Struers Coolimat-200 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Coolimat-200
Manual No.: 16167001
Instruction Manual
Date of Release 2016.09.20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Coolimat-200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Struers Coolimat-200

  • Page 1 Coolimat-200 Manual No.: 16167001 Instruction Manual Date of Release 2016.09.20...
  • Page 2 The manual may mention accessories or parts not included in the present version of the equipment. Original Instructions. The contents of this manual is the property of Struers. Reproduction of any part of this manual without the written permission of Struers is not allowed.
  • Page 3 The equipment should only be used for its intended purpose and as detailed in the Instruction Manual. The equipment is designed for use with consumables supplied by Struers. If subjected to misuse, improper installation, alteration, neglect, accident or improper repair, Struers will accept no responsibility for damage(s) to the user or the equipment.
  • Page 4 Coolimat-200 Instruction Manual Disposal Equipment marked with a WEEE symbol contain electrical and electronic components and must not be disposed of as general waste. Please contact your local authorities for information on the correct method of disposal in accordance with national legislation.

  • Page 5: Table Of Contents

    Preparing the Cooling Unit for Use ..........10 Filling the Tank ................10 Connecting to the Power Supply ..........11 Connecting Coolimat-200 to the Cut-off Machine ......12 2. Operation Control Panel ................... 13 Control Panel Indicators/ Functions ..........13 Starting Coolimat ................

  • Page 6: Getting Started

    Coolimat-200 Instruction Manual 1. Getting Started 1 Cooling unit tank, 200 l Coolimat-200 Components* 1 Waste collection bin 1 Plastic liner 1 Filter Unit: Band Filter OR Static Filter 1 Water level indicator 1 Control unit (Cooli-2) 1 24 V / CAN control cable...

  • Page 7: Unpacking Coolimat-200

    Coolimat-200 Instruction Manual  Unpacking Coolimat-200 Remove the plastic wrapping.  Lift off the filter unit and remove the waste collection bin from inside the tank. Filter unit Waste collection bin Tank Warning! Place the filter unit carefully on the floor.

  • Page 8: Getting Acquainted With Coolimat-200

     Water level indicator  Waste collection bin Filter Unit Cover - Safety The filter unit cover contains a switch which disconnects the power to Switch the Coolimat when the cover is opened. Coolimat-200 must be reset after activation of safety switch.
  • Page 9 Coolimat-200 Instruction Manual Coolimat-200 with Static Filter  Static Filter plate  Hole for additional Filter bag (option)  Filter bag with water inlet duct  Pump Unit  Cooling fluid tank (wheel mounted)  Pump housing  Control unit with Emergency Stop ...

  • Page 10: Assembling The Coolimat-200

    Coolimat-200 Instruction Manual  Assembling the Coolimat-200 Remove the filter unit and the pump unit.  Insert a tank liner into the cooling fluid tank.  Replace the pump unit on the right or the left hand side of the tank.

  • Page 11: Static Filter

    Coolimat-200 Instruction Manual Static Filter Mounting a Filter Bag The static filter unit is delivered with one filter bag fitted.  Ducts for outlet hose from connected machine.   Insert the water outlet hose from the connected machine into the duct with the correct size in the Filter Bag.

  • Page 12: Connecting The Control Unit

    Coolimat-200 Instruction Manual Connecting the Control Unit The diagram below shows the rear of the Cooli-2 control unit.  Cooli-2 to pump  Cooli-2 to Band Filter conveyor motor (for Static Filter, use the dummy connector plug supplied)  Cooli-2 to cut-off machine 24V/ CAN (W16) ...

  • Page 13: Cooli-1 Additional Control Unit

    Coolimat-200 Instruction Manual Cooli-1 Additional Control Unit When a 2 pump is used, an additional control unit (Cooli-1) is mounted on top of the Coolimat control unit (Cooli-2). (accessory)  Fit the black connection plate onto the Cooli-1 unit. ...

