  • Page 1 Owner’s Manual MSX GROM Please read this manual carefully before riding MSX125R...
  • Page 2 How can you contact to CR Section? Customer can contact to CR by the following: : 010 922 922 E-mail : cr@ncxhonda.com.kh Working Hours : 08:00AM-05:00PM Working Days : Every Monday to Saturday cr@ncxhonda.com (except National Holidays and Honda Cambodia – NCX Company Holiday) www.ncxhonda.com hondacambodiancx...
  • Page 3 This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.
  • Page 5 Congratulations on your purchase of a new The following codes in this manual ● Honda vehicle. Your selection of a Honda indicate each destination. makes you part of a worldwide family of The illustrations here in are based on the ●...
  • Page 6 A Few Words About Safety DANGER Your safety, and the safety of others, is very important. Operating this vehicle safely is an You WILL be KILLED or SERIOUSLY important responsibility. HURT if you don’t follow instructions. To help you make informed decisions about safety, we have provided operating WARNING procedures and other information on safety...

  • Page 7: Table Of Contents

    Contents Vehicle Safety P. 2 Operation Guide P. 16 Maintenance P. 49 Troubleshooting P. 79 Information P. 90 Specifications P. 102 Index P. 105...

  • Page 8: Vehicle Safety

    Vehicle Safety This section contains important information for safe riding of your vehicle. Please read this section carefully. Safety Guidelines ..........P. 3 Image Labels............P. 6 Safety Precautions..........P. 8 Riding Precautions ..........P. 9 Accessories & Modifications......P. 13 Loading ..............

  • Page 9: Safety Guidelines

    Safety Guidelines Safety Guidelines Before Riding Make sure that you are physically fit, mentally Follow these guidelines to enhance your safety: focused, and free of alcohol and drugs. Check Perform all routine and regular inspections ● that you and your passenger are both wearing specified in this manual.
  • Page 10 Safety Guidelines Make Yourself Easy to See Keep Your Honda in Safe Condition Make yourself more visible, especially at night, It's important to keep your vehicle properly by wearing bright reflective clothing, positioning maintained and in safe riding condition. yourself so other drivers can see you, signaling...

  • Page 11: Carbon Monoxide Hazard

    Safety Guidelines If you decide to continue riding, first turn the Never run your vehicle inside a garage or other ignition switch to the (Off) position, and enclosure. evaluate the condition of your vehicle. Inspect WARNING for fluid leaks, check the tightness of critical nuts Running the engine of your vehicle and bolts, and check the handlebar, control levers, brakes, and wheels.

  • Page 12: Image Labels

    Image Labels Image Labels The following pages describe the label Read instructions contained in Owner's meanings. Some labels warn you of Manual carefully. potential hazards that could cause serious injury. Others provide important safety Read instructions contained in Shop Manual information.
  • Page 13 Image Labels BATTERY LABEL DANGER • Keep flame and spark away from the battery. Battery produce explosive gas that can cause explosion. • Wear the eye protection and rubber gloves when handling the battery, or you can get burned or lose your eyesight by the battery electrolyte.

  • Page 14: Safety Precautions

    Safety Precautions Safety Precautions Face shield with unobstructed field of vision ● or other approved eye protection Ride cautiously and keep your hands on the ● WARNING handlebar and feet on the footpegs. Instruct your passenger to keep their hands Not wearing a helmet increases the ●...

  • Page 15: Riding Precautions

    Riding Precautions Riding Precautions Jacket and Trousers Protective, highly visible, long-sleeved jacket and durable trousers for riding (or a protective Running-in Period suit) During the first 500 km (300 miles) of running, follow these guidelines to ensure your vehicle's future reliability and performance. Avoid full-throttle starts and rapid ●...
  • Page 16 Riding Precautions Anti-lock Brake System (ABS) on Front Brakes Wheel Observe the following guidelines: II TH type Avoid excessively hard braking and ● This model equipped with an Anti-lock Brake downshifting. System (ABS) designed to help prevent the front Sudden braking can reduce the vehicle's brake from locking up during hard braking.
  • Page 17 Riding Precautions Engine Braking Parking Engine braking helps slow your vehicle down Park on a firm, level surface. ● when you release the throttle. For further If you must park on a slight incline or loose ● slowing action, downshift to a lower gear. Use surface, park so that the vehicle cannot engine braking with intermittent use of the move or fall over.
  • Page 18 Riding Precautions Turn the handlebar fully to the left. Refuelling and Fuel Guidelines Turning the handlebar to the right Follow these guidelines to protect the engine, reduces stability and may cause the fuel system and catalytic converter: vehicle to fall. Use only unleaded petrol.

