Summary of Contents for AEG BP1531310

  • Page 1 User Manual BP1531310 Oven...

  • Page 2: Table Of Contents

    13. ENERGY EFFICIENCY....................33 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference.

  • Page 4: Safety Instructions

    Ensure that the appliance is switched off before • replacing the lamp to avoid the possibility of electric shock. Do not use a steam cleaner to clean the appliance. • Do not use harsh abrasive cleaners or sharp metal •...
  • Page 5 ENGLISH • Connect the mains plug to the mains • Do not put flammable products or socket only at the end of the items that are wet with flammable installation. Make sure that there is products in, near or on the appliance. access to the mains plug after the WARNING! installation.

  • Page 6: Pyrolytic Cleaning

    • Make sure the appliance is cold. – provide good ventilation during There is the risk that the glass panels and after each Pyrolytic cleaning. can break. – provide good ventilation during • Replace immediately the door glass and after the first use at maximum panels when they are damaged.

  • Page 7: Product Description

    ENGLISH • Remove the door catch to prevent • Use original spare parts only. children and pets to get closed in the appliance. 2.8 Service • To repair the appliance contact an Authorised Service Centre. 3. PRODUCT DESCRIPTION 3.1 General overview Control panel Knob for the oven functions Power lamp / symbol / indicator...

  • Page 8: Before First Use

    4. BEFORE FIRST USE 2. Press to confirm. This is necessary WARNING! only when you set the time for the Refer to Safety chapters. first time. Later the new time will be saved automatically after 5 seconds. 4.1 Initial Cleaning...

  • Page 9: Oven Functions

    ENGLISH 2. Turn the knob for the temperature to 3. To deactivate the appliance turn the select a temperature. knobs for the oven functions and temperature to the off position. 5.3 Oven functions Oven function Application Off position The appliance is off. Fast Heat Up To decrease the heat-up time.

  • Page 10: Heat-Up Indicator

    5.5 Display A) Timer B) Heat-up and residual heat indicator C) Water drawer (selected models only) D) Core temperature sensor (selected models only) E) Door lock (selected models only) F) Hours / minutes G) Clock functions 5.6 Buttons Button...

  • Page 11: Setting The Minute

    ENGLISH Clock function Application To set when the appliance must deactivate. Use only when an oven function is set. You can use Duration and End at the same time (time delay), if the appliance is to be activate and deactivate automatically later. and "00"...

  • Page 12: Using The Accessories

    7. USING THE ACCESSORIES WARNING! Refer to Safety chapters. 7.1 Inserting the accessories Wire shelf: Push the shelf between the guide bars of the shelf support and make sure that the feet point down. • All accessories have small...

  • Page 13: Additional Functions

    ENGLISH Baking tray or deep pan: Put the wire shelf on the deep pan. Put the wire shelf and the deep pan on the Put the baking tray or deep pan on the telescopic runners. telescopic runners. Wire shelf and deep pan together: 8.

  • Page 14: Cooling Fan

    8.5 Cooling fan Temperature (°C) Switch-off time (h) When the appliance operates, the cooling fan activates automatically to 30 - 115 12.5 keep the surfaces of the appliance cool. 120 - 195 If you deactivate the appliance, the cooling fan can continue to operate until 200 - 245 the appliance cools down.

  • Page 15: Baking On One Level

    ENGLISH Baking results Possible cause Remedy The cake sinks and becomes The oven temperature is too The next time you bake, set soggy, lumpy or streaky. high. a slightly lower oven temper- ature. The cake sinks and becomes The baking time is too short. Set a longer baking time. soggy, lumpy or streaky.
  • Page 16 Food Function Temperature Time (min) Shelf position (°C) Flan base - True Fan Cook- 150 - 170 20 - 25 sponge mixture Apple pie / Ap- True Fan Cook- 60 - 90 ple pie (2 tins Ø20 cm, diago-...
  • Page 17 ENGLISH Food Function Temperature Time (min) Shelf position (°C) Fruit flans (made True Fan Cook- 35 - 55 with yeast dough / sponge mixture) Fruit flans (made Conventional 35 - 55 with yeast Cooking dough / sponge mixture) Fruit flans made True Fan Cook- 160 - 170 40 - 80...

  • Page 18: Bakes And Gratins

    Food Function Temperature Time (min) Shelf position (°C) Puff pastries True Fan Cook- 20 - 30 170 - 180 Rolls True Fan Cook- 10 - 25 Rolls Conventional 10 - 25 190 - 210 Cooking Small cakes / True Fan Cook-...

