  • Page 1 32" [16:9] AV/TV/PC MONITOR LCD COLOR TELEVISION DTV-322 DB-4500...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS (FOR TV TUNER) IMPORTANT INFORMATION IMPORTANT SAFETY PRECAUTIONS SUPPLIED ACCESSORIES PREPARATION INSERTING BATTERIES INTO THE REMOTE CONTROL ● USING THE REMOTE CONTROL UNIT ● CAUTIONS REGARDING REMOTE CONTROL UNIT ● DISPLAY FRONT VIEW ● REAR VIEW ● AVC SYSTEM FRONT VIEW ●...
  • Page 3 TABLE OF CONTENTS (FOR DVD PLAYER) BASIC OPERATIONS 52-56 PLAY DISCS ● PAUSE ● 52-55 ● VOLUME CONTROL ● DVD MENU PLAY ● SELECT WITH NUMBER BUTTONS ● PLAY DISCS IN VARIOUS WAYS 56-59 AUDIO MODE ● MUTE ● FAST PLAY ●...

  • Page 4: Important Information

    IMPORTANT INFORMATION WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated ’’dangerous voltage’’...

  • Page 5: Important Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS The present set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in the present unit will protect you if you observe the following procedures in installing, using and servicing. The present unit is fully transistorized and does not contain any element that can be repaired by the user.
  • Page 6 IMPORTANT SAFETY PRECAUTIONS f) When the product displays an abnormal condition. Any noticeable abnormality in the product indicates that the product needs servicing. 12. Replacement parts - In case the product needs replacement parts, make sure that the service person uses replacement parts specified by the manufacturer, or those with the same characteristics and performance as the original parts.

  • Page 7: Supplied Accessories

    SUPPLIED ACCESSORIES Make sure the following accessories are provided with the product. Power cord Display connecting cable AV cables 32" [16:9] AV/TV/PC MONITOR LCD COLOR TELEVISION DTV-322 DB-4500 Remote control User guide It also include: ①batteries (2) ②Warranty card ③QSG card...

  • Page 8: Preparation

    PREPARATION INSERTING BATTERIES INTO THE REMOTE CONTROL Insert supplied batteries via the battery compartment on the back of the remote control. Make sure polarity matches the (+) and (-) marks inside the compartment. USING THE REMOTE CONTROL UNIT Use the remote control by pointing it towards the remote ●...

  • Page 9: Display

    DISPLAY FRONT VIEW ON/OFF TV/VIDEO/PC TV MENU 1) POWER: Use to turn the unit on and off. 2) TV/VIDEO/PC: Use to select the AV signal source among: TV, INTER DVD, VIDEO1, VIDEO2, VGA, and HDMI/DVI. 3) TV MENU: Use to bring up the TV menu. 4) CH+/-: Use to skip to the next/previous channel.

  • Page 10: Avc System

    AVC SYSTEM FRONT PANEL 6 7 8 9 10 1112 (1) POWER Button (12) P Button (2) STANDBY indicator It can be used to select TV channel. ● Also it can be used as up/down buttons (3) DVD VFD ● when enter into TV menu and INPUT select (4) Disc Slot menu.

  • Page 11: Rear View

    AVC SYSTEM REAR PANEL 12 11 (1) AUDIO INPUT L/R(AV1 INPUT) (9) Power Supply Cord (10) ANTENNA INPUT (RF) (2) AV OUTPUT (L/R、VIDEO) (3) S-VIDEO INPUT (AV1 INPUT) (11) OPTICAL DIGITAL AUDIO OUTPUT (4) VIDEO INPUT (AV1 INPUT) (DVD) (12) COAXIAL DIGITAL AUDIO OUTPUT (5) Y, Cb/Pb, Cr/Pr INPUT (AV1 INPUT) (6) HDMI/DVI INPUT (DVD)

  • Page 12: Remote Control

    REMOTE CONTROL 1) VIDEO: Use to select the input signal source among: TV, INTER DVD, VIDEO1, VIDEO2, VGA, and HDMI/DVI. 2) DVD/CARD: In DVD mode, use to shift between DVD and CARD. In other mode, press to change to DVD mode directly. 3) TV: Press to change to TV mode directly.
  • Page 13 REMOTE CONTROL 8) Cursor Buttons ( ): Use to select a desired item on the setting screen. And move the picture on the screen. 9) OK: Use to confirm your selections. 10) DVD TITLE: Use to bring up the DVD title menu. 11) STOP: Use to stop the DVD playback.

