- Page 1 MAGNETIC LIGHTING TRACK SYSTEM EXILITY...
-
Page 2: Table Of Contents
Maytoni Technical www.maytoni.de CONTENTS 1. DESCRIPTION AND APPLICATION OF THE DEVICE..............3 1.1. TECHNICAL DATA..........................3 1.2 DIMENSIONS OF RECESSED MOUNTED MAGNETIC TRACK FOR PLASTERBOARD 9.5 MM......................4 1.3 DIMENSIONS OF RECESSED MOUNTED MAGNETIC TRACK FOR PLASTERBOARD 12.5 MM........................4 1.4 DIMENSIONS OF MAGNETIC SURFACE-MOUNTED/SUSPENDED TRACK....5 2. -
Page 3: Description And Application Of The Device
1. DESCRIPTION AND APPLICATION OF THE DEVICE The TRX034 series magnetic track system is the basis for building track lighting and is designed for mounting and supplying power to track lights in the DC electrical power grid with 48V of nominal voltage. -
Page 4: Dimensions Of Recessed Mounted Magnetic Track For Plasterboard 9.5 Mm
Maytoni Technical www.maytoni.de 1.2 DIMENSIONS OF RECESSED MOUNTED MAGNETIC TRACK FOR PLASTERBOARD 9.5 MM TRX034-421B 31 mm 26,5 mm 23,5 mm 18 mm 62 mm TRX034-421B / TRX034-421W TRX034-421B/TRX034-422B 1.3 DIMENSIONS OF RECESSED MOUNTED MAGNETIC TRACK FOR PLASTERBOARD 12.5 MM... -
Page 5: Dimensions Of Magnetic Surface-Mounted/Suspended Track
Maytoni Technical www.maytoni.de 1.4 DIMENSIONS OF MAGNETIC SURFACE-MOUNTED/SUSPENDED TRACK TRX034-411B 17 mm 1,5 mm 23,5 mm 24 mm 26,2 mm 26 mm h=1000 TRX034-411B / TRX034-411W TRX034-412B / TRX034-412W... -
Page 6: Safe Handling Guidelines
Maytoni Technical www.maytoni.de 2. SAFE HANDLING GUIDELINES All installation and mounting services must be rendered by persons with the appropriate permits and qualifications. Please contact a qualified electrician where necessary. All installation and dismantling work should be performed in a powered down state only. -
Page 7: Recessed Mounted Magnetic Track In Plasterboard
Maytoni Technical www.maytoni.de 3.RECESSED MOUNTED MAGNETIC TRACK IN PLASTERBOARD CEILING 9.5 MM AND 12.5 MM... -
Page 8: System Configuration For Plasterboard 9.5 Mm
Maytoni Technical www.maytoni.de 3.1 SYSTEM CONFIGURATION FOR PLASTERBOARD 9.5 MM SYSTEM ELEMENT COLOR ARTICLE PLUG TRA034EC-42B BLACK TRA034EC-42W WHITE TRACK TRX034-421B BLACK TRX034-422B BLACK INTERNAL RECESSED TRA034CL-42B BLACK ANGLE CONNECTOR RECESSED TRACL034-42B-R BLACK ANGLE CONNECTOR ROUND TRA044-angle BLACK ANGLE CONNECTOR... -
Page 9: System Configuration For Plasterboard 12.5 Mm
Maytoni Technical www.maytoni.de 3.2 SYSTEM CONFIGURATION FOR PLASTERBOARD 12.5 MM SYSTEM ELEMENT COLOR ARTICLE PLUG TRA034EC-42B BLACK TRA034EC-42W WHITE TRACK TRX034-421.12B BLACK TRX034-421.12W WHITE TRACK TRX034-422.12B BLACK TRX034-422.12W WHITE T-ANGLE CONNECTOR TRA034CT-42.12B BLACK TRA034CT-42.12W WHITE RECESSED TRA034CL-42.12B BLACK ANGLE TRA034CL-42.12W... - Page 10 Maytoni Technical www.maytoni.de 4. SYSTEM CON FIGUR ATION FOR MAGNETIC TRACK SYSTEM INSTALLED IN PLASTERBOARD SYSTEM ELEMENT COLOR ARTICLE SIZE TRX034-421B H46 X W62 X L1000 BLACK RECESSED MOUNTED TRACK FOR BLACK TRX034-422B H46 X W62 X L2000 PLASTERBOARD 9.5 MM* BLACK TRX034-421.12B...
