Summary of Contents for fenceweb Twinwire Professional
- Page 1 Manual Twinwire fence with round post - Professional.
-
Page 2: Personal Protective Equipment
Personal protective equipment. Twinwire fence with round post... - Page 3 What is needed to install the fence? Twinwire fence with round post Shovel / Rope / wire Auger Tape measure Angle grinder (Rubber) Hammer Level Make it even easier for yourself. The following could also come in handy! • Postdriver •...
-
Page 4: Check Your Order
Check your order. Twinwire fence with round post The fencing, the posts, the gate and concrete are delivered on a pallet, possibly on several for large orders. Small orders are placed upright and tied to a wooden trestle and finally sealed. Large orders transported on big pallets are usually not sealed in foil. - Page 5 Carefully remove the products from the pallet. Twinwire fence with round post Carefully cut open the foil with a boxcutter without damaging the products (Best on the short side of the pallet). Then cut the green straps and pull them off the pallet. Carefully remove the products from the pallet.
- Page 6 Overview: Twinwire fence with round posts. Twinwire fence with round post Distance between posts CENTER TO CENTER 2580mm Distance from center CENTER TO CENTER 2580mm CENTER TO CENTER 2580mm to center CARRIAGE BOLT Bolt *Center to center is the distan- CARRIAGE BOLT CARRIAGE BOLT ce between the center of one...
- Page 7 Preparation: Measuring is knowing. Twinwire fence with round post Level the ground at the location where the fencing will be placed. Free up enough space to work properly. Determine the starting point of your fence. This starting point must not be able to change in dimensions later.
- Page 8 Assembly: The fist post. Twinwire fence with round post Dig or drill a hole of Place the post in the hole. Secure the post with approximately 30 x Check if it is level and (quickdrying) concrete. 30 cm where the first place it against the stret- For fencing higher than post is to be placed.
- Page 9 Assembly: The second post and the first fencepanel. Twinwire fence with round post It is wise to install the fences with two or more people. We recommend installing the fencing fence by fence. So don’t start with all the posts and then the fences. When it turns out that the space between the posts are not correct, the posts that follow will all have to be corrected as...
- Page 10 Assembly: Sorting the brackets. Twinwire fence with round post *Middle brackets. *End brackets.. Tip: You might drop a nut or a bolt during assembly. To prevent you from losing it, you can place a (moving) blanket or plastic bag at the bottom of the pole that will catch it.
- Page 11 Assembly: Assemble the fence with an end bracket. Twinwire fence with round post Slide the correct amount of end brackets over the post (depending on the height of the fence) and slide the fencepanel between the bracket far enough so that the tabs of the bracket are over two bars.
- Page 12 Assembly: Assemble the fence with a middle bracket. Twinwire fence with round post When attaching the first gate with the intermediate brackets, the second fencepanel must be placed between the brackets at the same time. Place the second fence against the post and place one intermediate bracket part against one side of the gate.
- Page 13 Assembly: Assemble the fence with the corner bracket. Twinwire fence with round post When the fencing goes around a corner, use the corner brackets. The corner bracket consists of two parts, a small part and a large part. It is best to carefully slide the large part over the post to prevent damage.
- Page 14 Assembly: Level the fence and tighten the brackets. Twinwire fence with round post Start again at the first fencepanel. Keep the fence at the correct height and level the fence with a spirit level. Then tighten the nuts tightly with a socket wrench or wrench.
- Page 15 Assembly: Shorten a fence panel. Twinwire fence with round post If you want to place a fencepanel that needs to be shortened, you can shorten it with an angle grinder. Use the spray can to paint over the grinded part of the fence to prevent rust.
- Page 16 Final action: Placing the post caps. Twinwire fence with round post As a final action, place the caps on the posts.
- Page 17 Congratulations, your fence is up! Twinwire fence with round post Do not forget to take pictures of your fence and send them to: business@fenceweb.com Send your reactions to: Did you find this manual useful? business@fenceweb.com We would love to hear your feedback!
- Page 18 You made a great choice, these people also bought this fence! Twinwire fence with round post...
