Industrial On-Demand Inkjet Printer
Instruction Manual
Printhead Reservoir
Thank you for your purchase of our product.
Please read this instruction manual carefully so that you can use this equipment correctly.
Be sure to keep this instruction manual at hand, and consult it if you have any questions or run into a
problem during use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JET H1200 and is the answer not in the manual?

Questions and answers

Summary of Contents for KGK JET H1200

  • Page 1 Industrial On-Demand Inkjet Printer Instruction Manual Printhead Reservoir Thank you for your purchase of our product. Please read this instruction manual carefully so that you can use this equipment correctly. Be sure to keep this instruction manual at hand, and consult it if you have any questions or run into a problem during use.

  • Page 3: Introduction

    Introduction About this instruction manual This instruction manual is intended only for KGKJET H300 printhead (hereinafter referred to as “H300”), KGKJET H600 printhead (hereinafter referred to as “H600”), and KGKJET H1200 printhead (hereinafter referred to as “H1200”). No part of this manual may be reproduced without our prior permission. Every effort has been made to prepare this manual.

  • Page 4: Safety Precautions

    Safety Precautions Before you start using the equipment, read the [Safety Precautions] carefully and handle the equipment correctly so that the equipment can fully deliver its performance. This manual also contains safety precautions as shown below in order to prevent harm to people and damage to property.
  • Page 5 About the Power Supply Danger Handle the power cable with care. Do not scratch, modify, or heat the power cable. Do not put any heavy objects on the power cable. Failure to observe this may damage the power cable, thus leading to fire or electric shock.
  • Page 6 About the Printhead Warning Handle the nozzle face with care. The nozzle face (ink ejection face) is a delicate component. Pay special attention not to allow hands, objects, or target objects to come into contact with the nozzle face. Be aware that the printhead becomes very hot. The area around the printhead becomes hot when the power is on.
  • Page 7 Do not install this product in the following places, since this product is a precision device. Danger Do not install the equipment at a hot or humid place. Do not use this equipment at a place where the temperature is high (for example, due to direct exposure to sunlight) or at a place where the humidity is high.
  • Page 8 Caution Do not install the equipment at a place where there is not enough clearance around the equipment. Secure enough space around the equipment for maintenance work. Secure enough clearance in front of the printhead so that you can wipe the printhead face with the dedicated wiper, while looking at the nozzle face to minimize the vibration to the printhead.

  • Page 9: Features And Structure Of This Equipment

    Features and Structure of This Equipment H300 printhead, H600 printhead, and H1200 printhead are high-performance inkjet printers for industrial use, which enables the printing of high-quality characters (300 dots and 600 dpi, closer to letterpress printings) in various manufacturing lines. We have reviewed the basic design in all aspects ranging from the printhead, ink, hardware, software, to the system, and have realized the print quality, printing performance, operating efficiency, reliability, and maintenance friendliness that were unimaginable in conventional...

  • Page 10: Table Of Contents

    Table of Contents Introduction ....................3 Safety Precautions ..................4 Features and Structure of This Equipment ........9 Structure ..................12 Parts of H300’s Head Portion ................12 Structure of H600 and H1200 ................13 Parts of H1200’s Printhead Portion ..............14 Printheads for Each Model ...................
  • Page 11 Adjusting the Horizontal Angle ..................37 Adjusting the Front Angle ....................39 Adjusting the Printing Distance ................41 Adjusting the Printing Shift Between Cartridges .......... 41 How to Make Adjustments for HQ1100 ..............42 How to Make Adjustments for HQ8500 ..............45 Adjusting the Distance Between Cartridges ............

  • Page 12: Structure

    Structure Parts of H300’s Head Portion Ink cartridge lever Spit switch Mode switch Ink cartridge “Firing” lamp Nozzle cap “Maintenance” lamp “Ready” lamp Nozzle Printhead cable connector Photoelectric sensor connector Item Function Nozzle 300 ink ejection ports (nozzle) are arranged in the 12.7 mm range. If you do not eject ink for a long time, attach the cap to prevent ink from Nozzle cap hardening at the nozzle.