  • Page 14: Preparing The Cooling Unit For Use

    Note: To avoid corrosion, Struers recommends the use of Struers Additive, Corrozip-LF in the cooling water (percentage stated on the Additive container). Remember to top up with Struers Additive each time you refill with water.

  • Page 15: Connecting To The Power Supply

    IMPORTANT! Check that the mains voltage corresponds to the voltage stated on the type plate on the machine Coolimat-200 is shipped with 2 types of Mains cables: The 2-pin (European Schuko) plug is for use on single-phase connections. If the plug supplied on this cable is not approved in your country, then the plug must be replaced with an approved plug.

  • Page 16: Connecting Coolimat-200 To The Cut-Off Machine

    Water is directed from the cut-off machine to Coolimat via the water outlet hose supplied with the cut-off machine. On Struers’ large, floor-type cut-off machines the hose is rigid, on the smaller tabletop machines, a flexible hose is used. Both hose types are supplied with a drain angle which fits into the water inlet duct on filter unit cover.

  • Page 17: Operation

    Coolimat-200 Instruction Manual 2. Operation Control Panel The diagram below illustrates the Coolimat control panel (Cooli-2). Control Panel Indicators/ Functions Name Function Name Function   Green LED indicator: Power on. The Emergency Stop disconnects Normal operation. the power supply to Coolimat.

  • Page 18: Starting Coolimat

    (Band filter:- will automatically feed fresh filter paper when the cooling fluid reaches a set level). Coolimat-200 will enter Standby mode when cutting is stopped.  Power off To disconnect the power supply to Coolimat, press the Emergency Stop button.

  • Page 19: System Components And Accessories

    The use of Struers consumables is recommended. Other products (e.g. coolants) may contain aggressive solvents, which dissolve e.g. rubber seals. The warranty may not cover damaged machine parts (e.g. seals and tubes), where the damage can be directly related to the use of non-Struers consumables.

  • Page 20: Troubleshooting

    Reset machine has been activated. This NB!:- Pressing the Emergency stop will stop the pump. on Coolimat-200 will not stop the cut-off machine. Filter paper is not being replaced. When the filter paper is saturated Check that the float is functioning with swarf, the water level rises, and correctly.

  • Page 21: Maintenance

    Coolimat-200 Instruction Manual 5. Maintenance To ensure a longer lifetime for your equipment Struers strongly recommends regular cleaning. WARNING! Accumulated dirt and swarf can restrict or cause damage to the water inlet valves. IMPORTANT! Activate the Emergency Stop button to disconnect the power before performing any maintenance work.

  • Page 22: Filter Bag

    Coolimat-200 Instruction Manual  Filter Bag Check and if necessary empty and clean the Filter Bag. − Disconnect the power. − Remove the Filter Bag from the tank and turn it upside down over a waste container of suitable size.

  • Page 23: Replacing The Cooling Fluid

    10. IMPORTANT! Always maintain the correct concentration of Struers Additive, Corrozip-LF, in the cooling water (percentage stated on the container of the Additive). Remember to add Struers Additive each time you refill with water. Weekly  Band Filter Unit Clean all the surfaces in contact with the filter paper.

  • Page 24: Technical Data

    Coolimat-200 Instruction Manual 6. Technical Data Subject Specification Metric/International 200 l Tank Height 292 mm 11.5 “ Width 850 mm 33.5 “ Depth 1283 mm 50.5 “ Volume 200 l 52.8 gallons Band Filter Height with filter paper roll 709 mm 27.9"...

  • Page 25: Declaration Of Conformity

    Director of Business Development Struers ApS Pederstrupvej 84 Date of Issue: 2017.10.05 DK-2750 Ballerup, Denmark For other language versions, please visit Struers.com. Doc. No.: 16167901 For machines produced before the Date of Issue, please contact your Struers supplier. Rev.: A...
  • Page 26  Pederstrupvej 84 DK-2750 Ballerup Denmark...