  • Page 14: Connections

    CONNECTIONS You can connect many types of external equipment to your System. To protect all equipment, always turn off the AVC system before connecting. CONNECT TO POWER POWER SOCKET USING THE ANTENNA INPUT ANNTENA CABLE Connect the antenna terminal from an antenna or cable/satellite receiver to the antenna input terminal on the DB-4500;...

  • Page 15: Av1 Input

    CONNECTIONS You can use the AV1 INPUT terminal when connecting an HDTV tuner and DVD player. AV1 INPUT HDTV tuner or High High Definition Video Siginal Out Display (rear view) DVD player Y/Pb/Pr cable AVC System (rear view) Audio cable S-Video cable Display connecting cable Video cable...
  • Page 16 REMOTE CONTROL 8) Cursor Buttons ( ): Use to select a desired item on the setting screen. And move the picture on the screen. 9) OK: Use to confirm your selections. 10) DVD TITLE: Use to bring up the DVD title menu. 11) STOP: Use to stop the DVD playback.
  • Page 17 ANALOG RGB socket and the Audio input jack (for VGA) on the front panel of DB-4500; use the VIDEO button on the remote control to set the signal source to "VGA". DTV-322 monitor’s native resolution for computer use is 1366x768.
  • Page 18 CONNECTIONS When you connecting to the DVD output terminal, you must select INTER DVD by pressing VIDEO on the remote control. DVD OUT TO DIGITAL AMPLIFIER AVC system (rear panel) DIGITAL AUDIO OUT I N P U T SUBWOOFER MIXED FRONT SURROUND CENTER...
  • Page 19 CONNECTIONS DVD OUT TO 5.1-CHANNEL AMPLIFIER DIGITAL AUDIO OUT I N P U T SUBWOOFER MIXED FRONT SURROUND CENTER COAXIAL OPTICAL AUDIO ~ 120V 60Hz I N P U T R S - 2 3 2 C O U T P U T HDMI DISPLAY AUDIO...

  • Page 20: Basic Operations

    BASIC OPERATIONS POWER POWER VIDEO TV/VIDEO/PC ON/OFF TV/VIDEO/PC TV MENU TURN ON THE POWER 1. Turn on the power of the AVC system after the power cable is connected .And the AVC system is in standby state ; 2. Press POWER on the DISPLAY unit and the DISPLAY unit is in standby state and the STANDBY indicator lights up red ;...

  • Page 21: Watching Tv

    WATCHING TV TURN ON THE POWER 1. Turn on the power of the AVC system after the power cable is connected .And the AVC system is in standby state ; 2. Press POWER on the DISPLAY unit and the DISPLAY unit is in standby state and the STANDBY indicator lights up red ;...

  • Page 22: Using Flashback On The Remote Unit

    WATCHING TV Using number buttons on the remote unit NUMBER BUTTONS Select the channels directly by pressing the number buttons. EXAMPLE: To select a 1-digit channel (e.g. channel 2): Press 2 . ● To select a 2-digit channel (e.g. channel 12): Press 1 ,followed by 2 .

  • Page 23: Simple Button Operation For Changing Volume/Sound

    WATCHING TV SIMPLE BUTTON OPERATION FOR CHANGING VOLUME/SOUND Changing the volume You can change the volume by pressing VOL +/- button. VOL+/- ON/OFF TV/VIDEO/PC TV MENU VOL+/- 1. Press VOL+ to increase the volume. 2. Press VOL- to decrease the volume. Using MUTE on the remote control Press MUTE to mute the current sound output.

  • Page 24: Setting Mts/Sap Stereo Mode

    WATCHING TV Setting MTS/SAP stereo mode The System has a feature that allows reception of sound other than the main audio for the program. This feature is called Multi-channel Television Sound (MTS). The System with MTS can receive mono sound, stereo sound and Secondary Audio Programs (SAP). The SAP feature allows a TV station to broadcast other information, which could be audio in another language or something completely different like weather information.

