- Page 1 SERAPHIM MONOFACIAL PHOTOVOLTAIC MODULE SERAPHIM ENERGY GROUP CO. LTD ADDRESS: Intersection of baimafeng road and Weimin Road, Jinzhai County, Lu'an City, Anhui Province TELEPHONE: +86-0564-7736177 MAILBOX: info@seraphim-energy.com Version: 2024V1.1...
-
Page 2: Table Of Contents
CONTENTS 1 PURPOSE OF THIS GUIDE ........................1 1.1 APPLICABLE PRODUCTS .......................1 2 SAFETY ................................2 2.1 GENERAL SAFETY ..........................2 2.2 HANDLING SAFETY ........................3 2.3 INSTALLATION SAFETY .........................4 2.4 FIRE SAFETY ............................5 3 PRODUCT IDENTIFICATION ........................5 4 MECHANICAL INSTALLATION ......................5 4.1 GENERAL INSTALLATION PRINCIPLE ..................5 4.2 LOCATION AND ANGLE SELECTION ..................6 4.3 MOUNTING WITH CLAMPS ......................6 4.3.1 Install module with clamps at longsides of frames ............8... -
Page 3: Purpose Of This Guide
DUAL GLASS PHO TOVOLTAIC MODULE 1 PURPOSE OF THIS GUIDE We would like to express our sincerest gratitude for choosing Seraphim Photovoltaic Modules (hereafter referred to as “PV Module”), this guide provides detailed information on proper application and installation of Seraphim PV modules. -
Page 4: Safety
SRP-XXX-BMC-HV、SRP-XXX-BTC-HV、 2384*1303 SRP-XXX-BHC-HV NOTE: -HV: Modules with 1500Vdc system design voltage; XXX: Module Power Class Table 1: Seraphim PV module products 2 SAFETY 2.1 GENERAL SAFETY • The PV modules are qualified for class A compliance application for spread of flame, which may be used in systems operating at greater than 50 V DC or 240 W, where general contact access is anticipated. -
Page 5: Handling Safety
INSTALLA TION GUIDE FOR SERAPHIM DUAL GLASS PHO TOVOLTAIC MODULE • One single PV module generates more than 30V DC when exposed to direct sunlight. Access to a DC voltage of 30V or more is potentially hazardous. • PV modules convert light irradiation to DC electrical energy, which are designed for outdoor use. PV modules can be mounted onto ground, rooftop, vehicles or boats etc. -
Page 6: Installation Safety
PV module must be erected onto fixed tilt float where lowest point of module does not pose any risk of direct contact with sea water. • For floating solar installation at coastal line, accelerated aging due to salt mist corrosion onto the anodization of PV modules’ frame and early delamination will not fall under responsibility of Seraphim’s standard warranty. -
Page 7: Fire Safety
Additional Measures Under Warranty ≤50m Not advisable Table 2 Seraphim PV Module Products Coastal Distance Installation Table 2.4 FIRE SAFETY • The fire safety compliance of this PV module is only deemed valid upon which this Guide is strictly followed. -
Page 8: Location And Angle Selection
INSTALLA TION GUIDE FOR SERAPHIM DUAL GLASS PHO TOVOLTAIC MODULE • It is recommended to install the bifacial modules 1m above ground finishing level or 50mm above ridges of metal deck roof to maintain the energy yield of module rear side. - Page 9 INSTALLA TION GUIDE FOR SERAPHIM DUAL GLASS PHO TOVOLTAIC MODULE use a fixture that can hold the M8 bolt at least, with corresponding spring gaskets. Figure 1 and Figure 2 show two different types of press blocks: Figure 1 Single-side clamp...
-
Page 10: Install Module With Clamps At Longsides Of Frames
INSTALLA TION GUIDE FOR SERAPHIM DUAL GLASS PHO TOVOLTAIC MODULE 4.3.1 Install module with clamps at longsides of frames Clamp length≥50mm Module type Module size a*b Mechanical loads (Pa) A=(380-580)mm Downforce load≤5400Pa; 1956*992 SRP-XXX-6PA-HV Uplift load≤2400Pa 1970*992 SRP-XXX-6MA-HV A=(50-580)mm 1985*1002 Downforce load≤2400Pa;... - Page 11 INSTALLA TION GUIDE FOR SERAPHIM DUAL GLASS PHO TOVOLTAIC MODULE A=(300-500)mm SRP-XXX-BPB-HV 1755*1038 Downforce load≤5400Pa; SRP-XXX-BMB-HV Uplift load≤2400Pa A=(300-500)mm Downforce load≤5400Pa; SRP-XXX-BPC-HV Uplift load≤2400Pa 1852*1002 SRP-XXX-BMC-HV A=(50-500)mm Downforce load≤2400Pa; Uplift load≤2400Pa A=(380-580)mm Downforce load≤5400Pa; SRP-XXX-BPZ-HV Uplift load≤2400Pa 2180*1002 SRP-XXX-BMZ-HV A=(50-580)mm Downforce load≤2400Pa;...
