Omron NB5Q Series Instruction Manual

Omron NB5Q Series Instruction Manual

Operator panel for volumetric doser machine gorreri dvg500rp
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GORRERI S.r.l.
via Cisa, 172 - 42041 Sorbolo Levante di Brescello (RE) Italy
+39.0522.680853 - Fax +39.0522.680687 - 
www.gorreri.com
OPERATOR
PANEL
OMRON
Mod. NB5Q
INSTRUCTION MANUAL
VOLUMETRIC DOSER MACHINE
Mod. DVG500RP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NB5Q Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Omron NB5Q Series

Summary of Contents for Omron NB5Q Series

  • Page 1 GORRERI S.r.l. via Cisa, 172 - 42041 Sorbolo Levante di Brescello (RE) Italy +39.0522.680853 - Fax +39.0522.680687 -  www.gorreri.com OPERATOR PANEL OMRON Mod. NB5Q INSTRUCTION MANUAL VOLUMETRIC DOSER MACHINE Mod. DVG500RP...
  • Page 3 O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 3/24 "...

  • Page 4: General Information

    GENERAL INFORMATION This manual contains all necessary information about the correct use of the Control Panel " OMRON NB5Q". It needs, therefore, to be read carefully before carrying out any kind of operation. This manual completes the Machine; it must be kept all through the Machine life and it must necessarily follow the Machine itself in its possible changes of property;...
  • Page 5 O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 5/24 PRESENTATION AND CONSULTATION OF THE MANUAL ...
  • Page 6 O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 6/24 GLOSSARY Operator...
  • Page 7 O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 7/24 STAFF, TASKS, WORKING AREAS The following skilled worker figure has been determined for the use of the...

  • Page 8: Use Instructions

    O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 8/24 USE INSTRUCTIONS INITIAL PAGE...
  • Page 9 O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 9/24 MANI PAGE This page shows the access buttons to the different functions menu.

  • Page 10: Alarms Page

    O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 10/24 ALARMS PAGE In the Alarms page, it is possible to check which alarms are activated on the...
  • Page 11 O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 11/24 Explanation of the main alarms which can be displayed on the Machine: ...

  • Page 12: Manual Controls

    O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 12/24 MANUAL CONTROLS In the Manual Controls pages, it is possible to set up and execute the...
  • Page 13 O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 13/24 5.5.2 MANUAL CONTROLS –...
  • Page 14 O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 14/24 5.6.1 ACTUAL RECIPE...
  • Page 15 O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 15/24 5.6.2 ACTUAL RECIPE...
  • Page 16 O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 16/24 5.6.3 ACTUAL RECIPE...
  • Page 17 O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 17/24 RECIPES EDITOR –...
  • Page 18 O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 18/24 RECIPES EDITOR MANAGEMENT Pic.

  • Page 19: Recipe Selection

    O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 19/24 RECIPE SELECTION RECIPE means the ensemble of parameters which define the behaviour of...
  • Page 20 O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 20/24 TO EDIT RECIPE The modification of a recipe parameters is possible only in pages protected...

  • Page 21: Recipe Editor

    O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 21/24 5.8.1 RECIPE EDITOR...
  • Page 22 O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 22/24 5.8.2 RECIPE EDITOR...
  • Page 23 O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 23/24 5.8.3 RECIPE EDITOR...

  • Page 24: Actual Temperature

    O p e r a t o r P a n e l V O L UM E T R I C D O S E R M AC H I N E – M o d . D V G 5 0 0 R P – OM R O N N B 5 Q 24/24 5.8.3 HEATING...