  • Page 25: Basic Adjustment Settings

    BASIC ADJUSTMENT SETTINGS PICTURE ADJUSTMENT You can get the satisfied picture by adjusting the following picture setting menu. Press the VIDEO button to select various signal modes. Press TV MENU to enter LCD menu. Press / to select "Picture", and then press to enter "Picture"...
  • Page 26 BASIC ADJUSTMENT SETTINGS PICTURE ADJUSTMENT(CONTIUED) Color Saturation 1. Press to select "Color Saturation" in "Picture" menu. 2. Press to enter the color saturation menu. 3. Press to adjust the color saturation; press OK to return to the "Picture" menu. 4. Press TV MENU to exit. Note: In HDMI mode, "Color Saturation"...

  • Page 27: Audio Adjustment

    BASIC ADJUSTMENT SETTINGS AUDIO ADJUSTMENT Adjust the quality of the sound through the following audio settings. Press the VIDEO button to select various signal modes. Press TV MENU to enter LCD menu. Press to select "Audio", and then press to enter "Audio" menu. Other Mode PC Mode <left/right>...
  • Page 28 BASIC ADJUSTMENT SETTINGS AUDIO ADJUSTMENT(CONTINUED) Bass 1. Press to select "Bass" in "Audio" menu. 2. Press to enter the bass menu. 3. Press to adjust the bass; press OK to return to the "Audio" menu. 4. Press TV MENU to exit. Balance 1.

  • Page 29: Pip/Pop Adjustment

    BASIC ADJUSTMENT SETTINGS PIP/POP ADJUSTMENT Use to adjust the items of P&P functions. Press the VIDEO button to select various signal modes. Press TV MENU to enter LCD menu. Press to select "PIP/POP", and then press to enter "PIP/POP" menu. <left/right>...
  • Page 30 BASIC ADJUSTMENT SETTINGS 2. Press to adjust the horizontal position of the secondary picture. 3. Press OK to return and press TV MENU to exit. V · · Position You can move the secondary picture to up and down on the screen. to select "V ·...
  • Page 31 BASIC ADJUSTMENT SETTINGS POP Scan Mode 1. Press to select "POP Scan Mode" in "PIP/POP" menu. 2. Press to select the POP scan mode between Sequential and Fixed: (1) Sequential: In POP3 or POP12 mode, the TV program of the secondary picture being displayed in TV channel number order (1, 2,3,4 ..).

  • Page 32: Size Adjustment

    BASIC ADJUSTMENT SETTINGS SIZE ADJUSTMENT Use to adjust display mode of the playback picture. Press the VIDEO button to select various signal modes. Press TV MENU to enter LCD menu. Press to select "Size", and then press to enter "Size" menu. Other Mode PC Mode <left/right>...
  • Page 33 BASIC ADJUSTMENT SETTINGS SIZE ADJUSTMENT H-Position You can move the PC picture to left and right on the screen. 1. Press to select "H-Position" in "SIZE" menu. 2. Press to adjust the horizontal position of the PC picture. 3. Press OK to return and press TV MENU to exit. V-Position You can move the PC picture to up and down on the screen.

  • Page 34: Sleep Adjustment

    BASIC ADJUSTMENT SETTINGS SLEEP ADJUSTMENT Use to set the sleep timer. 1. Press the VIDEO button to select various signal modes. 2. Press TV MENU to enter LCD menu. 3. Press to select "Sleep", press to enter the sleep timer. 4.
  • Page 35 BASIC ADJUSTMENT SETTINGS COLOR ADJUSTMENT (PC MODE) <left/right> to adjust, <up/down> to select, <ok> to return PICTURE BACK NATURAL COLOR BACK COLOR NORMAL COLOR BLUE PRESET GREEN AUDIO BLUE RED PRESET SIZE USER PRESET PIP/POP SETUP 4. Press / to select Red , then press / to enter Adjust Color menu.

