Page 1 Supernote Nomad User Manual V 3.20.29 Don't panic...
Page 2: Table Of Contents
Table of Contents Applicable Models ......................... 8 Chapter 1 Quick start ......................10 1.1 Power on and the initial settings ................10 1.2 Connect to Wi-Fi ...................... 11 1.3 Sign up and log in ..................... 12 Chapter 2 Gestures and toolbar ................... 15 2.1 Gestures ........................15 2.2 Top menu bar ......................
Page 3 3.9 Bluetooth ......................... 53 Chapter 4 Handwriting and Drawing ..................54 4.1 Create a new notebook .................... 54 4.2 Rename a notebook ....................56 4.3 Set a notebook cover ....................56 4.4 Change templates ....................59 4.5 Using layers ......................60 4.6 Using headings ......................
Page 4 5.1 Import documents ....................80 5.2 Change the fonts ...................... 82 5.3 Adjust screen contrast ....................83 5.4 PDF gesture zoom ....................84 5.5 PDF trimming ......................86 5.6 PDF export ....................... 87 5.7 Bookmarks and Table of Contents ................88 5.8 Annotation .......................
Page 5 Chapter 8 Convenient Features ..................105 8.1 Organize files ......................105 8.2 Protect files ......................109 8.3 Star tag ........................109 8.4 Browse & Access ....................111 8.5 Screen mirroring ....................112 8.6 Search ........................113 8.7 Quick access ......................115 8.8 Recent access ......................117 Chapter 9 Mailbox Function ....................117 9.1 Login ........................
Page 6 Chapter 15 FAQ and Troubleshooting ................155 Q：How to make custom image templates? ..............155 Q：How to import document customized fonts ............157 Q：How to get Supernote Partner APP? ................157 Q：What should I do when the device freezes or fails to boot? ........158...
Page 7 Q：How to eliminate afterimages on note pages or display screen? ......159 Copyright ........................... 159...
Page 8: Applicable Models
Applicable Models This manual will guide you to use Supernote, and the applicable model is Supernote A6 X2 Nomad Specifications   Supernote A6 X2 Nomad Resolution：1872*1404(300DPI) Storage：32GB(Expandable) RAM：4GB Battery：2700mAh Structures ...
Page 9  Supernote A6 X2 Nomad 1. Power on/off 2. USB port (type-C) 3. Battery charge indicator 4. E Ink Display 5. Sidebar 6. Magnetic strip 7. Pogo pin...
Page 10: Chapter 1 Quick Start
Quick start 1.1 Power on and the initial settings 1、 Hold the power button on the top right corner of device, until the Supernote logo appears If cannot turned on, the device might need to be charged (Please refer to FAQ:...
Page 11: Connect To Wi-Fi
(enter SSID, security and password) *Note：If the “ ” icon on the top menu bar turns black, it indicates your Supernote device has been successfully connected to a Wi-Fi network. Long press the “ Wi-Fi” icon in the top menu bar to access the “Wi-Fi”settings screen.
Page 12: Sign Up And Log In
1.3 Sign up and log in  Sign up 1、 Open the top menu bar Settings”  Tap “ Tap“ My account”  2、 Sign up  Tap “Sign up” to create an account by phone number or email address ...
Page 13 (The DMS location is not to be confused with Supernote Cloud server location. You need to select your Supernote Cloud server location before using Supernote Cloud synchronization) 3、 Set account password  Enter the password twice ...
Page 14  Tap“ My account”  Tap “Log out”  Reset password  Tap “Forgot password?”  Enter your account  Tap “Verify”...
Page 15: Chapter 2 Gestures And Toolbar
 Enter your new password twice  Tap “Reset” *Note：Log in to bind your Supernote device to your account. (Refer to "Register and log in supernote cloud" or " Quick log in on Mobile APP " to get more registration methods).
Page 16 Refresh the screen One-finger slide up on the left sidebar(Right-handed Mode); One-finger slide up on the right sidebar(Left -handed Mode). Activate the top menu bar One-finger swipe down from the top of the screen. Undo One-finger slide up on the left sidebar(Right-handed Mode). One-finger slide up on the right sidebar(left-handed Mode).
Page 17 Redo One-finger slide down on the left sidebar(Right-handed Mode); One-finger slide down on the right sidebar(Left-handed Mode). Activate the region eraser Two-finger press and hold the left sidebar(Right-handed Mode); Two-finger press and hold the right sidebar(left-handed Mode). Note:You can customize this gesture and use two fingers to press and hold the screen.
Page 18 Return to page before jumping One-finger swipe up from the top half of the screen. Show and hide the toolbar Two-finger double-tap the screen. Show and hide the page number bar One-finger double-tap the page number bar in blank.