  • Page 13: Structure Of H600 And H1200

    Structure of H600 and H1200 Printhead Printhead cable AC adapter Stack collar Item Function Prints characters onto a target object (an item on which characters are Printhead printed). Cable for connecting the controller’s main unit and the printhead. This is an Printhead cable electric cable for driving the printhead.

  • Page 14: Parts Of H1200'S Printhead Portion

    Parts of H1200’s Printhead Portion “Maintenance” lamp “Firing” lamp “Ready” lamp Ink cartridge D Spit switch Ink cartridge C Mode switch Ink cartridge B Printhead cable connector Ink cartridge A Nozzle x 4 Printhead printing sensor connector AC adapter connector Bolt for adjusting Screw for adjusting Ink cartridge lever x 4...

  • Page 15: Printheads For Each Model

    Printheads for Each Model Available printheads depend on the model. The following are the allowable combinations: Model Printhead H1200 HQ1100 H600 H300 H1200 HQ8500 H600 Caution H300 printhead cannot be used with HQ8500. TEC3055K...

  • Page 16: Before Starting The Installation

    Before Starting the Installation Installation Procedure For H1200 Page 17 [Checking the Installation Environment and Precautions] For H300 Page 19 [Procedure for Installing the Page 27 [Installing the Shockless Guard] Photoelectric Sensor] Page 20 [Mounting the Photoelectric Page 30 [Procedure for Installing Sensor] the Printhead] Page 22 [Procedure for Installing the...

  • Page 17: Checking The Installation Environment And Precautions

    Checking the Installation Environment and Precautions Warning The printhead is a precision device. Avoid installing the equipment at the following places: ⚫ Place where the ambient temperature is outside the range of 5°C to 35°C (normal use). ⚫ Place exposed to frequent vibration / place where inclination is steep. ⚫...

  • Page 18: Directions In Which The Printhead Can Be Installed

    Directions in Which the Printhead Can Be Installed There are only two directions in which the printhead can be installed: downward and sideways. Even for sideways installation, do not set the printhead upside down. You can install it You can install it You cannot install it You cannot install it with its nozzle...

  • Page 19: Installing H300

    Installing H300 Procedure for Installing the Shockless Guard If you use the shockless guard (option), install it through the following procedure. Slide the nozzle cap upward. Set the nozzle cap on the upper side. Attach the shockless guard onto the printhead. Fix the shockless guard onto the printhead with the two supplied screws (hexagon...

  • Page 20: Mounting The Photoelectric Sensor

    Mounting the Photoelectric Sensor You need to mount the photoelectric sensor on the upstream side of the target object flow. Referring to the figure below, determine the mounting position and mount the photoelectric sensor. When the target objects flow in the When the target objects flow in the normal direction reverse direction...
  • Page 21 (a3) Fit the sensor cable in the groove on the left (b3) Fit the sensor cable in the groove on the side of the printhead. right side of the printhead. (a4) Insert the connector of the photoelectric (b4) Insert the connector of the photoelectric sensor into the photoelectric sensor sensor into the photoelectric sensor connector on the rear side of the printhead.

  • Page 22: Procedure For Installing The Printhead

    Procedure for Installing the Printhead Mount the printhead onto the stand using the 3 mm hexagonal wrench (a setscrew is used at one position). The printhead mounting unit can be mounted onto the 20mm diameter shaft. Make sure that the nozzle is placed perpendicular to the flow of the target objects, and then tighten the setscrew on the printhead mounting unit.

  • Page 23: Installing The Reservoir

    Installing the Reservoir If you use bulk ink, you need to install the reservoir. Install the reservoir through the following procedure. Setting Level of the Reservoir The setting level changes depending on the direction of ink ejection. Fix the shaft in place in accordance with the distances shown in the figure below. Make sure that the tank does not tilt.