-
Page 11: In Plasterboard
Maytoni Technical www.maytoni.de 5.SCHEMATIC FOR TRACK INSTALLATION IN PLASTERBOARD 9.5 MM AND 12.5 MM Attention! A recessed mounted track for installation in a plasterboard ceiling can be mounted using 1 or 2 layers of plasterboard. -
Page 12: System Elements
Maytoni Technical www.maytoni.de 6. SYSTEM ELEMENTS 6.1 POWER CONNECTORS SYSTEM ELEMENT COLOR ARTICLE SIZE STRAIGHT POWER TRA034PC-42B H18.2*W16.4*L138 BLACK CONNECTOR TRA034PC-42W H18.2*W16.4*L138 WHITE ANGLE FLEXIBLE TRA034CPC- 42B-15 H18.2*W16.4*L92.7 BLACK POWER CONNECTOR 15 CM ANGLE FLEXIBLE TRA034CPC- 42B-15-1 H19*W17*L260 BLACK POWER CONNECTOR... -
Page 13: Mechanical Connectors For 9.5 Mm Plasterboard Track
Maytoni Technical www.maytoni.de 6.2 MECHANICAL CONNECTORS FOR 9.5 MM PLASTERBOARD TRACK SYSTEM ELEMENT COLOR ARTICLE SIZE ANGLE TRACL034-42B-R H46*W100*L100 BLACK CONNECTOR INTERNAL ANGLE TRA034CL-42B H46*W100*L100 BLACK CONNECTOR ROUND ANGLE TRA044-ANGLE H46*W300*L470 BLACK CONNECTOR STRAIGHT CONNECTOR TRA034C-42S H1*W12*L70 SILVER (2 EA) 6.3 MECHANICAL CONNECTORS FOR 12.5 MM PLASTERBOARD TRACK... -
Page 14: Power Supplies
Maytoni Technical www.maytoni.de 6.4 POWER SUPPLIES SYSTEM ELEMENT COLOR ARTICLE SIZE POWER SUPPLY TRX034DR4-100B H42*W22*L250 BLACK TRX034DR4-200B H42*W22*L330 BLACK TRX034DR4-100W H42*W22*L250 WHITE TRX034DR4-100W H42*W22*L330 WHITE TRX004DR-100S H30*W97*L129 SILVER TRX004DR-150S H30*W97*L159 SILVER TRX004DR-200S H30*W115*L215 SILVER TRX004DR-350S H30*W115*L215 SILVER... -
Page 15: Procedure For Track Installation On Plasterboard Ceilig
Maytoni Technical www.maytoni.de 7. PROCEDURE FOR TRACK INSTALLATION ON PLASTERBOARD CEILING 1. Cut the track according to the design dimensions after removing the conductor runs. Cutting can be done at any place and angle. Cut the track with a miter saw. - Page 16 Maytoni Technical www.maytoni.de 3. Drill the power cable entry holes and remove the chamfers. 4. Connect the track sections using connectors and install the plugs. Pack the track in extruded polystyrene foam immediately after installation to protect it from deformation and dust during the remaining period of installation activities...
- Page 17 Maytoni Technical www.maytoni.de 5. Install the ceiling profile in accordance with the required dimensions. 6. Insert the supply wire into the track and connect it to the power input or the recessed power supply 7. Install the track into the mounting slot and secure it with screws.
- Page 18 Maytoni Technical www.maytoni.de 8. Install the plasterboard close to the track walls and secure it with screws. Bond a layer of fiberglass mesh. Cover the plasterboard with putty to make level with the track walls.