  • Page 27: Spare Parts And Diagrams

    Coolimat-200 Manual No.: 16167001 Spare Parts and Diagrams Date of Release 2016...
  • Page 28 The manual may mention accessories or parts not included in the present version of the equipment. The contents of this manual are the property of Struers. Reproduction of any part of this manual without the written permission of Struers is not allowed.
  • Page 29 Some of the drawings may contain position numbers not used in connection with this manual. Diagrams Diagram Wiring diagrams Block diagram ..............16163050A Coolimat-200, Block diagram Static filter ....... 16163051A Coolimat-200, Circuit diagram, 2 pages ......16163100E Circuit diagram Static Filter ..........16163101F...

  • Page 30: Float Assembly

    To check the availability of other replacement parts, please contact your local Struers Service Technician. It may help identify the part by referral to its position number on the assembly drawings included in this manual.

  • Page 31: Water Level Indicator, Assembly

    Mains cable. AWG16. Nema 5-15P 2WC02520 W16 Connect.cable.4 p.fem+male 15763516 OMRON J7KNA_09_10_24 RKM70910 Plastic Big Pump Collar 06166905 Water Tank Base Platform R6160130 Loose parts, Coolimat-200 Plastic Bin 400x600x270 RGQ79200 Coolimat-200 Plastic Bag (5pc) 49900057 Dummy connector plug for static filter 16163550...
  • Page 32 e i l o i t t i n t i n : l a : e l o i t e l l...
  • Page 33 o i t t i n t i n : l a : e l o i t e l l...
  • Page 34 i t c o i t t i n t i n : l a : e l c t i o i t e l l...
  • Page 35 . t i . t i o i t t i n t i n : l a : e l o i t e l l...
  • Page 36 . t i . t i t i n o i t t i n : l a : e l o i t e l l...
  • Page 37 e t i e t i o i t t i n t i n : l a : e l o i t e l l...
  • Page 38 ± n i l ÷ / n i l n i f t i n o i t t i n : l a : e l o i t e l l...
  • Page 39 o i t t i n t i n : l a : e l o i t e l l...
  • Page 40 o i t t i n t i n : l a : e l o i t...
  • Page 41 o i t t i n t i n : l a : e l o i t e l l...

  • Page 42: Block Diagram

    Coolimat-200 control box A1 POWER SUPPLY F1 PHASE FUSES PLUG AC Cable gland L + N M2 PUMP 1 F1 + F2 15AT 200W 220/110VAC Out: 24V/8,4A BIMETAL BIMETAL X103 24VDC 100-240V Connector for XPE4 50/60Hz pump 1 MOTOR AC...

  • Page 43: Coolimat-200, Block Diagram Static Filter

    A3 Cooli-1 control box connector 200-240VAC / 4,5A L + N Rev A: RSZ STRUERS A/S Pederstrupvej 84 DK-2750 Ballerup Denmark 100-240V Coolimat-200, Block diagram STATIC FILTER 50/60Hz Size Size Size CAGE Code CAGE Code CAGE Code DWG NO DWG NO...
  • Page 44 W1 Input COOLIMAT-200 CONVEYOR FUSE HOLDERS A1 POWER SUPPLY cabel F1 = F2 = 15AT 24V / rated 3A/ gear 30 RPM Float switch Cover switch 100-240V SP-200-24 50/60Hz 200W PLUG AC 2 x AWG16 24V / 8,4A 1 x AWG16...
  • Page 45 W1 Input COOLIMAT-200 CONVEYOR FUSE HOLDERS A1 POWER SUPPLY cabel F1 = F2 = 15AT 24V / rated 3A/ gear 30 RPM Float switch Cover switch 100-240V SP-200-24 50/60Hz 200W PLUG AC 2 x AWG16 24V / 8,4A 1 x AWG16...
  • Page 46 2 x AWG16 1 x AWG16 AWG16 x 3 mains cable XPE2 XPE3 XPE4 Input cable Front plate Main panel Main panel X5-2 X5-1 COOLIMAT-200 POWER PCB - 16163000 2 x AWG18 220/110VAC Supply for pump COOLIMAT-200 X8-4 POWER +24V X8-2...
  • Page 48  Pederstrupvej 84 DK-2750 Ballerup Denmark...