Page 19: Top Menu Bar
Enable or disable Wi-Fi connection Wi-Fi-Off Bluetooth-On Enable or disable Bluetooth Bluetooth-Off Browse & Access-On Transfer files by the browser;Supernote and the Browse & Access-Off receiving device connected to the same Wi-Fi during transfer. Screen Mirroring-On Keep Supernote and the receiving device connected Screen Mirroring-Off to the same Wi-Fi during mirroring.
Page 20 in the /SCREENSHOT folder in PNG format Search Search files by file name, keyword or tag“ ” Settings Configure your settings...
Page 21: Toolbar
2.3 Toolbar 2.3.1 Introduce the toolbar...
Page 23 The following mainly introduces the basic tools used in standard notes. Other tools will be introduced in the description of the relevant functions. (Note: Illustrations for functions introduced in the user manual mainly use the left toolbar as an example.) Icon Name Description Back to“...
Page 24 or strokes to quickly erase them.) Erase all Allows you to erase all the handwriting on the current layer. White Grayscale colors Light grey Dark grey Black Lasso You can resize, rotate, move, copy (across pages as well), cut and delete handwriting you select with the lasso tool, which you can turn into headings, keywords, calendar events, To-Do tasks or links.
Page 25: Using The Toolbar
One-finger swipe Allow one-finger gesture to slide and turn pages page turning Two-finger swipe Allow two-finger gesture to slide and turn pages page turning One-finger Allow one-finger gesture turn page turning pages(Applies to Documents only) Disable page Disable page-turning gestures Turning gestures More Tap to display additional functions in notes or documents...
Page 26 2、 Tap " " or double tap the screen with two fingers again to display the fixed or floating toolbar *Note: You can choose to toggle on/off the full screen gesture and show/hide the “ ”button by going to Toolbar>More>Gesture Settings ...
Page 27 2、 Drag the floating toolbar to the top, bottom, left or right edge of the screen to switch to the fixed toolbar  Change fixed toolbar position  Drag the fixed toolbar to the top, bottom, left and right edge of the screen, or tap “...
Page 28  Tap " " or drag the vertical floating toolbar to the top or bottom edge of the screen until a dashed line indicating the horizontal floating toolbar appears before releasing it to switch (and vice versa)  Shorten the floating toolbar ...
Page 29: Page Number Bar
2.4 Page number bar  Introduction of page number bar Previous page Go to previous page Page number Click to enter the page number for page quick jump Next page Go to next page  Hide and display the page number bar 1、...
Page 30: Eraser Gesture
2、 Double tap with one finger again at the page number bar area to display it *Note: You can move the position of page number bar at the top or bottom screen “Toolbar>More>Preferences”；You can choose to toggle on/off the page number bar gesture by going “Toolbar>More>Gesture Settings”...
Page 31 1、 The use of gesture eraser  When the pen is raised ， Press and hold the screen with fingers simultaneously to activate the region eraser  Use the pen as eraser after activating gesture eraser  After erasing, move fingers off the screen ，...
Page 32 2、 Effective area of gesture eraser  Press two fingers at the same time in the screen area 220°-300° outside shadow area of the image, below the tilt of the pen activates gesture eraser(see right image).Otherwise ， it will be invalid.
Page 33: Chapter 3 Basic Settings
*Note: The gesture eraser is available in Note, Document, Calendar and Digest. Chapter 3 Basic settings 3.1 Language, date & time 1、 Swipe down from the top of the screen to open the top menu  Tap “ Settings”...
Page 34  Tap “Display & input”  Language 1、 Tap “Language” 2、 Select system language  Font 1、 Display & input  Tap “Font Size”...
Page 35 2、 Font size  Tap choose your favorable font size  Date & time 1、 Tap “Date & time” 2、 Network automatic acquisition time On/Off  “Network-provided time” (Default On)  “24-hour format”（Default On） 3、 Set time time zone manually ...
Page 36 tap the date  Tap “OK”  Tap the time  Adjust hr/min/sec  Tap “OK”...
Page 37: Stylus
4、 Date format setting  Tap “Date format” Select the format  Tap “ ”and return 3.2 Stylus  Calibration 1、 Swipe down from the top of the screen to open the top menu Settings”  Tap “  Tap “Display & input”...
Page 38 2、 Display & input  Tap “Stylus Settings”  On the “Stylus Settings” page, “Start Calibration” 3、 Tap the center of cross marks appear on the screen with your stylus...
Page 39 4、 Check the calibration results  Handwriting in the square area  Tap “OK” if you are satisfied with the accuracy, or tap “Recalibration” to calibrate again  LAMY Side Button 1、 Tap “LAMY Side Button”...
Page 40: Keyboard
2、 Choose to activate the region eraser or lasso by pressing and holding the side button 3.3 Keyboard 1、 Swipe down from the top of the screen to open the top menu bar Tap “ Settings”  Tap “Display & input” ...