  • Page 19: Accessories & Modifications

    We strongly advise that you do not add any seriously hurt or killed. accessories that were not specifically designed for your vehicle by Honda or make Follow all instructions in this owner's modifications to your vehicle from its original manual regarding accessories and design.

  • Page 20: Loading

    Loading Loading WARNING Overloading or improper loading can Carrying extra weight affects your vehicle's ● cause a crash and you can be seriously handling, braking and stability. hurt or killed. Always ride at a safe speed for the load you are carrying.

  • Page 22: Basic Operation Flow

    Basic Operation Flow Pre-ride Inspection (P.54) Acceleration Carefully inspect your vehicle to make sure that it is safe to ride. Apply throttle gradually. Obey the speed limit. Shift Change (P.45) Starting the Engine (P.43) Start and warm the engine. Avoid revving the engine. Starting the Vehicle How to use basic features.

  • Page 23: Turning Corners

    Parking (P.11) Braking Close the throttle and apply the front and rear brakes together. Park on a firm level surface. Use the stand, and lock the The brakelight will indicate that steering. you have applied the brakes. Stopping If pulling off the road, signal early enough to show traffic that you are pulling over, and pull over smoothly.

  • Page 24: Parts Location

    Parts Location Tool kit (P.65) Document bag (P.48) Fuse box (P.88) Battery (P.66) Rear brake fluid reservoir (P.70) Front brake fluid reservoir (P.70) Front brake lever Throttle grip (P.78) Engine oil fill cap (P.68) Rear brake pedal Engine oil level inspection window (P.68) Brakelight switch (P.72)
  • Page 25 Clutch lever (P.75) Fuel fill cap (P.46) Seat (P.67) Helmet holder (P.47) Seat lock (P.67) Drive chain (P.74) Side stand (P.73) Shift lever (P.45)
  • Page 26 Instruments Tachometer NOTICE Do not operate the engine in the tachometer red zone. Excessive engine speed can adversely affect engine life. Tachometer red zone (excessive engine rpm range) button button Display Check When the ignition switch is turned to the (On) position, all the mode and digital segments will show.
  • Page 27 Clock (12-hour display) To set the clock: (P.29) Odometer [TOTAL] and Tripmeter [TRIP A/B] (P.22) Gear position indicator The gear position is shown in the gear position indicator. “-” appears when the transmission is not shifted properly. Speedometer Average fuel mileage [AVG] , Fuel consumption, and Average speed [AVG] (P.24) Fuel gauge...
  • Page 28 Instruments (Continued) Odometer [TOTAL] and Tripmeter [TRIP A/B] button switches between the odometer, tripmeter A, and tripmeter B. Odometer Tripmeter A Tripmeter B Odometer [TOTAL] Total distance ridden. When “ ” is displayed, go to your dealer for service. Tripmeter [TRIP A/B] Distance ridden since tripmeter was reset.
  • Page 29 To reset the tripmeter B, average fuel To reset the tripmeter [TRIP A/B], mileage B, fuel consumption B and average average fuel mileage [AVG], fuel speed B (these are based on tripmeter B) consumption and average speed [AVG] together, press and hold the button To reset the tripmeter A, average fuel while tripmeter B is displayed.
  • Page 30 Instruments (Continued) Average fuel mileage [AVG] , Fuel consumption, and Average speed [AVG] button switches between the average fuel mileage, fuel consumption, and average speed. Average fuel mileage Fuel consumption Average speed...
  • Page 31 Display range: 0.0 to 299.9 km/L (L/100km) Average fuel mileage [AVG] • More than 299.9 km/L (L/100km): “299.9” Displays the average fuel mileage since the is displayed selected tripmeter was reset. The average fuel mileage will be calculated • When the tripmeter A or B is reset: “ ”...
  • Page 32 Instruments (Continued) Fuel consumption Displays the fuel consumption since the selected tripmeter was reset. The fuel consumption will be calculated based on value displayed on the tripmeter (A or B) selected. Also, the fuel consumption for tripmeter A will be displayed when the odometer and tripmeter A are selected.
  • Page 33 Display range: 0 to 199 km/h Average speed [AVG] • Initial display: “---” is displayed. Displays the average speed since the selected tripmeter was reset. • When your vehicle has traveled less than The average speed will be calculated based 0.2 km since the engine was started: “---”...
  • Page 34 Instruments (Continued) Display Setting Setting Mode A Following items can be changed sequentially. (P.29) • Clock setting • Backlight brightness adjustment • Unit setting Setting Mode B Following items can be changed sequentially. (P.32) • Setting of REV indicator (lighting RPM setting, lighting interval RPM setting and brightness adjustment) •...
  • Page 35 1 Clock setting: Setting Mode A Turn the ignition switch to the (On) If the button is not pressed for about 30 position. seconds, the control is automatically switched Press and hold the and the from the setting mode to the ordinary buttons until the hour digits start flashing.
  • Page 36 Instruments (Continued) Press the button until the desired 2 Backlight brightness adjustment: minute is displayed. You can adjust the brightness to one of five Press and hold the button to levels. advance the minute fast. Press the button. The brightness is switched.