  • Page 24: Attaching The Cartridge

    Attaching the Cartridge Check the nozzle cap of the printhead before attaching the cartridge. The nozzle cap has been set on the upper side at the time of shipment (see the correct position in the figure below). Otherwise, pull the nozzle cap towards the front, and slide it upward. The nozzle cap is at the correct position when the nozzle is completely exposed and the nozzle cap is engaged with the positioning tab.
  • Page 25 Push down the projection on top of the cartridge as if the cartridge were pivoted around the rounded corner above the nozzle on the front. The cartridge fits in horizontally if it is mounted correctly. Pi v ot center Pull the lever up to fix the cartridge in place. Caution ⚫...

  • Page 26: Test Printing

    Test Printing When the printhead has been installed, print the test pattern to check for any printing defects. Refer to [Test Printing] on page 55 for how to conduct test printing. Protecting the Nozzle If you do not print for a long period, protect the nozzle through the following procedure to prevent ink from hardening at the nozzle.

  • Page 27: Installing H1200 (H600)

    Installing H1200 (H600) Installing the Photoelectric Sensor You need to install the photoelectric sensor on the upstream side of the target object flow. Referring to the figure below, determine the installation position and install the photoelectric sensor. When the Target Objects Flow in the Normal Direction Target object Photoelectric sensor...
  • Page 28 (2) Remove the bottom face cover of the printhead. Bottom face cover (3) Fit the cable into the grooves of the printhead. Photoelectric sensor cable Groove Groove (4) Attach the bottom face cover to the printhead. (5) Connect the photoelectric sensor to the printing sensor connector on the rear side of the printhead.

  • Page 29: When The Target Objects Flow In The Reverse Direction

    When the Target Objects Flow in the Reverse Direction Target object Photoelectric sensor (1) Install the photoelectric sensor on the left side of the printhead. Photoelectric sensor (2) Connect the photoelectric sensor to the printing sensor connector on the rear side of the printhead.

  • Page 30: Procedure For Installing The Printhead

    Procedure for Installing the Printhead (1) Adjust the protrusion of the stack collar bolts to 10 mm or below. (2) Slide the stack collar over the stand shaft. Stack collar Stand shaft (3) Slide the printhead over the stand shaft. Printhead (4) Attach the collar onto the edge of the shaft, and fix the collar in place with the hexagon socket setscrew.
  • Page 31 (5) Move the printhead until it touches the collar. Move the stack collar until it touches the printhead. Bring it into contact with the printhead. Bring it into contact with the printhead. (6) Tighten the screw of the stack collar. Note that the cut face of the shaft must be perpendicular to the screw.
  • Page 32 (8) After adjusting the horizontal angle, fix the printhead in place with the other bolt of the stack collar. Turn the horizontal angle adjusting bolt Printhead is fixed counterclockwise to fix the printhead in place in place (9) Tighten the two bolts on the printhead side to fix the printhead in place. Tighten the cap bolts TEC3055K...

  • Page 33: Connecting The Cable

    Connecting the Cable This section explains how to connect the cable. Before connecting the cable, be sure to turn OFF the power of the controller. Caution Do not connect or disconnect the cable while the power is ON. This equipment may break down if the cables are connected or disconnected while the power is still ON.

  • Page 34: Attaching The Cartridge

    Attaching the cartridge (1) Take a new cartridge out of the box. Detach the nozzle cover that is attached to the cartridge. Because you may need to use the nozzle cover again to protect the nozzle, keep the nozzle cover until you dispose of the cartridge. Nozzle cover Caution Do not touch the nozzle face or the electrodes located at the bottom of the cartridge or hit any...
  • Page 35 (4) Install the cartridge onto the printhead. Cartridge Take care not to rub and damage the nozzle Caution ⚫ Insert the cartridge, paying attention not to bump the cartridge nozzle into the wall of the cartridge holder. Otherwise, the cartridge may get damaged. ⚫...