-
Page 19: Surface-Mounted/Suspended Magnetic Track
Maytoni Technical www.maytoni.de 8. SURFACE-MOUNTED/SUSPENDED MAGNETIC TRACK 8.1 SCHEMATIC FOR SURFACE-MOUNTED/SUSPENDED MAGNETIC TRACK... -
Page 20: Surface-Mounted/Suspended Magnetic Track System Elements
Maytoni Technical www.maytoni.de 8.2 SURFACE-MOUNTED/SUSPENDED MAGNETIC TRACK SYSTEM ELEMENTS *Two plugs and a decorative moulding are included. SYSTEM ELEMENT COLOR ARTICLE SIZE TRACK TRX034-411B 1000*26*52 BLACK TRX034-412B 2000*26*52 BLACK TRX034-413B 3000*26*52 BLACK TRX034-411W 1000*26*52 WHITE TRX034-412W 2000*26*52 WHITE TRX034-413W 3000*26*52... -
Page 21: System Configuration Of Magnetic Surface-Mounted/Suspended Track
Maytoni Technical www.maytoni.de 9. SYSTEM CONFIGURATION OF MAGNETIC SURFACE-MOUNTED/ SUSPENDED TRACK 9.1 MECHANICAL CONNECTIONS FOR MAGNETIC SURFACE-MOUNTED/SUSPENDED TRACK SYSTEM ELEMENT COLOR ARTICLE SIZE RETAINER TRA034HS-21B 6*60*38 mm BLACK FOR SURFACE TRA034HS-21W 6*60*38 mm WHITE MOUNTING STRAIGHT TRA034C-21B 80*2*22.5 mm BLACK... -
Page 22: Procedure For Installing Surface-Mounted/Suspended Magnetic Track On Surface Using Brackets
Maytoni Technical www.maytoni.de 10. PROCEDURE FOR INSTALLING SURFACE-MOUNTED/SUSPENDED MAGNETIC TRACK ON SURFACE USING BRACKETS 10.1 PROCEDURE FOR INSTALLING SURFACE-MOUNTED MAGNETIC TRACK USING BRACKETS 1. Cut the track according to the design dimensions. Cutting can be done at any place at an angle of 90 degrees. -
Page 23: Procedure For Installing A Suspended Magnetic Track
Maytoni Technical www.maytoni.de 10.2 PROCEDURE FOR INSTALLING A SUSPENDED MAGNETIC TRACK 1. Screw the suspensions into the base. 2. Install the suspensions in the groove on the back of the track. 3. Secure the cable holder. Insert the cables into the holders. Adjust the length of the suspensions. -
Page 24: Connecting Power Supply To Magnetic Surface-Mounted/Suspended Track Using External Power Supply
Maytoni Technical www.maytoni.de 10.3 CONNECTING POWER SUPPLY TO MAGNETIC SURFACE-MOUNTED/SUSPENDED TRACK USING EXTERNAL POWER SUPPLY 1. Prepare a niche, place the power supply in it and connect the wires of the 230V 50Hz mains to it. 2. Connect the power supply to the 230V 50Hz mains according to the markings on it. The power reserve of the power supply must be at least 20%. -
Page 25: Connecting Digital Dali Protocol To Magnetic Track
Maytoni Technical www.maytoni.de 1. Connect the track power supply to the mains according to the marking on the input cable (G – ground, L – phase, N – neutral). Connect with the mains switched off. 2. Place the assembled connection in the track housing. -
Page 26: Recommendations
Maytoni Technical www.maytoni.de 11. RECOMMENDATIONS 1. When planning the placement of system elements, be sure to include an inspection hatch in the project to service the driver. 2. Do not deform the track during transport and installation. 3. When cutting track, use professional equipment, or use the services of an organisation providing such services. -
Page 27: Additional Information
Maytoni Technical www.maytoni.de 12. ADDITIONAL INFORMATION 12.1 TROUBLESHOOTING Fault description Cause Troubleshooting Install the lamp on the track until the adapter is in full contact with the current-carrying cores Loose connection of current- carrying parts Check the input cable connection... -
Page 28: Storage
12.7 MANUFACTURER Maytoni GmbH, Feldstiege 98, Münster, Germany, 48161 12.8 IMPORTER Maytoni GmbH, Feldstiege 98, Münster, Germany, 48161 www.maytoni.de Developed in Germany. - Page 29 +49 (0) 2533 64 295200 info@maytoni.com...
