Getting Started Getting Started Check the Package Content The IPEVO SOLO Phone package includes the following items: • SOLO phone • SOLO handset • AC/DC power adaptor • Ethernet cable • User Manual SOLO_ュ^、蟐ゥァ・indd 2007/9/7 、U、ネ 03:39:58...
Page 3
Getting Started Your SOLO Phone: Buttons, Functions, and Locations DC IN SOLO_ュ^、蟐ゥァ・indd 2007/9/7 、U、ネ 03:39:58...
Page 4
Getting Started 15 16 Location Buttons Functions/Press to LED Light • Blue light when phone is in standby mode. • Green light when a call is in progress. • Blinks if you have missed calls or voicemails. Display Soft Buttons Press to select options shown immediately above these buttons on the display...
Page 5
Getting Started Navigation/Confirm Buttons Press to select highlighted items. Press to move through the menus. In standby mode, press these buttons to go to a shortcuts menu. • Press to go to the Skype Status menu. • Press to go to the Contacts menu. •...
Page 6
Getting Started Redial Press to go to the Outgoing calls menu. Select from the lists and dial. Mute Press to turn-off the microphone. To resume the conversation press again. Speaker Press to activate hands-free speakerphone mode. Press again to return to handset mode. Volume Press to increase or press...
Page 7
Getting Started Your SOLO Display Icons Item Meaning New voice calls New missed calls New request waiting Skype network alert Skype status Offline online Skype me Away Not available Do not disturb...
Getting Started Access Menu Functions Press [Left] Press [Right] button to go left. button to go right. Press [Left Soft] button to <Select>. Or press [Right soft] Press the [Left button to go back one level in soft] button to go the menu.
Page 9
Getting Started From the standby display, press the [Left soft] button to go to the Skype’s menu. • Press the directional buttons to move through the menus. • Press the [Left soft] button to select the highlighted item or press the [Right soft] button to go back on level in •...
Connect the handset to the Phone handset jack located at the bottom of the Phone. Step 2: Use the provided Ethernet cable to connect the Phone Ethernet jack located at the back of the Phone to your ADSL or Cable modem. ADSL/Cable Modem DC IN SOLO 15 16 SOLO_ュ^、蟐ゥァ・indd 2007/9/7 、U、ネ 03:40:03...
Page 11
Installation Step 3: Connect the power adapter to the SOLO located at the bottom of the Phone. Connect the power adapter to the electrical outlet. SOLO ADSL/Cable Modem 15 16 DC IN Note: The default network settings of SOLO is DHCP which is used in most cases.
Installation Setting Up your SOLO Phone After you connect the power adapter to the electrical outlet, you are prompted to enter the basic settings for SOLO. Select Language Note: If you want to change the language Use [Up] or [Down] button setting later, please go to the Menu to scroll to a language.
Page 13
Installation Agreement Choose your Country and Area Code Read and accept the Skype Agreement. Use [Up] or [Down] button Enter area code and press to scroll to a country. <OK> to enter next menus. Press <Select> to select the highlighted item and enter next menus.
Installation Time and Date Press <Clear> to make corrections. Press <OK> to enter next menus. Note: If you want to change the settings later, please go to the MenuSettings Time and date to change the time Use numerical keys to Enter the date and press and date.
Installation Press to shift between capital, lower-case letter and numbers. Signing In to Skype After you have successfully set up the Phone, you can sign in Skype. You can use an existing Skype account or create a new account. Create a new skype account If you want the phone to automatically sign Use [down] button to scroll to...
Installation Entering Text and Numbers You will be asked to enter text for some features such as Skype name, password, Add Contacts, etc. Changing the text input mode Text input mode indicator: abc, ABC, 123 Press to shift between capital, lower-case letters and numbers SOLO_ュ^、蟐ゥァ・indd 2007/9/7...
Installation Entering text Press repeatedly until the desired character appears on the screen. abc mode. Press repeatedly until the desired character appears on the screen. SOLO_ュ^、蟐ゥァ・indd 2007/9/7 、U、ネ 03:40:11...