  • Page 37: Unit Setting

    3 Unit setting: You can change the fuel mileage meter units. Select the “L/100km” or “km/L” using the button. Continued...
  • Page 38 Instruments (Continued) 1 Setting of REV indicator: Setting Mode B Initial setting If the button is not pressed for about 30 blinking RPM: 7,500 r/min (rpm) seconds, the control is automatically switched interval RPM: 250 r/min (rpm) from the setting mode to the ordinary display.
  • Page 39 You can change the setting of the REV and the numerical tachometer display shows indicator. Tachometer bar segment is displayed as REV indicator is blinking while setting. conventional display, regardless of set up button REV indicator display method. Each time button is pressed, the lighting RPM set value increase by 250 r/min (rpm) (one segment).
  • Page 40 Instruments (Continued) Press the button. The REV indicator lighting RPM is set, and then the display moves to the setting of REV indicator lighting interval RPM. Tachometer At the same time, the blinking bar segment shows the currently applied setting originated from the REV indicator Numerical tachometer lighting RPM and the numerical display...
  • Page 41 Press the button. The REV indicator Ex When REV indicator lighting RPM is set at lighting interval RPM is set, and then the 8,000 r/min (rpm) and REV indicator display moves to the brightness adjustment lighting interval RPM is 250 r/min (rpm). of the REV indicator.
  • Page 42 Instruments (Continued) 2 Changing of tachometer display Conventional Tachometer bar mode: display segment Press the button to switch the display mode of tachometer. Press the button. The currently selected displaying mode is set, and the control returns to the ordinary display. Peak hold Conventional display display...
  • Page 43 Indicators If one of these indicators does not come on when it should, have your dealer check for problems. II TH type ABS (Anti-lock Brake System) indicator Comes on when the ignition switch is turned to the (On) position. Goes off when your speed reaches approximately 10 km/h (6 mph).
  • Page 44 Indicators (Continued) Neutral indicator High beam indicator Comes on when the transmission is in Neutral. Left turn signal indicator Right turn signal indicator REV indicator (P.32) Comes on briefly when the ignition switch is turned to the (On) position.
  • Page 46 Switches Engine stop switch Should normally remain in the (Run) position. In an emergency, switch to (Off) position (the starter motor will not operate) to stop the engine. Start button Turn signal switch Pressing the switch turns the turn signal off. CA type Lighting switch Horn button...

