Seleco 20SM622 Service Manual

COLOR TELEVISION
CHASSIS PC 020
SERVICE MANUAL
fp 3 © a 47 47 AF AY 47
GENERAL FEATURES
CHASSIS - Series PC020 "cold' modular type
electrically separated from mains
PICTURE TUBE - 14" 29.1 mm Neck Diam.
POWER SUPPLY - 220V +/- 10%, 50/60Hz, 52Watt
MUSIC POWER - 2 Watt
LOUDSPEAKER - 16 Ohm
EHT - 20.7KV
MAX BEAM CURRENT - 600 pA
ANTENNA INPUT - 75 Ohm DIN 45325-2
TUNER - Varicap type
TUNING SYSTEM - Electronic voltage synthesis type with
On-Screen-Display
PROGRAM PRESELECTION - 30 storable programs
EXTERNAL IN/OUTPUT - Peritelevision (SCART) connection type EN 50049
RECEPTION STANDARD - C.C.1.R. PAL B-G
931995390
