Kwumsy K3 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Warm Prompt：
1. Please ensure that the data cable is well connected with the computer and
products.
2. The starting power required for this product is 10W. Please ensure that the
computer, the type-C interface of the mobile phone or the USB interface can
provide 10W power (5V/2000mA).
3.Due to the poor performance in power supply, some mobile phones cannot be
connected with the product.
USER GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the K3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kwumsy K3

  • Page 1 USER GUIDE Warm Prompt： 1. Please ensure that the data cable is well connected with the computer and products. 2. The starting power required for this product is 10W. Please ensure that the computer, the type-C interface of the mobile phone or the USB interface can provide 10W power (5V/2000mA).
  • Page 2 50% and achieve efficient task processing. K3's screen can be freely adjusted to 0-90 degree display angle, and supports adjustment of brightness, contrast and other parameters settings, and is equipped with TYPE-C / USB3.0 / TF/SD / M2 B&M key / B key interfaces. You can achieve one-line connection display without expansion dock.

  • Page 3: Table Of Contents

    Contents of Instruction Product Attributes 1. Product host 2. Product accessories 3. Parameters Installation 1. Open support frame 2. Screen opening and storage 3. Hard disk installation Keyboard DIY 1.DIY key cap shaft body 2.Keyboard disassembly Product connection method 1. TYPE-C interface computer/mobile phone connection method 2.

  • Page 4: Product Attributes

    Product Attributes 1. Product host USB 3.0 TYPE-C POWER T-F / SD Kickstand Screen folding button Speaker Speaker System indicator lights Lock WIN Caps (WIN white light is always on, (white light is always on) (white light is always on) MAC green light is always on) 2.

  • Page 5: Installation

    Installation 1.Open support frame Two-level adjustable stand 2.Screen opening and storage 2.1 Please hold down the button to adjust the angle of the screen to the appropriate position, and then release the button to fix the screen angle. 2.2 In the process of opening and storing the screen,the screen angle locking button must be pressed,otherwise it will damage the screen and cause the lock to fail.

  • Page 6: Keyboard Diy

    Keyboard DIY 1.DIY key cap shaft body 1. Remove the key cap with a key puller 2. Use a professional shaft puller to pull out the switch body 3. Check the installation position of the switch to be replaced (note that the pins cannot be crooked) 4.

  • Page 7: Product Connection Method

    Product connection method 1.TYPE-C interface computer/mobile phone connection method Only a TYPE-C notebook/mobile phone with signal + power supply + video can achieve one-line communication. Note: The data line connected to the computer must be connected to the TYPE-C interface of the product to achieve video and data transmission.

  • Page 8: Audio Setting

    1.2 Select "switch on sound " in pop-up dialog box 1.3 Left click "turn on sound settings" and pop-up the box as provided,Here users can set about sound; Here users can set about sound 1. Master volume; 2. Select output device: (K3-R/speaker); 3. Device attributes. Sound output...

  • Page 9: Audio Settings Of Macos End

    2.1. Switch settings of MAC computer end sound output 2.2. Click computer's "settings" APP 2.3. Select "sound" in dialog box and pop-up as provided: Click "output", users can do settings about sound; Select output device: ( K3 / speaker )

  • Page 10: Display Setting

    Display setting 1.Windows 10 / Windows 11 Display Settings and Configuration 1.1 Right-click a blank area of the desktop. In the pop-up dialog box, select "Display Settings". Left click "Display Settings" to open the dialog settings box as shown: Sleep be�er Night light can help you get to sleep Select a display below to change the se�ngs for it.

  • Page 11: Macos 13 Ventura Display Settings

    Display setting 2.MacOS 13 Ventura Display Settings and Configuration 2.1 Enter the “System Preferences” menu 2.2 The user can now configure their displays to their liking. In this menu, the user can set the resolution and mirror/expand the display you want. 2.3 Arrange Displays To rearrange displays, drag them to the desired position.

  • Page 12: Touch Settings

    Touch settings Windows 7 System Touch Settings 1.Click the Start button → Click Control Panel → Choose Tablet PC Settings. Administrator Document Picture music Download Computer Connect Control panel Operation..2.The following text appears on the main screen. Touch this screen to identify it as the touchscreen If this is not the Tablet PC screen, press Enter to move to the next screen.

  • Page 13: Windows 10 / Windows 11 System Computer Touch Settings

    Touch settings Windows 10 / Windows 11 System Touch Settings 1.Click the Start Button → Search Open Control Panel → Choose Hardware and Sound → Click Tablet Settings. Administrator Documents Picture Music Download Computer Connect control panel Operation..2.Tablet PC settings → Click to display → Click to set...

  • Page 14: Mac System Computer Touch Setting

    Touch settings 3.The following text appears on the main screen. Tap this screen with a single finger to identify it as the touchscreen. If this is not the Tablet PC screen, press Enter to move to the next screen. To close the tool, press Esc. Press ENTER to go to the next screen Touch this screen to identify it as the touchscreen If this is not the Tablet PC screen, press Enter to move to the next screen.

  • Page 15: Osd Settings

    OSD Settings Note: 1.Pop up the OSD menu: Swipe down with two fingers in the bottom-right corner of the screen to pop up the OSD menu. 2.To exit the OSD menu: Swipe up with two fingers in the bottom-right corner of the screen to exit the OSD menu.

  • Page 16: Key Definition

    key definition 1.Keyboard key definition FN function key combination (hold FN） Windows combination keys Mac combination keys Fn+F1 My Computer Brightness- Fn+F2 Email Brightness+ Fn+F3 Windows Search Open Task Control Fn+F4 Browser Homepage Call out Siri Fn+F5 Multimedia Player Fn+F6 Play / Pause Fn+F7 Previous...

  • Page 17: Key Definition

    key definition key definition Red light when charging Blue Tap/Menu button/Confirm, light when connected and long press for 2 seconds to return Toggle up “Plus” Toggle down "Minus” key definition Tap to play Volume- Volume+ Note: When connecting to a MAC OS system, the computer's audio output must be from the computer's built-in sound card to ensure proper functioning.

  • Page 18: Driver Definition

    Driver definition 1.Driver installation 1.1 Download K3 driver from official website → Double-click to install K3 driver → Installation successful. UK driver US driver Note: In the driver interface, you can set the keyboard lighting, macro programming, language settings, driver updates, configuration layer settings, etc. If you need to log in to the...

  • Page 19: Storage And Use Requirements

    Storage and use requirements In order to ensure the normal use of this product and prevent accidents such as electric shock or fire, please read and understand all use requirements and operation procedures before using. Please strictly abide by the following requirements. 1.