  • Page 19: Pizza Setting

    ENGLISH Cakes / pastries / breads on baking trays Food Temperature Time (min) Shelf position (°C) 2 positions 3 positions Cream puffs / 25 - 45 1 / 4 160 - 180 Eclairs Dry streusel 150 - 160 30 - 45 1 / 4 cake 1) Preheat the oven.

  • Page 20: Roasting Tables

    Food Temperature (°C) Time (min) Shelf position Tarts 180 - 200 40 - 55 Spinach flan 160 - 180 45 - 60 Quiche Lorraine 170 - 190 45 - 55 Swiss Flan 170 - 190 45 - 55 Cheesecake...
  • Page 21 ENGLISH Food Quantity Function Tempera- Time (min) Shelf posi- ture (°C) tion Roast beef or fil- per cm of Turbo Grill- 5 - 6 190 - 200 let: rare thickness Roast beef or fil- per cm of Turbo Grill- 6 - 8 180 - 190 let: medium thickness...
  • Page 22 Game Food Quantity Function Temperature Time (min) Shelf posi- (°C) tion Saddle / Leg up to 1 kg Conventional 30 - 40 of hare Cooking Saddle of 1.5 - 2 kg Conventional 210 - 220 35 - 40 venison...

  • Page 23: Frozen Foods

    ENGLISH Grilling Food Temperature Time (min) Shelf position (°C) 1st side 2nd side Roast beef 210 - 230 30 - 40 30 - 40 Filet of beef 20 - 30 20 - 30 Back of pork 210 - 230 30 - 40 30 - 40 Back of veal 210 - 230...
  • Page 24 Food Temperature (°C) Time (min) Shelf position Hash Browns 210 - 230 20 - 30 Lasagne / Cannello- 170 - 190 35 - 45 ni, fresh Lasagne / Cannello- 160 - 180 40 - 60 ni, frozen Oven baked cheese...

  • Page 25: Preserving - Bottom Heat

    ENGLISH Food Quantity Defrosting Further de- Comments time (min) frosting time (min) Trout 150 g 25 - 35 10 - 15 Strawber- 300 g 30 - 40 10 - 20 ries Butter 250 g 30 - 40 10 - 15 Cream 2 x 200 g 80 - 100...

  • Page 26: Drying - True Fan Cooking

    Food Temperature (°C) Cooking time until Continue to cook at simmering (min) 100 °C (min) Mixed pickles 160 - 170 50 - 60 5 - 10 Kohlrabi / Peas / As- 160 - 170 50 - 60 15 - 20 paragus 1) Leave standing in the oven after it is deactivated.

  • Page 27: Removing The Shelf Supports

    ENGLISH • Clean all accessories after each use Do not start the Pyrolysis if and let them dry. Use a soft cloth with you did not fully close the warm water and a cleaning agent. oven door. In some models, •...

  • Page 28: Removing And Installing The Door

    10.5 Removing and installing the door You can remove the door and the internal glass panels to clean it. The number of glass panels is different for different models. WARNING! Be careful when you remove 9. Clean the glass panel with water and the door from the appliance.

  • Page 29: Troubleshooting

    ENGLISH 11. TROUBLESHOOTING WARNING! Refer to Safety chapters. 11.1 What to do if... Problem Possible cause Remedy The oven does not heat up. The oven is deactivated. Activate the oven. The oven does not heat up. The clock is not set. Set the clock.

  • Page 30: Service Data

    Problem Possible cause Remedy The display shows an error There is an electrical fault. • Deactivate the oven with code that is not in this table. the house fuse or the safety switch in the fuse box and activate it again.
  • Page 31 ENGLISH min. 50 mm min. 550 min. 550 min. 560 min. 560...
  • Page 32 100 max. R1200 mm H05VV-F H05RR-F min. 1600 mm 90° 2x3,5x25...

  • Page 33: Energy Efficiency

    ENGLISH 13. ENERGY EFFICIENCY 13.1 Product Fiche and information according to EU 65-66/2014 Supplier's name Model identification BP1531310M Energy Efficiency Index 103.5 Energy efficiency class Energy consumption with a standard load, conven- 0.99 kWh/cycle tional mode Energy consumption with a standard load, fan-forced 0.88 kWh/cycle mode Number of cavities...

  • Page 34: Environment Concerns

    14. ENVIRONMENT CONCERNS marked with the symbol with the Recycle the materials with the symbol household waste. Return the product to Put the packaging in applicable your local recycling facility or contact containers to recycle it. Help protect the your municipal office.
  • Page 35 ENGLISH...
  • Page 36 www.aeg.com/shop...

This manual is also suitable for:

Bp1531310m
