Anda RaluStick AP864051 User Manual

RaluStick power bank
Product parameters:
Capacity: 5000mAh (18,5 Wh), 3.7V
•
• Battery type: Polymer Lithium-ion battery
• Type C Input: DC 5V/3A, 9V/2A, 12V/1.5A
• Output: DC 5V/4.5A, 9V/2.5A, 10V/2.25A
Wireless charger output power: 15W
•
Frequency range: 110-205 kHz
•
• Function: Magnetic Power Bank
• Material: Recycled Aluminum alloy
Instructions
1. When charging the mobile power supply, first connect the power cord with the
mobile power supply Type-C and then connect the other end with the Charger.
Connect the charging head and insert the charging head into the power supply.
2. Orange light means less than 80% power, and green light means more than 80%
power.
3. Aim the mobile power supply at the wireless charging receiving position of the
mobile phone and pull it on the mobile phone to charge the mobile phone.
4. When the mobile phone is fully charged or does not need to be charged, remove the
mobile power supply.
5. When the mobile power supply is low, the orange light flashes to prompt charging.
Please connect the power cord for charging.
6. If the wireless receiving equipment is far away from the center of the module, the
module will not enter charging state, at this time. The wireless receiving device
needs to be moved to the center of the transmitting module coil, and the module
will enter automatically into a charging state.
7. If the module detects that the wireless receiver is abnormal, the foreign matter at
the receiver shall be transmitted from the transmitter. Remove it from the module
and put the receiving end equipment on the transmitting module again to enter the
charging state.
EN
AP864051
User manual
Attention
1. It has overcurrent protection (OCP), short circuit protection (short), overvoltage and
undervoltage protection (UVP), foreign object detection (FOD), no-load protection
and other functions
2. Short circuit protection when the output port is short circuited or exceeds the
software protection current value, the power supply will be automatically turned
off. The load must be removed and the machine must be started again. If the load is
seriously short circuited, it may cause hardware short circuit. After the protective
circuit action power supply is turned off the load must be removed and the power
supply can be used normally only after charging is activated.
3. Avoid direct sunlight, high temperature and other environments, and stay away from
fire and heat sources
4. Store in a dry environment and avoid contact with corrosive substances
5. The power supply shall be kept at 50% of the rated capacity for more than 3 months.
6. When children use the power supply, they should be guided by their parents and
operate according to the contents of the manual to ensure that it is correctly used.
7. Do not disassemble or put into the fire without permission to avoid explosion
This item is in conformity with the following standards:
RoHS Directive 2011/65/EU and its subsequent amendments Directive (EU) 2015/863
Electromagnetic Compatibility (EMC) - Directive 2014/30/EU
UK Electrical Equipment (Safety) Regulations (SI 2016/1101)
UK Electromagnetic Compatibility Regulations (SI 2016/1091)
This symbol both in the product and its user manual indicates that at the end of the devices electrical life, it should
be recycled separately from your household waste. There are adequate means to dispose of this material for proper
recycling. There are adequate means to dispose of this material for proper recycling.
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the instructions.‫ك‬
Distributor: Cool Collection, 1476 Budapest, POB.176. Hungary
Registration nr.: 01-09-276783
Made in China