  • Page 36: Advanced Adjustment Settings

    ADVANCED ADJUSTMENT SETTINGS You can use the "Setup" in LCD menu to make some change on OSD, Channel, Language, and etc. OSD SETTINGS 1. Press TV MENU to enter LCD menu. 2. Press to select "Setup", and then press to enter "Setup" menu. 3.
  • Page 37 ADVANCED ADJUSTMENT SETTINGS <left/right> to adjust, <up/down> to select, <ok> to return PICTURE BACK AUDIO OSD SETTINGS BACK TUNE MODE CABLE CHANNEL SETUP PIP/POP TV Mode FACTORY RESET AUTO SEARCH AV INPUT SETUP FINE TUNING SIZE 0000 CLOSE CAPTION SKIP SLEEP PARENTAL CONT SETUP...
  • Page 38 ADVANCED ADJUSTMENT SETTINGS Skip If you have set the "Skip" of one channel to "ON", then when you pressing CH∧/∨ and this channel will be skipped. 1. Press CH∧/∨ or the number buttons on the remote control to select the channel you want to set. 2.

  • Page 39: Factory Reset

    ADVANCED ADJUSTMENT SETTINGS FACTORY RESET 1. Press TV MENU to enter LCD menu. 2. Press to select "Setup", and then press to enter "Setup" menu. 3. Press to select "Factory Reset", and then press to enter "Factory Reset" menu. Other Mode PC Mode <left/right>...
  • Page 40 ADVANCED ADJUSTMENT SETTINGS AV INPUT SETUP 1. Press TV MENU to enter LCD menu. 2. Press to select "Setup", and then press to enter "Setup" menu. 3. Press to select "AV Input Setup", and then press to enter "AV Input Setup" menu. Other Mode PC Mode <left/right>...

  • Page 41: Close Caption

    ADVANCED ADJUSTMENT SETTINGS You system is equipped with an internal closed caption decorder close caption is the system which allow you to view conversations, narration, and sound effects in TV programs and home videos as subtitles on your display. Note: Only in primary window, the close caption is available. CLOSE CAPTION 1.

  • Page 42: Parental Control

    ADVANCED ADJUSTMENT SETTINGS PARENTAL CONTROL 1. Press TV MENU to enter LCD menu. 2. Press to select "Setup", and then press to enter "Setup" menu. 3. Press to select "Parental Cont", and then press to enter "Parental Cont" menu. <left/right> to adjust, <up/down> to select, <ok> to return PICTURE BACK AUDIO...
  • Page 43 ADVANCED ADJUSTMENT SETTINGS PARENTAL CONTROL (CONTINUED) <left/right> to adjust, <up/down> to select, <ok> to return PICTURE BACK AUDIO OSD SETTINGS BACK ACCESS CODE CHANNEL SETUP PIP/POP CHANNEL LOCK FACTORY RESET TV/VIDEO1/VIDEO2 Mode BLOCK CONTROL AV INPUT SETUP SIZE MOVIE RATING CLOSE CAPTION TV RATING SLEEP...
  • Page 44 ADVANCED ADJUSTMENT SETTINGS PARENTAL CONTROL (CONTINUED) Block Control 1. Press TV MENU to enter LCD menu. 2. Press to select " Setup " , and then press to enter " Setup " menu . 3. Press to select " Parental Cont" , and then press to enter "...
  • Page 45 ADVANCED ADJUSTMENT SETTINGS PARENTAL CONTROL (CONTINUED) The U.S. has two rating system for viewing content: movie ratings and TV ratings . And this unit equipped with movie rating and TV rating in Parental Cont menu .This tool gives parents a great degree of control over broadcasts accessed by their children.
  • Page 46 ADVANCED ADJUSTMENT SETTINGS PARENTAL CONTROL (CONTINUED) TV RATING 1. Press TV MENU to enter LCD menu. 2. Press to select " Setup " , and then press to enter " Setup " menu. 3. Press to select " Parental Cont" , and then press to enter "...
  • Page 47 ADVANCED ADJUSTMENT SETTINGS PARENTAL CONTROL (CONTINUED) CHANGE CODE 1. Press TV MENU to enter LCD menu. 2. Press to select " Setup " , and then press to enter " Setup " menu . 3. Press to select " Parental Cont", and then press to enter "...
  • Page 48 ADVANCED ADJUSTMENT SETTINGS PARENTAL CONTROL (CONTINUED) CLEAR ALL 1. Press TV MENU to enter LCD menu. 2. Press to select " Setup " , and then press to enter " Setup " menu. 3. Press to select " Parental Cont" , and then press to enter "...