  • Page 47: Ignition Switch

    Ignition switch Switches the electrical system on/off, locks the steering. Key can be removed when in the (Off) or (Lock) position. (On) Turns electrical system on for starting/riding. (Off) Turns engine off. (Lock) Lock steering. Continued...
  • Page 48 Switches (Continued) Steering Lock Locking Turn the handlebar all the way to the left. Lock the steering when parking to help Push the key down, and turn the ignition prevent theft. switch to the (Lock) position. A U-shaped wheel lock or similar device is Jiggle the handlebar if the lock is difficult also recommended.

  • Page 49: Starting The Engine

    Starting the Engine Start your engine using the following Consult your dealer for advice if you plan to procedure, regardless of whether the engine ride your vehicle at an altitude above 2,500 is cold or warm. m (8,000 feet). NOTICE If the vehicle is transported to a place 2,000 m (6,500 feet) higher or lower than the start point, you may not be able to achieve sufficient engine...
  • Page 50 Starting the Engine (Continued) Press the start button with the throttle If the engine does not start: completely closed. Open the throttle fully and press the start If you cannot start the engine, open the button for 5 seconds. throttle slightly (about 3 mm (0.1 in), Repeat the normal starting procedure.

  • Page 51: Shifting Gears

    Shifting Gears Your vehicle transmission has 5 forward gears in a one-down, four-up shift pattern.
  • Page 52 Refuelling Opening the Fuel Fill Cap Ignition key Open the lock cover, insert the ignition key, Lock cover and turn it clockwise to open the fuel fill cap. Closing the Fuel Fill Cap Lower edge After refuelling, push the fuel fill cap until it of filler neck locks.

  • Page 53: Storage Equipment

    Storage Equipment Helmet holder Removing and Installing the Seat (P.67) The Helmet holder is located under the seat. WARNING Helmet holder Riding with a helmet attached to the holder can interfere with the rear wheel or suspension and could cause a crash in which you can be seriously hurt or killed.
  • Page 54 Storage Equipment (Continued) Document bag / Tool kit Document bag and tool kit are located underside of the seat by the rubber straps. Rubber straps Document bag Tool kit...

  • Page 55: Maintenance

    Maintenance Please read “Importance of Maintenance” and “Maintenance Fundamentals” carefully before attempting any maintenance. Refer to “Specifications” for service data. Importance of Maintenance ......P. 50 Maintenance Schedule........P. 51 Maintenance Fundamentals ......P. 54 Tools ..............P. 65 Removing & Installing Body Components.. P. 66 Battery ..............

  • Page 56: Importance Of Maintenance

    Importance of Maintenance Importance of Maintenance Maintenance Safety Keeping your vehicle well-maintained is Always read the maintenance instructions absolutely essential to your safety and to before you begin each task and make sure that protect your investment, obtain maximum you have the tools, parts, and skills required. performance, avoid breakdowns, and reduce air We cannot warn you of every conceivable pollution.

  • Page 57: Maintenance Schedule

    Maintenance work should be performed in new owner. accordance with Honda's standards and specifications by properly trained and equipped Honda recommends that your dealer should technicians. Your dealer meets all of these road test your vehicle after each periodic requirements. Keep an accurate record of maintenance is carried out.
  • Page 58 Inspect (clean, adjust, lubricate, or replace, if necessary) dealer, unless you have the necessary tools and are Lubricate mechanically skilled. Replace Procedures are provided in an official Honda Shop Manual. Clean : Technical. In the interest of safety, have your vehicle serviced by your dealer.
  • Page 59 Maintenance Schedule Frequency Pre-ride Annual Regular Refer to Items Check × 1,000 km Check Replace page P. 54 × 1,000 mi Brake System Brakelight Switch Headlight Aim – Lights/Horn – Engine Stop Switch – Clutch System Side Stand Suspension – Nuts, Bolts, Fasteners –...