Page 41 3、 Add a keyboard Tap “Add Keyboard”  Add” (The keyboard Tap “  can switch between up to 7 languages) 4、 Remove a keyboard Tap “ Remove” ...
Page 42: Screensaver
5、 Using the handwriting keyboard  On the Keyboard page, tap “Handwriting”  Select your frequently used handwriting recognition language 3.4 Screensaver 2、 Swipe down from the top of the screen to open the top menu bar Settings”  Tap “ ...
Page 43 4、 Customize a screen saver  Tap “More” 5、 Select a picture  Select the folder where the picture is located  Choose a picture you like...
Page 44 6、 Preview a screen saver  The preview image can be zoomed in/out and moved. Tap "Fill" and "Fit" to adjust the image  Tap “OK” 7、 After setting completes, the page goes to the custom Screen saver  The latest six screen savers will be displayed ...
Page 45: Low Power Consumption
screen saver file will not be deleted from device drive) *Note: Only PNG, JPG, JPEG, WEBP format picture available for customized screen saver. 3.5 Low power consumption The following settings can save power consumption of the device.  Set auto sleep time 1、...
Page 46: Synchronization
 Tap “No load shut down”and turn "ON" 3.6 Synchronization You can choose to use Supernote Cloud/Dropbox/Google Drive/Onedrive to sync files on your Supernote. 1、 Swipe down from the top of the screen to open the top menu bar ...
Page 47 2、 Choose the cloud service  Select Supernote Cloud  If you choose Supernote Cloud, you need to register and log in My Account in advance  Tap“Supernote Cloud”  Tap “ ” in the upper left corner of the folder to select...
Page 48  Tap“Security & Privacy”  Tap“Supernote Cloud Server Location”  Select the server location you need to switch to and tap “Change”  Select Dropbox or Google Drive (The following uses Dropbox as an example)  Tap “Authorize”...
Page 49  Open the following web page from PC browser https://bind2dropbox.supernote.com  For PC web browser  Input the random code appears on device  Click “get Dropbox authorization”  It will jump to the Dropbox website to proceed authorization  Input the Dropbox account ID and password ...
Page 50 (Due to the difference between Dropbox cloud storage and Supernote device storage space, this part of the configuration will be limited according to the selected folder size)  Swipe down from the top of the screen to open the top menu bar, tap "...
Page 51: Third Party Application
*Note: After selecting folders you want to sync to Dropbox or Google Drive and activating the sync function on the device, you will find a folder named “Supernote” automatically created on your Dropbox or Google Drive. This folder is the main synchronization folder for your Supernote device.
Page 52: Custom The Sidebar Menu
3、 Third Party Application Management  Tap “My apps”  Select the app to uninstall, tap “Uninstall” 3.8 Custom the sidebar menu 1、 Swipe down from the top of the screen to open the top menu bar  Tap “ Settings”...
Page 53: Bluetooth
2、 Tap “Customize slidebar” 3、 Select the apps you want to in the sidebar menu and sort them  Tap “ ” to add an app to the sidebar menu Tap “ ” to remove an app  from the sidebar menu ...
Page 54: Chapter 4 Handwriting And Drawing
2、 On″Bluetooth″ page  Turn Bluetooth ON  Tap“Scan”  Select the device to be paired, input pairing code if required *Note:When reading PDF, EPUB, CBZ, FB2 and XPS documents, you can turn pages using Bluetooth. Long press the “ Bluetooth”...
Page 55 2、 Or tap "Files" in the sidebar menu to access the "Files" page, then tap " Note" in any file. 3、 Enter a new name for the note or use the default name , Select a note type and tap “Create”.
Page 56: Rename A Notebook
4.2 Rename a notebook 1、 Tap “ More” on the toolbar Rename”  Tap “  Enter a new name in the popup window and tap “OK” * Note: File names cannot start and end with a space, nor can they contain special symbols, such as \/ *:?”<...
Page 57 page or image  Tap "Apply" 3、 Cover adjustment  Tap to select the note page or image  Tap again to enter the preview...
Page 58 *Note: Deleting the current cover will restore the default last page as the cover; you can select a image from my file as the cover; the cover supports only images in PNG, JPG, JPEG and WEBP formats.
Page 59: Change Templates
4.4 Change templates  Tap “ Templates”  Or select one or more pages on the “Pages” screen “ Templates”.  Built-in templates  Tap on the template to apply it  Image  Tap "Customization" or select from MyStyle folder ...
Page 60: Using Layers
 PDF  Tap "Customization" or select from MyStyle folder  Tap a PDF template to select one or more pages on the “Pages” screen Apply as  Tap “ Template ”(Note:Supports navigating between pages via the links embedded in the original PDF) Note: Support importing custom image and PDF templates, please refer to How to make a custom note template using images?
