Philips dynalite DDMIDC8 Installation Instructions
Philips dynalite DDMIDC8 Installation Instructions

Philips dynalite DDMIDC8 Installation Instructions

Advertisement

Quick Links

DDMIDC8
Low Level Input
Integrator
Devices must be installed in an
approved enclosure by a qualified
electrician in accordance with all
national and local electrical and
construction codes and regulations.
Les appareils doivent être installés dans un lieu jugé
apte, par un électricien qualifié et conformément
aux règles et normes locales et nationales en
matière d'électricité et de construction.
Die Geräte müssen von einem geprüften Elektriker
entsprechend allen nationalen und lokalen Elektro
– und Bauvorschriften in einem zugelassenen
Gehäuse installiert werden.
1
IEC Pollution Degree II
Los dispositivos se deben instalar en un recinto
aprobado por un electricista cualificado de acuerdo
a todos los reglamentos eléctricos y de construcción
locales y nacionales pertinentes
I dispositivi devono essere installati da un
elettricista qualificato in un luogo approvato, in
conformità a tutti gli standard e le norme nazionali
e locali vigenti in materia di impianti elettrici e
costruzioni edilizie.
Apparaten moeten door een erkende elektricien
worden geïnstalleerd in een goedgekeurde
behuizing in overeenstemming met alle nationale
en lokale elektriciteits – en bouwvoorschriften
en wetgeving.
RJ12
2
45 mm
(1.77 in)
45 mm
(1.77 in)
12 V
≤ 68 mA
IEC Overvoltage Category III
50° C (122° F)
0° C (32° F)
Installation Instructions
Instructions d'installation
Installationsanweisungen
Instrucciones de instalación
Istruzioni per l'installazione
Installatie-instructies
インストール手順
安装指南
デバイスを取り付ける際は、 資格のある電気技師に依頼
し、 電気と建設に関する国および地域のすべての法令に
従って、 認可されている筐体内に取り付けてください。
根据国家/地区及当地的电气与建筑规范和法规,该设
备必须由有资质的电工安装在经批准的外罩内。
59 mm (2.32 in)
105 mm (4.13 in)
10-24 V
µP
RS-485 DyNet
≤90%
75 mm (2.95 in)
0-5/0-10 V
≤ 0.5 mA
