PELICAN
Model: WR900
Long Range Dual Band Wireless Repeater
Installation Guide
!
PELICAN
Before You Start
Before beginning installation, thoroughly review all instructions to prevent
any potential issues. This repeater is specifically designed to bridge Pelican
wireless mesh networks across extended wireless gaps.
This device only requires a power connection. It's crucial to consider
mounting orientation and location carefully to maximize wireless signal
strength and quality.
Network Connection
Upon powering on, the repeater will seamlessly connect to an existing Pelican
wireless mesh network without the need for additional installation steps.
To verify the repeater's connection status, consult the lights located at the
bottom of the device or access the Pelican Connect app and navigate to Admin
> Network Map to locate and confirm the repeater's connection within the
network.
Advertisement
Table of Contents
Summary of Contents for Pelican WR900 Series
- Page 1 To verify the repeater's connection status, consult the lights located at the bottom of the device or access the Pelican Connect app and navigate to Admin > Network Map to locate and confirm the repeater's connection within the...
-
Page 2: Installation Location
Next to another Pelican Repeater or Gateway. On a desk or any other flat surface to ensure optimal signal propagation and minimize potential obstructions. On rooftops or anywhere outside unless advises otherwise by Pelican Technical Support. DO INSTALL REPEATER: Approximately halfway between the existing Pelican mesh network and the devices unable to connect. - Page 3 2.4 Ghz Antenna MOUNT REPEATER 900 Mhz ON WALL WITH ANTENNA Antenna FACING UPWARDS FOR BEST WIRELESS STRENGTH AND QUALITY. PELICAN DO NOT INSTALL REPEATER ON A SHELF, TABLE OR ON ANY HORIZONTAL SURFACES 5V DC / 2A 120V Outlet...
- Page 4 Mounting DO NOT INSTALL REPEATER ON A TABLETOP SURFACE SUCH AS A DESK, CABINET OR NETWORKING RACK, AS THIS WILL DRASTICALLY REDUCE WIRELESS DISTANCE AND QUALITY. ALWAYS MOUNT THE REPEATER WITH THE LOGO FACING UPWARDS AND LEGIBLE FOR OPTIMIZED 900 MHz WIRELESS PERFORMANCE. DIRECT THE ANTENNA UPWARDS AND AWAY FROM THE GROUND TO MAXIMIZE 2.4 GHz WIRELESS DISTANCE AND QUALITY.
-
Page 5: Indicator Lights
(2) SIGNAL indicates the wireless signal detection and quality of the repeater. Long Range Dual Band Wireless Repeater USB-C POWER STATUS SIGNAL STATUS SIGNAL OFF : NO POWER OFF : UNABLE TO FIND A PELICAN WIRELESS NETWORK FLASH FLASH FLASH FLASH FLASH FAST BLINKS : POWERING UP FLASH 1 SECOND... -
Page 6: Troubleshooting
If the repeater is still unable to find the Pelican wireless network, it might be in a bad location or too far from the network to connect. Try moving the repeater to a new location. - Page 7 3. Ensure there are no electronic devices like network routers, switches, backup generators, or other wireless hubs near the Pelican repeater, as these can cause interference. 4. Ensure there are no metal or thick concrete walls or enclosures around the repeater, as these materials can block or significantly reduce the repeater's...
- Page 8 PELICAN Website: www.pelicanwireless.com Pelican Wireless Systems. All Rights Reserved. Phone: 888.512.0490 WR900 37-0545 REV01...
