- Page 1 Nomadic 270LTE Awning CAREFULLY READ INSTRUCTIONS PRIOR TO THE FIRST USE OF THE 270LTE AWNING...
- Page 2 Nomadic 270LTE Awning SET-UP & CARE INSTRUCTIONS GET TO KNOW YOUR AWNING We recommend you check all parts are included prior to first use. Box 1 Box 2 Tools needed 1 270LTE Awning 2 x L shaped mounting brackets 4 x short bolts and nuts...
-
Page 3: Remove Cover
Nomadic 270LTE Awning SET-UP & CARE INSTRUCTIONS SET-UP REMOVE COVER Unzip cover and fold it over the awning body RELEASE AWNING Release the three Velcro straps and allow canvas to drape... - Page 4 Nomadic 270LTE Awning SET-UP & CARE INSTRUCTIONS SET-UP OPENING To begin setting up the awning follow steps 1 to 4 Awning will self-support during set up only however it is not advisable to leave the awning hanging for any long period of time.
- Page 5 Nomadic 270LTE Awning SET-UP & CARE INSTRUCTIONS SET-UP POLE SET-UP • Undo the hook and loop fasteners that are supporting each leg. Be careful as the legs will drop down. Ensure no person or item is under or near the awning when doing this.
- Page 6 Nomadic 270LTE Awning SET-UP & CARE INSTRUCTIONS PACK-DOWN • Undo all pegs / guy ropes • Fold away legs and stow away using attached Velcro straps • Stow 3 x additional legs in canvas carry bag. • Release front and rear tension strap.
- Page 7 • TO AVOID CHANCES OF PERSONAL INJURY AND not covered under warranty. PROPERTY DAMAGE, WE HIGHLY RECOMMEND THE STRUCTUAL INTEGRITY NOMADIC 270LTE AWNING SHOULD NOT BE ERECTED DURING WINDY CONDITIONS. The 270LTE awning has been designed for general camping use under normal conditions.