  • Page 36: Test Printing

    Test Printing When the printhead has been installed, print the test pattern to check for any printing defects. Refer to [Test Printing] on page 55 for how to conduct test printing. Protecting the Nozzle If you do not print for a long period, detach the cartridge and attach the supplied cover to prevent ink from hardening at the nozzle.

  • Page 37: Adjusting The Printhead Angle

    Adjusting the Printhead Angle Adjusting the Horizontal Angle This section explains how to adjust the horizontal angle of the printhead. Make this adjustment if the printed contents look tilted. Printed result when the horizontal angle is incorrect (1) Loosen the two cap bolts. Loosen the cap bolts (2) Release the lock of the horizontal angle adjustment.
  • Page 38 (3) Adjust the horizontal angle. You can adjust the angle in the direction A if you turn the bolt clockwise, and in the direction B if you turn the bolt counterclockwise. Turn the bolt clockwise Turn the bolt counterclockwise (4) Lock the adjusted angle. Turn the bolt clockwise until the bolt contacts the base. Turn the bolt clockwise (5) Tighten the two cap bolts.

  • Page 39: Adjusting The Front Angle

    Adjusting the Front Angle This section explains how to adjust the front angle of the printhead. Printed result when the front angle is incorrect (1) Loosen the two screws. Loosen these screws (2) Turn the two bolts until they become separated from the base. Base Turn the bolts until they become separated from the base TEC3055K...
  • Page 40 (3) Adjust the front angle using the front angle adjusting screw. Turn the screw clockwise to move the printhead in direction Turn the screw counterclockwise to move the printhead in direction B. (4) Tighten the two screws. Tighten these screws (5) Turn the two bolts until they contact the base.

  • Page 41: Adjusting The Printing Distance

    Adjusting the Printing Distance 5 mm or less You can get better printing results if the nozzle is closer to the printing surface. Install the printhead at a position where it would not collide with the target objects even if this clearance fluctuates depending on the flow of the target objects.

  • Page 42: How To Make Adjustments For Hq1100

    How to Make Adjustments for HQ1100 (1) From the main screen of the controller, select “Menu” → “System settings” → “System” → “Head composition” in that order. Touch “Menu” on the main screen. Touch “System setting,” and then touch “System.” In the system menu, touch “Head システム設定メニューよりシステム...
  • Page 43 (2) The Head composition screen appears. Select the printhead to which H1200 is connected. As for the “Number of heads,” select the number of printheads that is connected to the controller. As for the “Print command input,” select a printhead whose photoelectric sensor is used.
  • Page 44 (4) Print the test pattern. Refer to [Test Printing] on page 55 for how to conduct test printing. If you need to make readjustments after test printing, repeat Steps (1) to (4). TEC3055K...

  • Page 45: How To Make Adjustments For Hq8500

    How to Make Adjustments for HQ8500 (1) In the menu bar of the main screen of the controller, select “System” → “Head settings” → “Indv head settings” in that order. (2) The individual printhead setting screen appears. Select the printhead to which H1200 is connected.
  • Page 46 (3) In the “Basic settings” tab, adjust the setting values of the stack. Refer to [Adjusting the Distance Between Cartridges] on page 47 and [Adjusting the Overlapping Area] on page 49 for details of the setting values. Stack setting items Description Stack item Enable these settings to sound an alarm if a cartridge cannot...

  • Page 47: Adjusting The Distance Between Cartridges

    Adjusting the Distance Between Cartridges Caution ⚫ Make this adjustment after the adjustment of the printhead angle. ⚫ Refer to [Adjusting the Horizontal Angle] on page 37 and [Adjusting the Front Angle] on page 39 for how to adjust the angles. Adjust the distance between cartridges when there is shift in the lateral direction between cartridges.
  • Page 48  When printing in the reverse direction (1) Adjust the distance between C-D cartridges. There is no need for adjustment if only two or three cartridges are used. If the distance is set longer, the printing start position of cartridge C shifts to the left.