  • Page 60: Maintenance Fundamentals

    Maintenance Fundamentals Drive chain - Check condition and slack, Pre-ride Inspection ● adjust and lubricate if necessary P. 74 To ensure safety, it is your responsibility to Brakes - Check operation; ● perform a pre-ride inspection and make sure Front and Rear: check brake fluid level and that any problem you find is corrected.
  • Page 61 Maintenance Fundamentals WARNING Replacing Parts Always use Honda Genuine Parts or their Installing non-Honda parts may make equivalents to ensure reliability and safety. your vehicle unsafe and cause a crash in which you can be seriously hurt or killed. Always use Honda Genuine Parts or equivalents that have been designed and approved for your vehicle.
  • Page 62 Maintenance Fundamentals Battery This symbol on the battery means that this product must not be treated as Your vehicle has a maintenance-free type household waste. battery. You do not have to check the battery electrolyte level or add distilled water. Clean the NOTICE battery terminals if they become dirty or An improperly disposed of battery can be...
  • Page 63 Maintenance Fundamentals WARNING What to do in an emergency If any of the following occur, immediately see The battery gives off explosive your doctor. hydrogen gas during normal operation. Electrolyte splashes into your eyes: ● Wash your eyes repeatedly with cool water for at least 15 minutes.
  • Page 64 Always replace the battery with another maintenance-free battery of the same type. NOTICE Installing non-Honda electrical accessories can NOTICE overload the electrical system, discharging the Replacing a fuse with one that has a higher rating greatly battery and possibly damaging the system.
  • Page 65 For recommended engine oil, see or “Resource Conserving” on the circular API “Specifications.” P. 103 service symbol. If you use non-Honda engine oil, check the label to make sure that the oil satisfies all of the following standards: JASO T 903 standard : MA ●...

  • Page 66: Recommended Brake Fluid

    Brake fluid can damage plastic and painted surfaces. Wipe up spills immediately and wash thoroughly. Recommended brake fluid: Normal Worn Damaged Honda DOT 3 or DOT 4 Brake Fluid or (GOOD) (REPLACE) (REPLACE) equivalent Drive Chain NOTICE Use of a new chain with worn sprockets will cause The drive chain must be inspected and rapid chain wear.
  • Page 67 Maintenance Fundamentals Never use petrol or low flash point solvents for Cleaning and Lubricating cleaning the drive chain. After inspecting the slack, clean the chain and A fire or explosion could result. sprockets while rotating the rear wheel. Use a Avoid getting lubricant on the brakes or tyres.
  • Page 68 Maintenance Fundamentals Inspecting for Abnormal Wear Tyres (Inspecting/Replacing) Checking the Air Pressure Inspect the tyres for Visually inspect your tyres and use an air signs of abnormal wear pressure gauge to measure the air pressure at on the contact surface. least once a month or any time you think the tyres look low.
  • Page 69 Maintenance Fundamentals WARNING Inspecting Tread Depth Inspect the tread wear indicators. If they Riding on tyres that are excessively become visible, replace the tyres immediately. worn or improperly inflated can cause a crash in which you can be seriously hurt or killed.
  • Page 70 Maintenance Fundamentals Have your tyres replaced by your dealer. WARNING For recommended tyres and air pressure, see Installing improper tyres on your “Specifications.” P. 103 vehicle can adversely affect handling Follow these guidelines whenever you replace and stability, and can cause a crash in tyres: Use the recommended tyres or their which you can be seriously hurt or...

  • Page 71: Tools

    Tools The tool kit is stored underside of the seat. The following tool is stored under the seat. P. 67 P. 67 P. 88 Fuse puller ● You can perform some roadside repairs, minor adjustments and parts replacement with the provided tools.

  • Page 72: Removing & Installing Body Components

    Removing & Installing Body Components Battery Remove the seat. P. 67 Remove the battery holder by removing the bolt. Battery holder Bolt Disconnect the negative - terminal from Positive terminal the battery. Disconnect the positive + terminal from the battery. Remove the battery, taking care not to drop the terminal nuts.

  • Page 73: Seat

    Removing & Installing Body Components Seat Seat Removal Insert the ignition key into the seat lock. Turn it clockwise, then pull the seat up Prongs Seat and backward. Installation Insert the prongs into the stays on the frame. Push forward and down on the rear of the seat until it locks in place.