Page 61  Tap “ Layers”  The “Main Layer” is The “Main Layer” is mainly used handwriting words. It’s the only layer where headings and keywords for notes, create links and calendar events. (Please refer to “Using headings”, “Using Keywords”, “Using links”...
Page 62: Using Headings
2、 Adjust the layer sequence  Tap “ ” or “ ” to adjust order selected layer 3、 Rename layer  Tap " "  Enter a new name in the popup window and tap “OK” rename selected layer 4.6 Using headings 1、...
Page 63  Tap “ ”to select a heading pattern *Note: Handwriting lassoed heading area cannot be performed. 2、 Check headings Navigation  Tap “ Window” Headings”  Select “...
Page 64: Using Keywords
3、 Delete headings  Circle a heading with the lasso tool and tap “ ”.  Alternatively, Headings page, tap “ ”. * Note: The heading function is only available on main layer. 4.7 Using keywords The content written on the note or document page can be identified by circled keywords, so as to quickly search for the file pages related to the keywords.
Page 65  Enter a keyword using the keyboard and tap“Add”; select from recently used. 2、 Check keywords Navigation  Tap “ Window”  Select “ Keywords” 3、 Delete keywords  On the “Keywords” page, tap “ ”. *Note：Keywords only can be recognized in the main layer.
Page 66: Organize Handwriting
4.8 Organize handwriting 4.8.1 Copy/cut/paste handwriting 1、 Tap " Lasso"  Select handwriting content by drawing a circle around it with stylus. Copy”, or  Tap “ “ Cut”  After that, the lasso icon will switched “ Paste” 2、 Paste copied handwriting to the current note...
Page 67 jump “Pages”screen and select a target page.  Tap the screen with stylus nib to paste the note 3、 Paste copied handwriting to a different note Open a different note   Tap “ Paste”(skip this step if the paste icon is already selected) ...
Page 68: Move Handwriting
4.8.2 Move handwriting  Tap “ Lasso”, select handwriting content by drawing a circle around it with stylus.  Drag in lasso selected square region with pen 4.8.3 Zoom in/zoom out handwriting  Tap “ Lasso”, select handwriting content by drawing a circle around it with stylus.
Page 69: Rotate Handwriting
4.8.4 Rotate handwriting  Tap “ Lasso”, select handwriting content by drawing a circle around it with stylus.  Use pen tip on " " icon of lasso selected region to rotate the square angle. 4.9 Organize pages 4.9.1 Delete/insert note pages 1、...
Page 70: Copy/Move Note
2、 Insert a note page  Tap “ ”on the toolbar or navigate from the top function “Pages” screen.  Tap “ Insert Page Before” to insert a note page before the current page  Tap “ Insert Page After” to insert a note page after the current page 4.9.2...
Page 71 2、 Select note page(s) to copy or move  Tap “ Copy” or Move” “ 2、 “Copy to” “Move to”page  Stay in the current note or select another note  Tap to select a page to be moved or copied ...
Page 72: Cut/Copy Current Note Page
4.9.3 Cut/copy current note page 1、 Tap “ More” on the toolbar Cut Current  Tap “ Page”or “ Copy Current Page”  Select where to paste the cut or copied page in the current note or other notes Paste Page” to Tap “...
Page 73  Select a link style and target type (When creating a link from the More menu, you can choose how the link title to be displayed)  Select a link target...
Page 74 2、 Edit links  Circle a link with the lasso tool and tap “ ”. 3、 Delete links  Circle a link with the lasso tool and tap “ ”. 4、 Navigate using links  Tap the link to jump to the target location ...
Page 75: Using Real-Time Recognition Notes
once *Note: Links can only be created and tapped on the visible main layer. （You can only create links in notes for now.） 4.11 Using real-time recognition notes This type of note is marked with “ ”in “Files”and supports searching for recognized handwritten text, but doesn’t support layers.
Page 76 2、 View recognition results  Tap “ ” to view the recognition results  Tap “ ” re-recognize the current page Tap “ ”to view the  recognition progress in the backend 3、 Export recognition results Tap “ ” on the ...
Page 77 DOCX. Select formatting  4、 Search Handwriting Tap “ ”  search  recognized handwriting on the search page Note: The following actions can affect handwriting recognition efficiency: copying, pasting, cutting and zooming in/out of handwritten text; copying or moving pages from standard notes to real-time recognition notes.
Page 78: Return To Page Before Jumping
4.12 Return to page before jumping note/document  you’ve opened After you use headings,  stars, links, pages, table of contents, keywords, bookmarks, annotations, page numbers searches jump between pages/files  Tap “ ” or swipe up from the top half of the screen to return to the page before jumping ...
Page 79: Export And Share
*Note: The gesture for returning to page before jumping can turn on/off in “Toolbar>More>Gesture Settings.” 4.13 Export and share 1、 Tap “ Share/Export”...