  • Page 49: Window Adjustment

    WINDOW ADJUSTMENT In PC mode you have to set the Windows system firstly as below. Resolution Freq. (Hz) 640×480 640×480 640×480 800×600 SVGA 800×600 800×600 1024×768 1024×768 1024×768 WXGA 1280×768 SXGA 1280×1024 NOTE: In case of inputting the PC signal format out of range , this unit will appear blank screen phenomenon.
  • Page 50 WINDOW ADJUSTMENT 2. Click on "Control panel", the control panel screen appears. 3. Double click on "Display" and a display dialog box displays. 4. Navigate to the "Setting " tab on the display dialog box .Set the "Screen resolution" to "1280×768 pixel".

  • Page 51: Instruction For Multi-Windows 48-50

    INSTRUCTIONS FOR MULTI-WINDOWS MULTI-PICTURE OPTIONS 1. Press the P&P button to select the following picture display: (1) Single Picture: There will be a single picture Single Picture being displayed on the screen. Secondary Picture (2) PIP: There will be a secondary picture displayed in the primary picture being played.
  • Page 52 INSTRUCTIONS FOR MULTI-WINDOWS 5. Signal Source Selection of Primary And Secondary picture: a. Signal Source selection of Primary picture: press "P.SELECT" to select the primary picture, and the green frame appears; then press "VIDEO" to open the SIGNAL SOURCE menu: INPUT SELECT EXIT INTER DVD...
  • Page 53 INSTRUCTIONS FOR MULTI-WINDOWS 6. Size of the primary or the secondary picture: a. Press P.SELECT button on the remote control to select the primary or the secondary picture. b. Then press VIEW MODE to select the following size: standard, zoom, 4:3, wide and full screen.

  • Page 54: Troubleshooting

    TROUBLESHOOTING Symptom Check Items Make sure the Display and the AVC System are connected correctly. No power ● Check if you pressed POWER on the remote control unit. If the ● indicator on the Display lights up red, press POWER. Is the AC cord disconnected? ●...

  • Page 55: Basic Operations

    BASIC OPERATIONS (FOR DVD PLAYER) Pause Play Discs 、 、 1. Press POWER to turn on the unit. 2. P r e s s t h e V I D E O b u t t o n o n t h e r e m o t e c o n t r o l t o b r i n g u p t h e AV s i g n a l s o u r c e s e l e c t i o n s c r e e n a n d u s e t h e b u t t o n s...
  • Page 56 BASIC OPERATIONS (FOR DVD PLAYER) Remember, you can only access the Display when you're 2. Press the buttons to highlight the Chapter icon. 3. Press the buttons to go to the previous or next playing a disc. Also, the Display features are only chapter.
  • Page 57 BASIC OPERATIONS (FOR DVD PLAYER) All - repeats the disc that is playing ● 1. When the disc is playing, press OSD on the remote Title - repeats the title that is playing ● to bring up the Display. Chapter - repeats the chapter that is playing ●...

  • Page 58: Volume Control

    BASIC OPERATIONS (FOR DVD PLAYER) DVD Menu Play To Use Repeat: 1. While a disc is playing, press OSD on the remote to bring up the Display. 2. Highlight the Repeat icon. Some DVDs have title menus and chapter menus. 3.

  • Page 59: Select With Number Buttons

    BASIC OPERATIONS PLAY DISCS IN VARIOUS WAYS Select with Number Audio Mode 、 Buttons You may select a language from a multi-language DVD. ● You may select the right channel, left channel, or stereo ● options from a multi-channel CD. Load a disc.

  • Page 60: Play Discs In Various Ways

    PLAY DISCS IN VARIOUS WAYS Fast Play 、 To select audio channel option when for CD playback, press A.MODE . The screen will show the following in When playing a disc, you can play it in fast-forward or order: fast-reverse mode to find what you want to view. A.MODE MONO LEFT DVD OR CD...

  • Page 61: Repeat Play

    PLAY DISCS IN VARIOUS WAYS REPEAT Repeat Play 、 TRACK This function can be used to repeatedly play a title, chapter, track, or a whole disc. 2. To repeat a disc: Press REPEAT , the screen shows " ALL". The unit plays all the tracks on the disc. REPEAT REPEAT 3.

  • Page 62: Select Subtitles

    PLAY DISCS IN VARIOUS WAYS Select Subtitles Program Play This operation works only with discs with multiple subtitle PLAY MODE languages recorded. To use the program playback feature, you must enter the order in which you want the titles (and chapters) on the DVD or the tracks on the CD to play by creating a program.