  • Page 74: Checking The Engine Oil

    Engine Oil Checking the Engine Oil Oil level If the engine is cold, idle the engine for 3 inspection to 5 minutes. window Turn the ignition switch to the (Off) Upper level position and wait for 2 to 3 minutes. Place your vehicle in an upright position on a firm, level surface.

  • Page 75: Adding Engine Oil

    Engine Oil Adding Engine Oil Adding Engine Oil NOTICE Overfilling with oil or operating with insufficient oil can cause damage to your engine. Do not mix If the engine oil is below or near the lower different brands and grades of oil. They may level mark, add the recommended engine oil.

  • Page 76: Brakes

    Brakes Checking Brake Fluid If the brake fluid level in either reservoir is below the LWR or LOWER level mark or the brake lever and pedal freeplay becomes Place your vehicle in an upright position excessive, inspect the brake pads for wear. on a firm, level surface.

  • Page 77: Inspecting The Brake Pads

    Brakes Inspecting the Brake Pads Inspecting the Brake Pads Front Brake pads Check the condition of the brake pad wear indicators. The pads need to be replaced if a brake pad is worn to the indicator. Inspect the brake pads from below Front Wear the brake caliper.

  • Page 78: Adjusting The Brakelight Switch

    Brakes Adjusting the Brakelight Switch Adjusting the Brakelight Switch Check the operation of the brakelight switch. Hold the brakelight switch and turn the adjusting nut in the direction A if the switch operates too late, or turn the nut in the direction B if the switch operates too soon.

  • Page 79: Checking The Side Stand

    Side Stand Checking the Side Stand Check that the side stand operates smoothly. If the side stand is stiff or squeaky, clean the pivot area and lubricate the pivot bolt with clean grease. Check the spring for damage or loss of tension.

  • Page 80: Drive Chain

    Drive Chain Inspecting the Drive Chain Do not ride your vehicle if the slack exceeds 50 mm (2.0 in). Slack Check the drive chain slack at several points Drive chain along the chain. If the slack is not constant at all points, some links may be kinked and binding.

  • Page 81: Checking The Clutch

    Clutch Checking the Clutch Check the clutch cable for kinks or signs of wear. If necessary, have it replaced by your Checking the Clutch Lever Freeplay dealer. Lubricate the clutch cable with a Check the clutch lever freeplay. commercially available cable lubricant to Freeplay at the clutch lever: prevent premature wear and corrosion.

  • Page 82: Adjusting The Clutch Lever Free Play

    Clutch Adjusting the Clutch Lever Freeplay Adjusting the Clutch Lever Rubber dust cover Upper clutch cable adjuster Freeplay Upper Adjustment Attempt adjustment with the upper clutch cable adjuster first. Upper lock nut – Pull back the rubber dust cover. Loosen the upper lock nut. Turn the upper clutch cable adjuster until the freeplay is 10 - 20 mm (0.4 - 0.8 in).
  • Page 83 Clutch Adjusting the Clutch Lever Freeplay Loosen the upper lock nut and turn the Lower lock nut upper clutch cable adjuster all the way in (to provide maximum freeplay). Tighten the upper lock nut. Loosen the lower lock nut. Turn the lower clutch cable adjusting nut –...

  • Page 84: Throttle

    Throttle Checking the Throttle With the engine off, check that the throttle rotates smoothly from fully closed to fully open in all steering positions and throttle freeplay is correct. If the throttle does not move smoothly or close automatically, or if the cable is damaged, have the vehicle inspected by your dealer.

  • Page 85: Troubleshooting

    Troubleshooting Engine Will Not Start........P. 80 Warning Indicators On or Flashing....P. 81 PGM-FI (Programmed Fuel Injection) Malfunction Indicator Lamp (MIL)....P. 81 ABS (Anti-lock Brake System) Indicator ..P. 82 Other Warning Indications......P. 83 Fuel Gauge Failure Indication......P. 83 Tyre Puncture .............

  • Page 86: Engine Will Not Start

    Engine Will Not Start Starter Motor Operates But Starter Motor Does Not Engine Does Not Start Operate Check the following items: Check the following items: Check the correct engine starting Check the correct engine starting ● ● sequence. P. 43 sequence.