Page 80: Chapter 5 Read, Digest & Annotation
Chapter 5 Read, Digest & Annotation 5.1 Import documents You can use USB 、Supernote Partner App or Cloud to import PDF and EPUB files to your Supernote device. Method 1: USB 1、 Connect Supernote device to PC with a USB cable...
Page 81 *Note：For iMac, a third party MTP application is required（Please refer to connection）. Method 2: Cloud（The following illustration uses Supernote Cloud as an example） 1、 Use the registered account to log in to Supernote Cloud on the computer's browser: https://cloud.supernote.com 2、 Select “Document”on the left side, click “Upload”,...
Page 82: Change The Fonts
3、 Connect your Supernote device to Wi-Fi and log in with your Cloud Account  Swipe down from the top of the screen to open the top menu bar, then tap Sync ” “  Wait for the completion of upload.
Page 83: Adjust Screen Contrast
2、 Select fonts, size, Row spacing and Margin Tap “Save” *Note: Support document customized font import (please refer to " How to import document customized fonts ") if you have added handwritten annotation(s) on the EPUB files, then the display settings cannot be changed.
Page 84: Pdf Gesture Zoom
5.4 PDF gesture zoom The pinch to zoom feature is only applicable to PDF, CBZ, XPS and DOC documents.  Open the document, pinch on the screen with two fingers to zoom in and out  When page size exceeds 100%, drag two fingers on the screen to move the page to view the...
Page 85  Click on the screen to zoom in " " and zoom out " " to zoom in and out of the page  Drag thumbnail window with finger to move the position of the thumbnail window within the page ...
Page 86: Pdf Trimming
5.5 PDF trimming The trimming feature only applies to PDF,CBZ and XPS documents. 1、 Tap “ Trim” 2、 Auto-trimming effect will be displayed on the page “Restore”,  border of the page will recovered, While Actual size will change to Adjust Adjust manually ...
Page 87: Pdf Export
trimming 5.6 PDF export This function only applies to PDF files. Export"  Tap "  Select handwriting type when exporting as PDF file.  Export choose handwriting style and handwriting color  Export customized to select the page number...
Page 88: Bookmarks And Table Of Contents
5.7 Bookmarks and Table of Contents 1、 Bookmark  Tap " Add Bookmark "  In the“Bookmark Added”pop-up box, tap Done or Remove as soon as you set the bookmark name.  After setting bookmark, " Remove Bookmark", to Remove the bookmark of the current page 2、...
Page 89 3、 Bookmark change name and delete Tap “ Contents”,  Bookmarks” or “ “ Annotations” to switch views  Tap “ Bookmarks” to view the bookmarks you have added Select the bookmark,  tap " ", enter a new bookmark name, then tap "Done"...
Page 90: Annotation
5.8 Annotation 1、 Write annotations  Open a document and you can start to annotate it with notes or marks. 2、 Delete annotations on the document pages  Tap “ Navigation Window” Annotation”to  Tap“ view all the pages with annotations ...
Page 91: Digest And Annotation
5.9 Digest and annotation  Digest  Draw “[“ and “]” in one stroke around text.  Or tap “ ”to select text, and then tap “ ” to create a digest. (This only applies to PDFs.)  Once created, a digest is marked with a “...
Page 92  View digests and annotations In the sidebar menu,  tap “Digest”to open the digest list  Tap the document name to view all the digests annotations associated with document  Tap “Show comments only” filter annotated digests. （Digests and annotations are sorted by file names）...
Page 93: Highlights And Comments
 Export digests and annotations  Select the digests you need to export and tap “ Export” on the top function bar *Note：Digests and annotations are only available for EPUB files and PDF texts. The digest symbols“ ” “ ” for annotations can be displayed or hidden in “Document toolbar > Preferred settings”.
Page 94  Comments  Tap “ ”to select text or tap a highlight you have created. Tap “ ”to open the  comment box to enter your understanding or thought about highlight.  View highlights and comments  Tap “ Navigation Window”.
Page 95: Chapter 6 Txt
 After tapping highlighted text, “ ”. Navigation  Window, long press a highlight to bring up the top function bar, select the highlight(s) you want to delete, and then tap “ Delete”. *Note: The default color for exported highlights is yellow. Chapter 6 ...
Page 96: Chapter 7 Word
 Scroll up and down to browse through content  Tap “ ”and “ ”to jump to the bottom and top of the TXT file Note: Using small TXT files that contain no more than 100,000 words is recommended. Chapter 7 Word 7.1 New Word file Tap “...
Page 97: Browse Mode
7.2 Browse Mode  Tap the page number area to display or hide the thumbnails  Tap on a thumbnail on the right side to jump to a specific target page  Tap the left/right arrows in the page number area or simply swipe up or down on the screen to turn pages...