  • Page 49: Adjusting The Overlapping Area

    Adjusting the Overlapping Area Caution ⚫ Make this adjustment after the adjustment of the printhead angle. ⚫ Refer to [Adjusting the Horizontal Angle] on page 37 and [Adjusting the Front Angle] on page 39 for how to adjust the angles. Adjust the overlapping area when the distances of the printed contents between cartridges are uneven.
  • Page 50 cartridge B shifts upward. If the area is set smaller, the position shifts downward. Information Do not use the lower area of the canvas when creating the contents to be printed. Otherwise, if you set an overlapping area, contents may not be printed in the area by the ink cartridge A.

  • Page 51: Maintenance

    Maintenance The maintenance procedure is common to the printheads of all models. Regular Maintenance If the exterior surface is very dirty, wipe it off using neutral detergents. Caution Do not use any neutral detergents on the nozzle face. When Not in Use for a Long Period If you do not use the H300 (with TK403 Black ink attached) for one week or longer, detach the cartridge from the printhead, and attach the cover that was supplied with the cartridge.

  • Page 52: Spitting

    Spitting Spitting is a function which ejects ink from all nozzles. The spitting procedure changes depending on the model. HQ1100  Operating from the printhead Press the Mode switch once while the maintenance lamp is OFF. The maintenance lamp flashes (spitting mode). Hold a piece of paper in front of the nozzle, and press the Spit switch.

  • Page 53: Hq8500

    HQ8500 (1) Press the Mode switch once while the maintenance lamp is OFF (normal mode). Then the maintenance lamp flashes (spitting mode) and the system screen enters the spitting mode. This lamp flashes Press once System screen for the spitting mode Information Refer to [Mode Switch and Lighting Patterns] on page 66 for details of the Mode switch and maintenance lamp.
  • Page 54 (3) Hold a target object which will not be used, in front of the nozzle; and press the Spit switch. Pressing the switch ejects ink. Target object not to be used Press this switch (4) Print the test pattern. Refer to [Test Printing] on page 55 for how to conduct test printing. To exit the maintenance mode without test printing, press the Mode switch twice.

  • Page 55: Test Printing

    Test Printing This section explains how to print the test pattern and check the condition of the printed contents. The procedure changes depending on the model. HQ1100  Operating from the printhead Press the Mode switch twice while the maintenance lamp is OFF. The maintenance lamp comes on.
  • Page 56 Press to exit the test printing. Information ⚫ If the actual conveyor speed is different from the speed setting, the length of the printed pattern becomes different from the normal print length. ⚫ If the actual conveyor speed is slower than the print speed setting, the printed pattern becomes shorter.

  • Page 57: Hq8500

    HQ8500 (1) Press the Mode switch twice while the maintenance lamp is OFF. The maintenance lamp comes on (test printing mode); and the system screen switches to the test printing mode. This lamp comes ON Press twice System screen for the test printing mode Information Refer to [Mode Switch and Lighting Patterns] on page 66 for details of the Mode switch and maintenance lamp.
  • Page 58 (3) Move a test piece (copy paper, a piece of cardboard, etc.) at a steady speed (manual feeding, or on a conveyor if available). When the test piece moves across the front of the nozzle, press the Spit switch. Test piece Press this switch Information ・If the actual conveyor speed is different from the speed setting, the length of the printed...
  • Page 59 (4) Make sure that the test patterns are printed on the test piece. If there are dots that are not printed, repeat test printing a few times. If missing dots are still observed, refer to [If Missing Dots Are Observed] on page 51. In addition, if the printed contents are not normal, refer to [Examples of Printing Defects and the Action] on page 71.
  • Page 60 (5) Press the Mode switch once to exit the test printing mode. The equipment is back to the normal operation mode when the maintenance lamp is OFF. This lamp goes out Press once TEC3055K...