  • Page 87: Warning Indicators On Or Flashing

    Warning Indicators On or Flashing PGM-FI (Programmed Fuel Injection) Malfunction Indicator Lamp (MIL) If the indicator comes on while riding, you may have a serious problem with the PGM-FI system. Reduce speed and have your vehicle inspected by your dealer as soon as possible.

  • Page 88: Abs (Anti-Lock Brake System) Indicator

    Warning Indicators On or Flashing ABS (Anti-lock Brake System) Indicator ABS (Anti-lock Brake System) If the ABS indicator stays on, your brakes will continue to work as a conventional system, Indicator but without the anti-locking function. II TH type The ABS indicator may flash if you turn the If the indicator operates in one of the rear wheel while the rear wheel is lifted off following ways, you may have a serious...

  • Page 89: Other Warning Indications

    Other Warning Indications Fuel Gauge Failure Indication If the fuel system has an error, the fuel gauge indicators will be displayed as shown in the illustration. If this occurs, see your dealer as soon as possible.

  • Page 90: Tyre Puncture

    Tyre Puncture WARNING Repairing a puncture or removing a wheel requires special tools and technical expertise. Riding your vehicle with a temporary We recommend you have this type of service tyre repair can be risky. If the temporary performed by your dealer. repair fails, you can crash and be After an emergency repair, always have the seriously injured or killed.

  • Page 91: Electrical Trouble

    Electrical Trouble Battery Goes Dead Burned-out Light Bulb Charge the battery using a motorcycle Follow the procedure below to replace a battery charger. burned-out light bulb. Remove the battery from the vehicle before Turn the ignition switch to the (Off) or charging.
  • Page 92 Electrical Trouble Burned-out Light Bulb Front/Rear Turn Signal Bulb Install a new bulb and the parts in the reverse order of removal. The right and left turn signal bulbs Use only the amber bulb. replacement can be done in the same way. Collar Turn signal lens Screw...
  • Page 93 Electrical Trouble Burned-out Light Bulb License Plate Light Bulb Remove the screws. Remove the license plate light cover and the cover packing. Pull out the bulb without turning. Bulb License plate light cover Cover packing Screws Install a new bulb and the parts in the reverse order of removal.

  • Page 94: Blown Fuse

    Electrical Trouble Blown Fuse Blown Fuse Spare fuses Spare fuses Before handling fuses, see “Inspecting and Replacing Fuses.” P. 58 Fuse Box Fuses Remove the seat. P. 67 Open the fuse box cover. II TH type TH, LO, CA type Pull the fuses out one by one with the fuse puller and check for a blown fuse.

  • Page 95: Unstable Engine Operation Occurs Intermittently

    Unstable Engine Operation Occurs Intermittently If the fuel pump filter is clogged, unstable engine operation will occur intermittently while riding. Even if this symptom occurs, you can continue to ride your vehicle. If unstable engine operation occurs even if sufficient fuel is available, have your vehicle inspected by your dealer as soon as possible.

  • Page 96: Information

    Information Keys............... P. 91 Instruments, Controls, & Other Features..P. 91 Caring for Your Vehicle........P. 93 Storing Your Vehicle......... P. 96 Transporting Your Vehicle ......P. 97 You & the Environment........P. 98 Serial Numbers........... P. 99 Fuels Containing Alcohol ......P. 100 Catalytic Converter .........

  • Page 97: Keys

    Keys Keys Instruments, Controls, & Other Features Ignition Key Ignition Switch Be sure to record the key number provided with the key number plate. Store the spare key and Leaving the ignition switch in the (On) position key number in a safe location. with the engine stopped will drain the battery.

  • Page 98: Trip Meter

    Instruments, Controls, & Other Features Tripmeter High Beam Indicator Each tripmeter resets to 0.0 when the trip The high beam indicator will come on briefly mileage exceeds 9,999.9. due to the capacitor being discharged when the ignition switch is turned to the (On) position Document Bag immediately after the engine is stopped with the The owner's manual, registration, and insurance...