Page 98: Pinch To Zoom
7.3 Pinch to zoom  Use two fingers on the screen to zoom in and out 7.4 Repage view  You can switch to the Reflow View to view or edit Word as needed.  Tap “ ” to enter the reflow view and use the pinch to zoom feature to rearrange...
Page 99: Editing
7.5 Editing  Keyboard mode for editing  Tap the area you want to edit to bring up the keyboard  Enter text using the keyboard  Handwriting mode editing...
Page 100: Proofreader's Marks
 Tap “ Handwriting Mode”  After handwriting text, tap “ ” to convert it to text.  Proofread and edit text handwriting proofreader’s marks  Tap “ ” to save the changes you made to the document. 7.6 Proofreader's marks The following handwritten proofreaders’...
Page 101: Delete
7.6.1 Delete stylus draw  " " characters spaces to be deleted, it will be automatically recognized as a delete signal, and the selected content will be deleted. 7.6.2 Line break Use stylus to draw " "  from top-down between characters or spaces to start a new line, it will automatically...
Page 102: Transpose
7.6.3 Transpose stylus draw  " " on the characters you want to transpose. It will be automatically recognized as a transpose symbol, selected characters will transposed. 7.6.4 Insert Handwritten Insert content between  characters stylus draw  “ ” between characters insert...
Page 103 screen, “ ”to convert it to text. Draw a line across  insert mark “ ” to cancel the inserted content  Additional ways to insert content Simply handwrite the  content you need to insert at the end of a paragraph “...
Page 104: Insert Space
Handwrite the content  you need to insert in a new line “ ”to  automatically convert it to text in a new line. 7.6.5 Insert space  Insert space by space symbol Draw “ ”mark  with stylus between words that need to be inserted into space to be recognized...
Page 105: Chapter 8 Convenient Features
Chapter 8 Convenient Features 8.1 Organize files You can organize (Rename/copy/move/delete/lock) all your files.  Create a new folder 1、 In the sidebar menu, tap “Files” to access any file; if you have opened a note/document, “ ”to go back to “Files” ...
Page 106 1、 In file management page  Long press the file  Select the files or folders to be moved or copied (Multiple -Choice supported)  Tap “Move”or “Copy” 2、 On Move to /Copy to page  Select the folder to move to/Copy to , tap “Ok”...
Page 107 1、 In file management page Long press the file or  folder Select the file or folder  to be renamed (Only single-choice supported) Tap “Rename”  2、 Rename Input the new name of  the folder and tap “OK” * Note: File names cannot start and end with a space, nor can they contain special symbols, such as \/ *:?”<...
Page 108 descending of size/name/ time View files or folders  1、 In file management page Tap “ ”, “ ” or  “ ” to switch file display mode “ ” is list mode  “ ” is thumbnail list  mode “...
Page 109: Protect Files
*Note: The file password must be set for the first use of "Lock", and the file password can be turned on and off in "Settings>Security & Privacy". File protection is only valid for files on the Supernote device in use, and it is invalid on other Supernote devices and external devices.
Page 110 2、 View pages with the " " Tap “ Navigation  Window” Tap " Stars" to view  pages with this tag 3、 Erase pages with the " " tag Select and long press a  page Select the pages with the ...
Page 111: Browse & Access
On the receiving device,  click “ ” to upload files, single-click filename to download the corresponding file and click “ ” to refresh the webpage. *Note: Keep Supernote and the receiving device connected to the same Wi-Fi during transfer.
Page 112: Screen Mirroring
” and “ ” to rotate right and left. Note ： Keep Supernote and the receiving device connected to the same Wi-Fi during mirroring. Hover the pen up to 5mm above the Supernote screen to display a laser pointer circle effect.
Page 113: Search
8.6 Search Open the top menu bar, tap “ Search”  Search for files  Tap a file format and tap “ ”.  Or enter the file name and tap “ ”.  Search for keywords...
Page 114  Switch the search target to Keyword.  Tap “ ” directly to see the search results that contain keywords have added.  Or enter a keyword, and tap “ ”.  Search results for related files or pages per input keyword ...
Page 115: Quick Access
specific files that contain stars.  Search for handwritten text  Switch the search target to Handwriting.  Enter recognized handwritten text from real-time recognition notes.  Tap “ ” 8.7 Quick access You can add 8 specified pages, notes/documents, or folders that need to be opened quickly to the quick access list in the sidebar menu 1、...
Page 116 tapping the “Add”button *Note: When open “Current Note/Document” via Quick Access, it will open to the last viewed page by default.  Folders  Tap“Files”  Select a single folder on the file editing page Add”  Tap “ 2、 Open items in Quick Access ...
