Optical eye for reading and configuration
Digital display showing consumption
Type number
(includes information on
meter size, overall length etc.)
Serial number and production year
Configuration of the adjustable parameters
Protection Class IP68 (Waterproof/submersible)
Software version
The sealing surface of
the threaded connection
must be clean and level.
ALWAYS use new gaskets
(PE or EPDM).
The adjacent piping must be parallel and
match the meter in- and outlet
flowIQ® 3101 - Encoded Output version
Optional customer label (not an option for Encoded Output version).
Bar code with serial number
Nominel meter size - Max. flow for
continous operation
Temperature range
FCC identification
flowIQ® 3101 - RF
& flowIQ® 3101 - Encoded Output
Installation guide
Advertisement
Related Manuals for Kamstrup flowIQ 3101
Summary of Contents for Kamstrup flowIQ 3101
- Page 1 Optical eye for reading and configuration Optional customer label (not an option for Encoded Output version). Digital display showing consumption Bar code with serial number Type number (includes information on meter size, overall length etc.) Nominel meter size - Max. flow for Serial number and production year continous operation Configuration of the adjustable parameters...
- Page 2 1.3 Installation angle of flowIQ® 3101 service the meter without breaking the seal. This means that all service, flowIQ® 3101 can be mounted at all angles and positions. Kamstrup 1.7 Info codes and display must be carried out at Kamstrup Headquarters.