  • Page 99: Caring For Your Vehicle

    Frequent cleaning and polishing is important to Thoroughly rinse your vehicle with plenty of ensure the life of your Honda. A clean vehicle clean water and dry with a soft, clean cloth. makes it easier to spot potential problems.
  • Page 100 Caring for Your Vehicle Washing Precautions Do not direct water at the air cleaner: ● Water in the air cleaner can prevent the Follow these guidelines when washing: engine from starting. Do not use high-pressure washers: ● Do not direct water near the headlight: High-pressure water cleaners can ●...

  • Page 101: Aluminium Components

    Caring for Your Vehicle Aluminium Components Exhaust Pipe and Muffler Aluminium will corrode from contact with dirt, If the exhaust pipe and muffler are painted, do mud, or road salt. Clean aluminium parts not use a commercially available abrasive regularly and follow these guidelines to avoid kitchen cleaning compound.

  • Page 102: Storing Your Vehicle

    Storing Your Vehicle Storing Your Vehicle Remove the battery ( P. 66) to prevent ● discharge. Fully charge the battery and then If you store your vehicle outdoors, you should place it in a shaded, well-ventilated area. consider using a full-body cover. If you leave the battery in place, If you won't be riding for an extended period, disconnect the negative - terminal to...

  • Page 103: Transporting Your Vehicle

    Transporting Your Vehicle Transporting Your Vehicle If your vehicle needs to be transported, it should be carried on a motorcycle trailer or a flatbed truck or trailer that has a loading ramp or lifting platform and motorcycle tie-down straps. Never try to tow your vehicle with a wheel or wheels on the ground.

  • Page 104: You & The Environment

    You & the Environment You & the Environment Recycle Wastes Put oil and other toxic wastes in approved Owning and riding a vehicle can be enjoyable, containers and take them to a recycling centre. but you must do your part to protect the Call your local or state office of public works or environment.

  • Page 105: Serial Numbers

    Serial Numbers Serial Numbers The frame and engine serial numbers uniquely identify your vehicle and are required in order to register your vehicle. They may also be required when ordering replacement parts. You should record these numbers and keep them in a safe place. Frame number Engine number...

  • Page 106: Fuels Containing Alcohol

    Fuels Containing Alcohol Fuels Containing Alcohol If you notice any undesirable operating symptoms or performance problems, try a different brand of petrol. Except TH, II TH type Some conventional fuels blended with alcohol are available in some locales to help reduce emissions to TH, II TH type Some conventional fuels blended with alcohol are meet clean air standards.

  • Page 107: Catalytic Converter

    A defective catalytic converter contributes to air pollution and can impair your engine's performance. A replacement unit must be an original Honda part or equivalent.

  • Page 108: Specifications

    Specifications Main Components ■ Displacement 123.94 cm (7.560 cu-in) Overall length 1,758 mm (69.2 in) Bore x stroke 50.000 x 63.121 mm (1.9685 x 2.4851 in) Overall width 726 mm (28.6 in) Compression 10 : 1 ratio Overall height 1,017 mm (40.0 in) Unleaded petrol Wheelbase 1,198 mm (47.2 in)
  • Page 109 , 29 psi) qt, 0.92 Imp qt) passenger) Recommended Spark plug (standard) CPR7EA-9S (NGK) Honda DOT 3 or DOT 4 Brake Fluid brake fluid Recommended Drive chain lubricant If not available, use drive chain SAE 80 or 90 gear oil. lubricant Drive chain slack 30 - 40 mm (1.2 - 1.6 in)
  • Page 110 Specifications Bulbs ■ Headlight Brakelight/Taillight Front turn signal 12 V-21 W x 2 Rear turn signal 12 V-21 W x 2 License plate light 12 V-5 W Fuses ■ Main fuse 15 A 10 A TH, CA, LO type Other fuse 15 A, 10 A II TH type...

  • Page 111: Index

    Honda Cambodia – NCX www.ncxhonda.com hondacambodiancx 4PK26J30 00X4P-K26-J300...