Page 117: Recent Access
 Or long press a Quick Access item sidebar menu, and tap Remove”. “ 4、 Reorder items in Quick Access  Long press Quick Access item sidebar menu.  Tap “ ”and “ ”to adjust its order in the Quick Access section. 8.8 Recent access In the sidebar menu, tap the“Recent”tag.
Page 118: Login
9.1 Login  Log in to Gmail  Tap “Mail” in the sidebar menu  Select "Gmail" to enter the authorization page.
Page 119  Use QR code scan or input website link  Input Random code Sign in with Google  Tap " " *Note: The device only supports IMAP protocol. Please ensure your Gmail account has IMAP service enabled.  Log in to Microsoft Exchange or Outlook/Hotmail/Live ...
Page 120  Log in to Other Emails 1、 Login  Select “Other (IMAP)”  Enter your email address and password  You choose remember password, then tap "Log in"  Please check server setting if login failed...
Page 121 2、 Mailbox server set up  Tap “Manual Settings”  Setting per content (IMAP etc.) request of your mail server  Tap “Log in” (Please set up this part according your mailbox server requirements)
Page 122: Settings
*Note: Click "Have trouble logging in?" to check how to obtain authorization code  Multi-mail account login Add account"  Tap "  On the “Add Account” page, select an email account to log in to *Note: The mailbox supports max.
Page 123  Set the number of emails to sync  Tap " Settings"  Enter the number of emails you want to sync for each folder (Up to 99 emails)  Customized Signature Setting  In the signature box, enter your email signature using...
Page 124: Compose
9.3 Compose 1、 Tap " Compose "  By handwriting  By keyboard input 2、 File attachment  Tap " "  Select the file you want send attachment “Add”. 3、 Enter recipient address or relevant information  Tap“ ” *Note: Email attachments have restrictions on the size.
Page 125: Inbox
9.4 Inbox 1、 Sync emails  Tap “ ” manually sync emails. 2、 Check emails  Swipe up and down to view email details  Support zoom in/out for checking email details fingers.
Page 126: Delete Local Emails
3、 Save attachment  Tap " "  Tap "Save" in the attachment list  As default, the file is saved to the relevant email account under the "INBOX" folder 9.5 Delete Local emails  Long press to select the mail to be deleted ...
Page 127: Chapter 10 Calendar Function
Chapter 10 Calendar function In the sidebar menu, tap “Calendar”. If it is the first time opening the Calendar, the default view will be the “Monthly View”. 10.1 Manage account  Tap " "  Ta" "to enter authorization page ...
Page 128  After authorization completed successfully, choose enable Auto-sync tap“ ”to manually sync your calendar. * Note: If Auto-sync is enabled, the calendar will be synced automatically every time a calendar event is created, revised or deleted.
Page 129: Settings
10.2 Settings  Tap " "  Tap the date square or " "  Select the start day of the week  Close side column by tapping screen once after completion settings *Note：Please delete ALL handwritings before set up the date. 10.3 Switch view ...
Page 130: Select The Date
10.4 Select the date  Tap Year/Month on top of display  Select "Year"and "Month"  Tap " " or slide the calendar to switch different month  Tap " Today "to return 10.5 Using events 1、 Create  Tap " "...
Page 131  Daily calendar view   Tap the time slot to input  Create event corresponding the time slot  Tap "OK" 2、 Check   In monthly or weekly view  Select date...
Page 132  Tap date square bottom-right corner to check all events of the  Click single event to  check details  In Daily calendar view   Tap the date to check all events of the day...
Page 133 3、 Edit, Delete   Edit  Tap " "  Open the event page ， Re-edit  Tap "OK"  Delete  Tap“ ” in event list  box or Event details  Tap “Delete” in event edit page...
Page 135: View Notes
10.6 View notes  In weekly or monthly view  Tap "View Notes" in the lower left block to open the note list and browse all notes of the day 10.7 Recognize titles for event  On a note page, tap ...
Page 136: Chapter 11 Basic Functions
* Note: Event title recognition is only valid on the “Main Layer”. Chapter 11 Basic functions 11.1 USB connection You can use USB cable to connect your Supernote device and PC to charge device, organize and transfer files. Use USB cable to connect your Supernote device to PC.
Page 137: Wake Up From Sleep Mode
 Find folder representing the OTG U drive in the root directory of Supernote, click to enter the U drive, you are able to view and organize files in the U drive *Note: 1. When opening the OTG U drive file, please click "...
Page 138  In standby state, the device will automatically enter hibernate mode and display screensaver page according to the sleep time set by the user (please refer to screensaver, power consumption setting In active state, press the  power button to enter hibernate mode ...
Page 139: Reboot/Update
11.4 Reboot/update 1、 Open the top menu bar Settings”  Tap “  Tap “System”  Reboot 2、 Tap “Restart” from the system reboot  Update  Tap “Check”  It will start to download firmware if there is a new release ...