  • Page 61: Cleaning The Nozzle Face

    Cleaning the Nozzle Face If missing dots cannot be eliminated even if spitting operation is repeated a few times, clean the nozzle face. Turn OFF the power or shut down the operation. With the dedicated wiper, wipe the nozzle face gently through the following method (the wiping procedure changes depending on the ink type).

  • Page 62: Replacing The Cartridge

    Replacing the Cartridge The ink level appears on the controller screen. When the ink level becomes lower than the specified value, the ink lamp comes on in the case of HQ1100, and the “LOW” alarm appears in the case of HQ8500. Immediately replace the cartridge if these signs show up.
  • Page 63 Remove the cartridge. Click to display the next step. Take a new cartridge out of the box, and remove the cover. Click to display the next step. Because you may need to use the nozzle cover when you store it for a long time, keep the nozzle cover until you dispose of the cartridge.

  • Page 64: Hq8500

    To exit cartridge replacement, click Information ⚫ You can also replace the cartridge while the equipment is powered OFF. In that case, the cartridge will be scanned when the power is ON. ⚫ You can also conduct the cartridge replacement work with the Mode switch on the printhead. Refer to [Mode Switch and Lighting Patterns] on page 66 for details.
  • Page 65 (4) Detach the cartridge to be replaced. Cartridge (5) Install a new cartridge into the holder, lift the cartridge lever, and fix the cartridge in place. Refer to [Attaching the cartridge] on page 34 for details. Cartridge (6) Press the Mode switch on the printhead once. “Scanning for the cartridge” appears on the screen.

  • Page 66: Mode Switch And Lighting Patterns

    Mode Switch and Lighting Patterns This section explains each operation mode and the lighting pattern of the lamp. The operation mode can be switched by pressing the Mode switch. The lighting pattern changes depending on the mode and the model. HQ1100 You can conduct spitting, test printing, and cartridge replacement using only the Mode switch and Spit switch of the printhead.

  • Page 67: Hq8500

    HQ8500  Using the Mode switch The following explains the procedure and indications when you cycle through the operation modes using the Mode switch. Mode Printhead status Lamp indication Function This is the normal Maintenance lamp is Normal state. Press the Mode switch once This is the spitting mode.
  • Page 68  To attach/detach the cartridge The following explains the procedure and indications when attaching/detaching the cartridge. Mode Printhead status Lamp indication Function This is the normal Normal Maintenance lamp is state. Select “Put on/off” button on the system screen You can attach or detach the cartridge Attaching/ All lamps come on...

  • Page 69: Consumables

    Consumables Placing Orders for Consumables When you place an order for consumables, let us know the model (indicated on your cartridge) and the quantity. Model Part name (Your cartridge model)-CS 1 cartridge of your cartridge model. (Your cartridge model)-CP A set of 10 cartridges of your cartridge model. WIPER1 BC wiper Solvent for cleaning (applicable to TK406 Black, TK411...

  • Page 70: Bc Wiper

    BC Wiper The BC wiper is used for wiping the nozzle face. This wiper is a dust-free wiper dedicated to IJP nozzles. If other materials (tissue paper or the like) are used for wiping the nozzle face, the equipment may break down. If air is trapped inside the nozzle, or if foreign materials, hardened ink, or other substances have adhered to the nozzle face, ink may not be ejected from some nozzles (missing dots).

  • Page 71: Examples Of Printing Defects And The Action

    Examples of Printing Defects and the Action This chapter explains how to deal with printing defects. Example of printing defects Possible cause and action Characters are overlapped. Check whether the speed of the actual target object matches the speed setting of the printing conditions. If the speeds do not match, adjust the speed setting.

  • Page 72: Product Warranty

    KGK even if the fault of the Product is valid for free repairs. ⚫ If part or whole of the Product is modified without KGK’s prior approval, the cost of repairs shall be borne by the Customer even if the fault occurs within the warranty period.
  • Page 74 Kishu Giken Kogyo Co., Ltd. 466 Nunohiki Wakayama-city Wakayama, Japan 641-0015 http://www.kishugiken.co.jp (July 2023)
