! CAREFULLY KEEP THIS MANUAL!

Table of Contents

Need help?

Do you have a question about the E-BIKE X and is the answer not in the manual?

Questions and answers

Summary of Contents for ROSSO E-BIKE X

Page 1 ROSSO E - BIKE X ELECTRIC DIRT BIKE OWNERS MANUAL PRIOR TO FIRST USE, READ THIS MANUAL COMPLETELY AND ATTENTIVELY! IMPERATIVELY FOLLOW THE SAFETY INSTRUCTIONS! NONOBSERVANCE CAN LEAD TO PERILOUS INJURIES! CAREFULLY KEEP THIS MANUAL!
Page 2 PLEASE INSPECT THIS EQUAD Q UPON ARRIVAL AND REPORT ANY DAMAGES THAT MAY HAVE OCCURRED DURING SHIPPING...
Page 3 Rosso Motors recommends that owners periodically review and reinforce the information in this manual with younger riders, and inspect and maintain this machine to ensure any rider’s safety. An owner's decision to allow a child to ride this product should be based on the child’s maturity, skill and...
Page 4: Safety Information
SAFETY INFORMATION ALWAYS follow safety information, product instructions and recommended maintenance and care, to ensure the best possible performance, lifespan and experience with a new ebike! ALWAYS wear proper protective safety equipment. (See details below) ALWAYS check and obey any local laws or regulations that may affect the locations where the eBike may be used.
Page 5 NEVER immerse in or saturate the bike with water, as the electrical and drive components could be damaged by water or create other possible unsafe conditions. While shallow depths of water, such as shallow puddles or a few cm of mud or snow are most likely ok, avoid levels of water that may be near to or deeper than the unit’s ground clearance.
Page 6 ASSEMBLY ● The Rosso eBike X requires minimum assembly. ● Please follow the instructions below in order to get this eBike X assembled properly ● An assembly video can also be found at https://youtu.be/b2DrDNYvCfQ ● For stability and to make assembly easier, we recommend leaving the e-dirt bike attached to the base of the metal shipping cage until installing components on that portion of the bike.
Page 7: Handlebar Installation
2. Handlebar installation: Attach the handlebar clamps(a) overtop of the handlebars(b) with the included bolts, correctly position and center the handlebars, tightening the bolts into the handlebar bracket(d). ⚠ FAILURE TO PROPERLY ADJUST & TIGHTEN THESE BOLTS CAN CAUSE LOSS OF CONTROL & ACCIDENT ⚠ 3.
Page 8 ASSEMBLY continued… Loosen the mounting bolt on the number plate and shift the number plate into position slotting the plastic pins on the fender into the holes on the bottom of the number plate. Tighten the mounting bolt on the number plate. 4.
Page 9: Rear Shock Installation
The last step in the front wheel installation is to attach the brake caliper. Slide the caliper over the brake disc and align the mounting bracket. Secure the caliper to the fork with the 2 hex bolts from the hardware box. Secure the brake cable with the clamp located on the fork just above the wheel. 5.
Page 10: Fuse Installation
ASSEMBLY continued… 6. Fuse installation: Find the fuse case on the red positive battery wire, located under the seat near the charging port. Open the case, install one of the included fuses and securely close the fuse case. 7. Reflectors & Final adjustments Attach the red rear reflectors to the reflector mount located underneath the very rear of the seat with the included nuts.
Page 11: Component Diagram
COMPONENT DIAGRAM eBike X Components: (a) forward/reverse gear switch (f) throttle/battery meter & front brake lever (b) 36V Battery (3x12V 12AH) (g) rear brake lever (c) controller (h) kickstand (d) 1000W motor (e) 3-speed switch (left side) & charging port (right side)
Page 12: Basic Operation
OPERATION Basic Operation With the dirt bike powered on, gently twist the throttle until the desired speed is reached. Release the throttle and squeeze both brake levers to stop. Charging Step 1 - Ensure the eBike X is turned off (see instructions pg 11) Step 2 - Plug the charger into a wall outlet.
Page 13 Oppositely if it does not do either that does not indicate it is not working properly. If the charger becomes very hot, please unplug it and contact Rosso Motors technical support. The charger supplied with the ebike should be regularly examined for damage to the cord, plugs, enclosure and other parts.
Page 14: Pre-Ride Checklist
PRE-RIDE CHECKLIST Ensure to check the following before each ride to ensure maximum safety: Brakes - Check the brakes for proper function. When the levers are squeezed, the brakes should provide positive braking action. Tires – Check tires periodically. Inspect tires for excess wear and replace them as needed. (Please note riding on abrasive surfaces such as concrete or asphalt will increase tire wear.) Regularly check the tire pressure and inflate as needed.
Page 15: Brake Adjustments
Brake adjustments Failure to inspect and properly adjust brakes increases the risk of having an accident. Riding with worn brake pads can reduce braking performance and cause an accident. Check and adjust brakes if needed before each ride. To adjust cable play on the left (rear) or right (front) brake lever, tighten/loosen the adjuster. To adjust the calipers, loosen (do not remove completely) the anchor nut(a) and pull the brake cable(c) until the brake pads are almost touching the rotor(b) (brake disc).
Page 16 MAINTENANCE continued… Chain The eBike X is chain-driven and should be periodically lubricated with lithium spray. The chain may make some clicking noises, this is normal. Always inspect, maintain or adjust the chain, if necessary, before each ride. Riding with a chain in poor condition or one improperly adjusted, can lead to serious injury.
Page 17: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Solution Power does not turn on Fuse not installed/burnt out Replace fuse Bike is turned off Turn ignition switch on Battery not connected Connect battery Battery not charged Charge battery Loose connection Check connections on the battery, controller &...
Page 18: Wiring Diagram
WIRING DIAGRAM...
Page 19: Warranty
WARRANTY ROSSO MOTORS warranties this product to be free of manufacturing defects for a period of 6 months from the date of purchase. This limited warranty does not cover normal wear and tear components, (tires, tubes, brake cables, etc) or any damage, failure or loss caused by improper assembly, maintenance, care, storage or use of the eBike X.