- Page 12 INSTALLA TION GUIDE FOR SERAPHIM DUAL GLASS PHO TOVOLTAIC MODULE A=(300-550)mm SRP-XXX-BTD-HV 1962*1134 Downforce load≤5400Pa； Uplift load≤2400Pa A=(220-450)mm SRP-XXX-BTE-HV 1762*1134 Downforce load≤5400Pa； Uplift load≤2400Pa A=(200-400)mm SRP-XXX-BTF-HV 1540*1134 Downforce load≤5400Pa； Uplift load≤2400Pa SRP-XXX-BMB-HV A=(250-440)mm SRP-XXX-BTB-HV 2172*1303 Downforce load≤2400Pa; SRP-XXX-BHB-HV Uplift load≤1800Pa...
-
Page 13: Install Module With Clamps At Short Side Of Frames
INSTALLA TION GUIDE FOR SERAPHIM DUAL GLASS PHO TOVOLTAIC MODULE 4.3.2 Install module with clamps at short side of frames Clamp length≥50mm Module type Module size e*d Mechanical loads (Pa) Monofacil SRP-XXX-BMA-HV 2278*1134 module SRP-XXX-BTA-HV SRP-XXX-BMB-HV 1909*1134 SRP-XXX-BTB-HV SRP-XXX-BMC-HV 2093*1134... - Page 14 INSTALLA TION GUIDE FOR SERAPHIM DUAL GLASS PHO TOVOLTAIC MODULE (8 mounting holes suitable for frame with 8 mounting holes design) (4 mounting holes suitable for frame with 4 mounting holes design) Module type Module size Module type Module size...
-
Page 15: Electrical Installation
INSTALLA TION GUIDE FOR SERAPHIM DUAL GLASS PHO TOVOLTAIC MODULE SRP-XXX-BMB-HV SRP-XXX-BMB-HV SRP-XXX-BTB-HV 2172*1303 SRP-XXX-BTB-HV 2172*1303 SRP-XXX-BHB-HV SRP-XXX-BHB-HV SRP-XXX-BMC-HV SRP-XXX-BMC-HV SRP-XXX-BTC-HV 2384*1303 SRP-XXX-BTC-HV 2384*1303 SRP-XXX-BHC-HV SRP-XXX-BHC-HV Table 6 Schematic diagram of screw installation and mechanical load The details information on screw type installation are illustrated in Figure 5. To ensure that the module can withstand desired mechanical loads, at least four screws should be used to secure the module to the mounting bracket at the long edge. - Page 16 If there is any, it must be cleaned and removed before installation. If the connector is damaged or deformed, the connector must be replaced before use; if there is no spare connector, please contact seraphim in time.
-
Page 17: Grounding
INSTALLA TION GUIDE FOR SERAPHIM DUAL GLASS PHO TOVOLTAIC MODULE Figure 6 Minimum bending radius of cables Remark ： If jumper/conversion cable is needed, see attachment 1 for details. 4.6 GROUNDING Any common grounding hardware and components such as nuts, bolts, star washers, spilt-ring lock washers, flat washers, and other compatible components can be used for grounding or equipotential bonding. -
Page 18: Cleaning
INSTALLA TION GUIDE FOR SERAPHIM DUAL GLASS PHO TOVOLTAIC MODULE charging regulators, inverters, batteries etc. 5.1 Cleaning Use a dry mop to sweep away debris and contaminants on the module surface, such as dry floating dust and leaves. For hardened objects or stains that are tightly attached to the glass surface, such as dirt, bird droppings, and viscous objects, a slightly hard scraper or gauze can be used for scraping, but care must be taken not to use hard abrasive materials to scrape to avoid damaging the glass surface and anti-reflection coating. -
Page 19: Parameters
DUAL GLASS PHO TOVOLTAIC MODULE 6 PARAMETERS The parameters may be updated from time to time, accurate parameters please check out our website at http://www.seraphim-energy.com or email to our technical support team at technic@seraphim-energy.com. [1] REMARK Landscape installation Portrait installation... - Page 20 INSTALLA TION GUIDE FOR SERAPHIM DUAL GLASS PHO TOVOLTAIC MODULE 2. Make sure that the connector on the conversion cable is not detached or loose, and the metal core is not skewed or water stained, etc. 3. Confirm that the cable insulation layer of the conversion cable is not damaged, and the cable is not severely bent or twisted.