  • Page 63: Shuffle (Random) Play

    PLAY DISCS IN VARIOUS WAYS Shuffle (Random) Play 1. Press PLAY MODE until the screen shows: The unit can play DVD chapters or audio tracks in PROGRAM: TRACK (01-20) 01 _ _ 06 _ _ random order. 02 _ _ 07 _ _ 03 _ _ 08 _ _...

  • Page 64: Menu Setting

    MENU SETTING According to the recorded information and external The screen shows: equipment, set the following functions for the player to obtain the best playing status. -- Audio Setup Page -- Speaker Setup Dolby Digital Setup Channel Delay SETUP Channel Trim Channel Equalizer 3D Processing Main Page...

  • Page 65: General Setup

    MENU SETTING -- General Setup Page -- TV Display WIDE Normal/PS --Dolby Digital Setup-- Normal/LB Dual Mono Stereo Wide Left Mono HD MODE 1080i Right Mono Mixed Mono 1080i D.R.C SPDIF Audio Setup SPDIF/RAW SPDIF/PCM Captions 3. Exit setup menu. Press the direction button to exit from "Dual ●...

  • Page 66: Audio Setup

    MENU SETTING Audio Setup ■ HD MODE You may select according to the color system of the TV to The setting structure is: be connected. - - Audio Setup Page - - Select "OFF"for a NTSC TV. ● Speaker Setup Dolby Digital Setup Select "1080i"...
  • Page 67 MENU SETTING DUAL MONO ■ CHANNEL EQUALIZER ● This is the output mode of the L and R signals of the This option will help you to select graphic equalizer patterns according to the genre of the music being set audio output. If it is set to "MIXED MONO", the played.
  • Page 68 MENU SETTING NOTE:If "PRO LOGICⅡ "is set to "OFF",the all PRO LOGIC II ● following options will be turned off . Use the direction button to select "PRO LOGIC II " and press the (PLAY) button to confirm,and MODE ◆ enter"PRO LOGICⅡ...

  • Page 69: Password Setup

    MENU SETTING Password Setup CENTRE WIDTH ◆ This is used to select different width and mix the sound The setting structure is : out of the centre channel to the two front channels to bring better feeling. When it is set to the max ,the sound out of the centre - - Password Setup Page - - channel is completely mixed to the two front channels.

  • Page 70: Preferences

    ■ discs rated higher than the PG grade. ■ DEFAULT >> RESET Each function setting returns to the initial status in the During playback of MP3 discs, the unit features mute, factory if you select this option. volume control, and repeat play. Operations are the Note: same as CD.

  • Page 71: Kodak Picture Cd Playback

    KODAK PICTURE CD PLAYBACK A Kodak Picture CD has the size and shape of a regular CD. You can order a KODAK Picture CD simply by checking the box on the photofinishing envelope when you drop off a roll of film (35 mm or Advanced Photo System (APS) color print film) at the time of processing in photo processing outlet displaying "Kodak Picture CD"sign.

  • Page 72: Memory Card Play Operation

    MEMORY CARD PLAY OPERATION MEMORY CARD (MMC/SD /Memory Stick card ) can memory MP3 songs and digital pictures . How to select MEMORY CARD to play 1. Turn on the power of the display and AVC system after the system cable is connected. 2.

  • Page 73: Troubleshooting

    TROUBLESHOOTING If you experience the following problems while using the unit, this troubleshooting guide can help you. No sound Disc cannot be played Check if the unit is connected securely. ● There is no disc in the unit. ● Make sure the TV or amplifier is working properly. Put the disc on the disc tray properly with the label ●...

  • Page 74: Technical Specifications

    TECHNICAL SPECIFICATIONS 32’’ WIDE TFT LCD PANEL RESOLUTION 1366 X RGB X 768 (WXGA) VIEWING ANGLE (H/V) 176° /176° CONTRAST RATIO 600:1 BRIGHTNESS (cd/m2) MORE THAN 99.99% EFFECTIVE PIXEL RATE WITH STAND (mm) 1000 X 180 X 605 DIMENSION WITHOUT STAND (mm) 1000 X 79 X 503 TV STANDARD NTSC...
