- Page 1 SABRE Relay/Inline Quickstart Guide 8825-000 | 8820-000 Last Updated: August 27, 2024...
-
Page 2: Table Of Contents
Introduction In the box Contents Specifications Installation Disclaimers Support Safetrust Inc. | safetrust.com sales@safetrust.com... -
Page 3: Introduction
Introduction Safetrust Inc. | safetrust.com sales@safetrust.com... - Page 4 Credential Manager for OTA remote management and configuration. The SABRE RELAY is an extension of the INLINE device with additional access controller management capabilities. The RELAY is ideally suited for parking garages, remote buildings and single door offices where no existing cabling or reader infrastructure exists.
-
Page 5: In The Box
In the box Safetrust Inc. | safetrust.com sales@safetrust.com... - Page 6 Included Not Included (Required) a) INLINE or RELAY Sensor b) Wiring c) 7 1/8 in Solid and Stranded Wire Stripper d) Insulation Displacement Connector, Moisture Resistant, 300 V Max e) Screwdriver Safetrust Inc. | safetrust.com sales@safetrust.com...
-
Page 7: Specifications
Specifications Safetrust Inc. | safetrust.com sales@safetrust.com... - Page 8 Bluetooth Low Energy 2.400 GHz - 2.4835 GHz 48V 5A relay IoT Protocol Mobile Operating Systems MQTT (ISO/IEC PRF 20922) Apple iOS 9.0 or later and Android 4.4 or later on devices with the Safetrust Wallet Safetrust Inc. | safetrust.com sales@safetrust.com...
- Page 9 Dimensions 65mm x 30mm x 12mm Safetrust Inc. | safetrust.com sales@safetrust.com...
- Page 10 FCC Part 15 Modular Transmitter HID®, Indala®, AWID®, GE Casi®, Certification, Canada IC, EU EMC CE, Farpointe and Honeywell®, MIFARE® India ETA-WPC, RCM, RoHS. WEEE Classic, MIFARE® DESFire® and Seos® Credentials Power Requirements 5-12 V DC Safetrust Inc. | safetrust.com sales@safetrust.com...
-
Page 11: Installation
Installation Safetrust Inc. | safetrust.com sales@safetrust.com... - Page 12 Note: This guide assumes you have already created an Identity System within the Credential Manager platform and assigned credentials to that system. If you have not done so, please refer to the Safetrust Onboarding Guide before completing the sensor installation.
-
Page 13: Wiring Illustration
9 — Relay 5v In Ext 8 — Relay 5v In2 Ext 7 — Relay In 6 — Normally Closed 5 — Common 4 — Normally Open 3 — Ground 2 — Relay Out 1 — 12V Safetrust Inc. | safetrust.com sales@safetrust.com... - Page 14 3.3v and as such, please consult with your panel manufacturer for permitted line voltage levels. In most cases panels are compliant with RS-485 and accept the range 2.5 - 5v. Safetrust Inc. | safetrust.com sales@safetrust.com...
-
Page 15: Standard Wiring
0 RS-485 A' and 'Data 1 RS-485 B' connections on the reader connector of the Inline/Relay, and connect the 'Data 0' and 'Data 1' outputs from the panel connector to the Wiegand input on the panel. Safetrust Inc. | safetrust.com sales@safetrust.com... - Page 16 For Wiegand translated to RS-485 (OSDP), connect the wires the same way as above between the reader and the Inline/Relay, and connect the 'RS-485 A' and 'RS-485 B' outputs from the panel connector to the RS-485/OSDP input on the panel. Safetrust Inc. | safetrust.com sales@safetrust.com...
- Page 17 Bluetooth and configures the sensor for an Identity System. Setup: • Open your Safetrust Wallet App or download it from the App Store or Google Play if you haven't already. • Login with Google Sign-In or with the username and password that you set your Safetrust account up with.
- Page 18 With the Manage Sensor tab open, bring the phone in range of the SABRE and once visible from the App, click on the sensor. Note: You may need to click the refresh button in the top right hand corner. Once the sensor is highlighted, click CONFIGURE from the bottom options. Safetrust Inc. | safetrust.com sales@safetrust.com...
- Page 19 • Specify the Type of access from the dropdown (eg. Door, Gate etc.) • Assign a short Name and Description using alphanumeric characters. • Choose an Output for the sensor (the default is set to Wiegand). Safetrust Inc. | safetrust.com sales@safetrust.com...
- Page 20 Configuring Wi-Fi (Recommended but optional) To connect the sensor to a Wi–Fi network, click the 'Configure Wi-Fi' toggle button. Switching the toggle will reveal additional settings below. Safetrust Inc. | safetrust.com sales@safetrust.com...
- Page 21 Click the 'Choose a network' setting or type in the Wi–Fi Name in the 'Wi–Fi Name' field. If your network is not listed, try clicking the refresh icon next to 'Choose a network'. Safetrust Inc. | safetrust.com sales@safetrust.com...
- Page 22 Choose the network type - Personal or Enterprise. For Enterprise 802.1X networks, click the 'Root certificate' and 'Client p12' buttons to upload your certificates. Type the P12 password in the 'P12 password' field. Safetrust Inc. | safetrust.com sales@safetrust.com...
- Page 23 Set the Activation Distance for your sensor between touch and 50 ft (15m). The distance will automatically be set to 30cm, meaning a user needs to be within 30cm in order to "Auto Authenticate" to the reader. Safetrust Inc. | safetrust.com sales@safetrust.com...
-
Page 24: Anti-Passback
Anti-Passback can be used to prevent users from passing their credential back for another user to borrow and to stop users entering an area by simply following or tailgating another user. Safetrust Inc. | safetrust.com sales@safetrust.com... - Page 25 If the Output is set to OSDP, select the Serial Baudrate and set the Device ID to match the settings of the access control panel. Once you have adjusted all the configuration settings, scroll to the bottom of the page and click SUBMIT to successfully complete the sensor configuration. Safetrust Inc. | safetrust.com sales@safetrust.com...
-
Page 26: Configuration Complete
Configuration complete! Getting Access: • To open the door, simply present your mobile device running the Safetrust Wallet application to the reader. • When the phone is within the configured activation range, the LED on the assigned credential for this sensor will turn yellow. -
Page 27: Disclaimers
Disclaimers Safetrust Inc. | safetrust.com sales@safetrust.com... - Page 28 Safetrust, SABRE Relay, SABRE Inline and Safetrust Wallet are all trademarks of Safetrust Inc. All other product and company names are trademarks of their respective holders; use of these trademarks does not imply any affiliation with or endorsement by their holders.
- Page 29 Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Safetrust Inc. | safetrust.com sales@safetrust.com...
-
Page 30: Support
Thank purchasing Safetrust SABRE Relay and/or SABRE Inline. Support If for any reason you need assistance with your installation, please contact your local Sales representative . Sincerely - The Safetrust Team Safetrust Inc. | safetrust.com sales@safetrust.com... - Page 31 www.safetrust.com/support...