Page 140: Reset
11.5 Reset 2、 Open the top menu bar Settings”  Tap “  Tap “System”  Tap“Factory reset” 3、 Factory initialization  Tap “Reset Now” *Note: Please back up your files before reset for Reset will erase all data and account information you have added in the device.
Page 141: Power Off/Shutdown
11.6 Power off/Shutdown 1、Graceful shutdown  Long press the power button (>5 seconds),Tap “Power Off” *Note：The device is powered off after 10 seconds when you tap “Power Off” 2、 Forced shutdown  Long press the power button (>5 seconds) ， then the device shut down immediately...
Page 142: Chapter 12 Privacy And Security
12.1 Privacy User Experience Project only upload the exception log, which can help to diagnose and improve Supernote device. Your files on the device will not been uploaded. 12.1.1 User Experience Project ON/ Off 1、 Open the top menu bar ...
Page 143: Screen-Lock Password
 After setting the password, you need to enter it to unlock when wake-up *Note：You are able to unlock the screen via log in Supernote Account if you forget the password (Please refer to Sign up and log in from...
Page 144 2、 Retrieve the screen-lock password  Tap “Forget Password”  The device will try to connect to Wi-Fi After successfully  connected, the device will send a 6-digit verification code to your registered mobile phone or email address  Type in the verification code...
Page 145: File Password
 After successful unlock, it will jump to setting screen-lock password page, where you can reset the password *Note: If you have not registered an Supernote account, please recall your password and try different combinations first; if you still cannot input correct password, please contact Supernote Customer Service.
Page 146  After the successful setting, you need to enter the file password when opening the locked file and related contents *Note： If the password is forgotten, you can unlock via the registered Supernote ID (Please refer to Sign up and log in from...
Page 147 2、 Retrieve lock file password  Open the locked file password input box in "Files"  Or go to the "Disable file password" and "Change File Password" column  Tap “Forget Password”  The device will try to connect to Wi-Fi ...
Page 148  Type in the verification code you just received  After unlocking successfully, the page enters the setting file password page, which can be reset 2、 Disable file password  Open the top menu bar ， Settings ” ， Tap Tap “...
Page 149: Chapter 13 Cloud
Chapter 13 Cloud Supernote cloud is bound to your Supernote device with sole account. If you have registered the cloud service but not log in on Supernote device, your cloud service is still not activated. 13.1 Register and log in 1、...
Page 150 2、 Email and mobile phone number are available for registration  Enter email address mobile phone number  Set a user name  Click “Get Code” 3、 Enter graphic verification code and click “Sure”...
Page 151: Cloud Service
 Enter the password twice  Tick User agreement  Click “Register” *Note ： When registration from PC completes, you have to log in from the Supernote device to activate your cloud service. 13.2 Cloud service Cloud provides the following main services.
Page 153: Chapter 14 Safety
Away from Strong Magnetic and Keep Dry Electrostatic Field  Supernote Pen is only used for Supernote device with FeelWrite film Please do not use on other devices to avoid scratch or damage  Screen is fragile, keep away from extrusion, bump, drop sharps ...
Page 154  The Company shall not be liable for damage or deletion of in-flight data due to personal abnormal operation or other unexpected circumstances,neither any indirect loss...
Page 155: Chapter 15 Faq And Troubleshooting
*Note: In order to show better effect, we suggest not to apply large grey area in this image, no optionally change of image or rename of file. 4. Copy and paste the saved image to /MyStyle directory of Supernote disk. The custom templates are to be found from the templates list of Supernote ...
Page 156 PNG format to relevant folder 4 、 Copy and paste the saved image to “MyStyle” directory of U disk. The custom templates are to be found from the templates list of Supernote Method 2 ： You can sketch directly on Superote device.
Page 157: Q：how To Import Document Customized Fonts
*Note: You can also create a "fonts" folder under Document on Supernote cloud or Supernote Partner APP, and import fonts to Supernote device by synchronization. Q：How to get Supernote Partner APP? A: You can search Supernote Partner Google Play and App Store, or download it directly from https://supernote.com ...
Page 158: Q：what Should I Do When The Device Freezes Or Fails To Boot
 Connect the device to USB charger to charge  Waiting for few minutes, you should be able to see Supernote logo on screen or boot progress bar of startup, and you can see the LED flash on the top menu bar *Note: If you do not see the boot screen within half an hour, please carefully check the socket of device, the USB cable and the power adapter.
Page 159 8 seconds again until the SUPERNOTE logo appears *Note: Forced rebooting the device will not erase the data you saved. If above methods cannot help to solve your problem, please contact Supernote Customer Service. Q：How to eliminate afterimages on note pages or display screen? A ：...

Supernote A6 X2 Nomad User Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Supernote A6 X2 Nomad

Summary of Contents for Supernote A6 X2 Nomad
