Customers and users of OCEASOFT products are responsible for making sure that the product is fit for the intended usage. Do not open the product casing and do not disassemble or modify internal components in any manner. OCEASOFT products do not contain any internal components that require user intervention or repair.
Page 3
Please contact us for more information. 1.1.10 Disclaimer and limitation of liability OCEASOFT assumes no responsibility for any loss or claims by third parties which may arise through the use of this product. This document is non-contractual and subject to change without notice.
Detailed configuration instructions and software settings are provided in the documentation for Cobalt L3 companion software applications: CobaltSet, an OCEASOFT mobile app for iOS and Android used to setup Cobalt L3 modules CobaltView, an OCEASOFT web application offering a complete sensor monitoring interface This document focuses on the physical aspects of the module and compatible sensors.
Introduction Main module features Cobalt L3 wireless temperature and humidity datalogging module with LCD Unlimited data storage on OCEACloud; up to 4,000 readings in module memory LoRaWAN™ wireless connectivity Bluetooth Smart® wireless connectivity Various supported temperature and humidity ranges (details in next section) ...
Introduction Available sensor types Cobalt L3 models are available with several different sensor options, as described below: Sensor type Ranges No. sensors Cable Application Ambient Internal digital 0°C to +50°C temperature temperature sensor measurement Freezers, -40°C to +80°C or refrigerators, and External digital -40°C to +120°C...
Please read CobaltView™ and CobaltSet™ User Manuals carefully. Product description Cobalt L3 modules are available either with internal temperature sensors, or external sensors as shown below. The modules themselves are identical in both cases (other than the external sensor cable).
Getting started Typical installation A typical installation therefore involves one or more Cobalt L3 modules and a LoRaWAN™ receiver. Long-range wireless connectivity enables Cobalt L3 modules to be placed nearly anywhere in your building or site. In cases where the signal is not strong enough, a second LoRaWAN receiver may be required.
This informal site testing procedure will enable you to verify that all your modules are communicating correctly. Excessive obstruction, interference, or harsh conditions can affect wireless performance. Please contact OCEASOFT technical support for specific cases if you have a module that is having difficulty reaching the receiver. OCEASOFT LoRaWan enabled solution...
Getting started Requirements and recommendations The OCEASOFT L3 receiver runs continuously, 24/7/365, and should be connected to an Uninterruptible Power Supply (UPS) that protects against power surges and provides power to back up the receiver. The CobaltView web application will show an alert clearly on the computer screen if a module is not communicating.
Preparing mounting kit with a magnet (optional) Your Cobalt L3 module includes a plastic holder so you can mount the device easily on various surfaces. In addition to the provided screws, you will also find a magnetic pad with adhesive backing that you can attach to the holder and then adhere the holder to metal surfaces easily.
CobaltView web application (with a voucher to authorize Cloud access). This section focuses on the physical aspects of the Cobalt L3 module. This image shows a Cobalt L3 module with an external Pt100 sensor, connected via OCEASOFT Smart Sensor technology.
Page 16
External Smart Sensors (Note: if you change the sensor on a functioning Cobalt L3 module, you must reconfigure the module on the server-side using the CobaltView Web application.) Insert the cable from your module into the keyed plug on the OCEASOFT Smart Sensor connector.
When possible, route the sensor through the same access port used by the unit control sensor or an accessory port, such as that shown below in Figure 6. When routing the Pt100 sensor through the same port used by the control sensor, OCEASOFT recommends installing the sensor only after the freezer has reached a thawed state.
Page 18
Make sure you attach the sensor using the provided cable-ties and reseal any openings you may have unsealed to insert the sensor using permagum sealant. Figure 6 – Sample PT100 (-100°C to +150°C) for ULT freezer OCEASOFT LoRaWan enabled solution Cobalt L3 module Page 18...
Page 19
Pt100 sensors for LN2/cryogenic tanks must be mounted, when applicable, in close proximity to the unit display sensor. To avoid temperature measurement disappearances, OCEASOFT recommends mounting the sensor at the same height as the display sensor. As an example, some freezers have an access panel on the back of the unit in which you may route the sensor cable up the back wall.
CobaltSet mobile application for upload them to the module. Figure 8 – Cobalt L3 module with external digital sensor (optional cable lengths) Depending on the design of the space to be monitored, you may be able to pass the sensor through an access port or opening.
Figure 9 – Cobalt L3 module with external digital sensor (optional cable lengths) Placing the sensor 1. If you have a Cobalt module with one or more external sensors, the best solution is to use the access port or opening to insert the sensor(s).
Page 22
Cobalt module as described in section 3.6 Placing your Cobalt module for best wireless performance. For example: Figure 11 – Cobalt module mounted on the refrigerator door 7. Attach or coil the excess cable neatly. OCEASOFT LoRaWan enabled solution Cobalt L3 module Page 22...
Internal sensor Internal sensor Cobalt L3 modules with integrated temperature do not have a cable protruding from the side of the module, and you do not have to connect a sensor yourself. LCD display with module name, temperature, signal and battery indicators Push-button Figure 12 –...
Figure 13 – Dual temperature & humidity sensor The Cobalt L3 wireless humidity / temperature module monitors both relative humidity levels and temperature. This module is generally used in various types of storage, medical and traceability applications. The white sensor shown above contains both the humidity and temperature sensor.
Choose the method that works best for your location and place the Cobalt L3 module as described earlier in 3.6 Placing your Cobalt module for best wireless performance. Use the provided plastic cable holders to attach or coil the excess cable neatly.
Cobalt L3 module you are trying to connect. The Cobalt L3 temperature / humidity module runs on battery power. To activate your Cobalt L3 module and enable it to communicate via your OCEASOFT L3 receiver and the Cloud, follow these steps: 1.
Page 27
Refreshing the module display with a short press You may refresh the Cobalt L3 display with the latest sensor readings by performing a short press on the module’s pushbutton. Press the button briefly to update and view the current reading.
Lithium, 3600 mA). Contact technical support if the battery is OK and still nothing is displayed on the screen. I press the button for 3 seconds but my Cobalt L3 module does not connect to my receiver; what should I do? If your module displays “ACK_NOT_RECEIVED” instead of “ACK_RECEIVED” when you press the button, try bringing the module closer to your receiver for a better wireless connection.