Page 18
Installation Using ABC, abc Mode Characters in order displayed Upper Case Lower Case SOLO_ュ^、蟐ゥァ・indd 2007/9/7 、U、ネ 03:40:11...
Page 19
Installation Insert special characters abc mode. Press [OK] to insert a symbol. Special Characters Table ‘ “ & < > ₤ € ¥ ° Press [#] button to § ¿ show the <Insert Press [Up] [Down] [Left] ‘ symbol> menu. [Right] to scroll to a symbol.
Skype Calling Skype Calling Skype features Skype Call Call other people on Skype for free. SkypeOut™ SkypeOut™ allows you to place calls to regular telephones (landlines or mobiles) all over the world. To SkypeOut™ you’ll need to purchase some Skype Credit. SkypeIn™...
Skype Calling Make a Skype call Press <Contacts> to enter. Use [Up] or [Down] button to scroll to a contact. Press <Options> to enter. Or press [Call] to start a call. Press <Select> to enter. Use [Up] or [Down] button to scroll to a number.
Skype Calling Make a SkypeOut call SkypeOut numbers must be entered in the following format: “00” + “country code” + “area code” + “number” You need to have Skype Credit The call timer displays the talk to make SkypeOut calls. time of your call.
Page 23
Skype Calling You need to have Skype Credit before making a SkypeOut call. If you have set up your country and area code, Please go to http://www.skype.com/helloagain.html to purchase you don’t have to dial the country and area Skype Credit. code while making a local SkypeOut call.
Skype Calling Answering a call When you receive a call, the phone rings and displays the incoming call image. Simply lift up the handset or press to answer the call. Rejecting a Skype call Press to reject the call. Redialing the last number Use [Up] or [Down] button to scroll to a number.
Page 25
Skype Calling Placing a call on hold/Retrieving During a call, you can put the call on hold to answer the second call. Press <Options> to open <Options> menus. Press <Select> to hold the call. To resume the call, please <Options>. Press <Select>...
Skype Calling Call diverting You can forward Skype calls to a landline or mobile phone number when you are away from your home or office. Press <Menu> to open Use [Up] or [Down] button <Menu> menus. to scroll to <Call divert>. Use [Right] button to Press <Select>...
Skype Calling Speed dials Assign speed dials SOLO provide three speed dial buttons for 3 of your most frequently dialed numbers. To assign speed dial numbers follows steps shown as below. Use [Up] or [Down] button Use [Up] or [Down] button to scroll to <Speed dials>.
Skype Calling Dialing speed dial numbers In standby mode, press to call, Viewing missed calls If you have missed calls, the screen displays how many calls you have missed. Press <View> to open <Missed calls> menus. Use [Up] or [Down] button to scroll to a missed call item.
Skype Calling Skype Contacts Searching & Add a contact To add a Skype or SkypeOut Contact, follow these steps: Press <Menu> Use [Left] and [Up] buttons Enter the name Use [Up] or [Down] button to open <Menu> to scroll to <Search>. and press <OK>...
The new contact is added to your contact list. Skype will send a request to the contact for authorization. Reset to default settings The default settings are the original factory settings of your phone. If you want to reset your SOLO to the default factory settings, 1.
The Warranty is valid solely on the condition that the Product is shipped to IPEVO within the warranty period. In the event of a fault or defect in the Product, it must be shipped back to IPEVO. Products are repaired or exchanged at IPEVO’s own discretion.
Page 32
International IPEVO Inc. IPEVO CORP. 2860 Zanker Road, Suite 100, 12F, #105, Section 2, Tun-hwa S. Road, San Jose, CA 95134 Taipei, 106, Taiwan Tel 1-877-2-myIPEVO Tel 886-02-5550-8686 Service mail: cs@ipevo.com Service mail: service@ipevo.com http://www.ipevo.com http://www.ipevo.com.tw SOLO_ュ^、蟐ゥァ・indd 2007/9/7 、U、ネ 03:40:19...
