OWNER'S MANUAL
M M 2 2 2 2 6 6 2 2 D D
M M 2 2 3 3 6 6 2 2 D D
M M 2 2 7 7 6 6 2 2 D D
Make sure to read the Safety Precautions before
using the product.
Keep the User's Guide(CD) in an accessible place
for furture reference.
See the label attached on the product and give the
information to your dealer when you ask for service.

Advertisement

loading
Need help?

Need help?

Do you have a question about the MM2262D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG MM2262D

Summary of Contents for LG MM2262D

  • Page 1 All manuals and user guides at all-guides.com OWNER’S MANUAL M M 2 2 2 2 6 6 2 2 D D M M 2 2 3 3 6 6 2 2 D D M M 2 2 7 7 6 6 2 2 D D Make sure to read the Safety Precautions before using the product.

  • Page 2: Front Panel Controls

    All manuals and user guides at all-guides.com PREPARATION FRONT PANEL CONTROLS This is a simplified representation of the front panel. The image shown may be somewhat different from your set. P P o o w w e e r r I I n n d d i i c c a a t t o o r r illuminates blue when the set is switched on.

  • Page 3: Back Panel Information

    All manuals and user guides at all-guides.com PREPARATION BACK PANEL INFORMATION This is a simplified representation of the back panel. The image shown may be somewhat different from your set. COMPONENT AV-IN AV 1 AV 2 RS-232C IN (CONTROL & SERVICE) S-VIDEO HDMI IN RGB IN (PC)

  • Page 4: Stand Installation

    All manuals and user guides at all-guides.com < < M M 2 2 2 2 6 6 2 2 D D / / M M 2 2 3 3 6 6 2 2 D D > > PREPARATION STAND INSTALLATION The image shown may be somewhat different from your set.
  • Page 5 All manuals and user guides at all-guides.com < < M M 2 2 7 7 6 6 2 2 D D > > PREPARATION STAND INSTALLATION The image shown may be somewhat different from your set. Carefully place the product screen side down on a Insert the s s t t a a n n d d b b a a s s e e into the product cushioned surface that will protect product and screen from damage.

  • Page 6: Detaching Stand

    All manuals and user guides at all-guides.com < < M M 2 2 2 2 6 6 2 2 D D / / M M 2 2 3 3 6 6 2 2 D D > > PREPARATION DETACHING STAND The image shown may be somewhat different from your monitor.
  • Page 7 All manuals and user guides at all-guides.com < < M M 2 2 7 7 6 6 2 2 D D > > PREPARATION DETACHING STAND The image shown may be somewhat different from your monitor. Detach the monitor to the Stand Base by Place the set screen side down on a cushion or turning the screw to the left.
  • Page 8 All manuals and user guides at all-guides.com PREPARATION DETACHING STAND BODY The image shown may be somewhat different from your set. Remove the Stand Body in the same way as the following when using it as a Wall Hook. < < M M 2 2 2 2 6 6 2 2 D D / / M M 2 2 3 3 6 6 2 2 D D > > 1.

  • Page 9: Wall Mount: Horizontal Installation

    All manuals and user guides at all-guides.com PREPARATION WALL MOUNT: HORIZONTAL INSTALLATION For proper ventilation, allow a clearance of 4 inches on each side and from the wall. Follow the instructions included with the wall mount. 4 inches 4 inches 4 inches 4 inches 4 inches...

  • Page 10: Positioning Your Display

    M M 2 2 2 2 6 6 2 2 D D / / M M 2 2 3 3 6 6 2 2 D D : 100mm x 100mm hole spacing M M 2 2 7 7 6 6 2 2 D D : 200mm x 100mm hole spacing * Wall mount interface(LG) : RW120 RW120...
  • Page 11 All manuals and user guides at all-guides.com PREPARATION SECURING THE SET TO THE WALL TO PREVENT FALLING WHEN THE SET IS USED ON A STAND Image shown may differ from your set. We recommend that you set up the set close to a wall so it cannot fall over if pushed backwards. Additionally, we recommend that the set be attached to a wall so it cannot be pulled in a forward direction, potentially causing injury or damaging the product.
  • Page 12 All manuals and user guides at all-guides.com PREPARATION ATTACHING THE TV TO A DESK (Only M2762D) Image shown may differ from your set. The TV must be attached to desk so it cannot be pulled in a forward/backward direction,potentially causing injury or damaging the product.Use only an attached screw.

  • Page 13: Kensington Security System

    All manuals and user guides at all-guides.com PREPARATION KENSINGTON SECURITY SYSTEM - The product is equipped with a Kensington Security System connector on the back panel. Connect the Kensington Security System cable as shown below. - For detailed installation and use of the Kensington Security System, refer to the user’s guide provided with the Kensington Security System.

  • Page 14: External Equipment Setup

    All manuals and user guides at all-guides.com EXTERNAL EQUIPMENT SETUP To prevent equipment damage, never plug in any power cords until you have finished connecting all equipment. ANTENNA CONNECTION For optimum picture quality, adjust antenna direction. An antenna cable and converter are not supplied. AV 1 AV 2 Multi-family Dwellings/Apartments...

  • Page 15: Hd Receiver Setup

    All manuals and user guides at all-guides.com EXTERNAL EQUIPMENT SETUP To prevent the equipment damage, never plug in any power cords until you have finished connecting all equipment. The image shown may be somewhat different from your set. HD RECEIVER SETUP When connecting with a component cable Connect the SET-TOP outputs to the C C O O M M P P O O N N E E N N T T I I N N V V I I D D E E O O sockets (Y P...

  • Page 16: When Connecting With A Hdmi To Dvi Cable

    All manuals and user guides at all-guides.com EXTERNAL EQUIPMENT SETUP When connecting with a HDMI Connect the HDMI output of the digital set-top box to the HDMI IN H H D D M M I I I I N N jack on the set. When connecting with a HDMI to DVI cable Connect the digital set-top box to H H D D M M I I I I N N jack on the set.

  • Page 17: Dvd Setup

    All manuals and user guides at all-guides.com EXTERNAL EQUIPMENT SETUP DVD SETUP When connecting with a component cable Connect the video output sockets (Y P ) of the DVD to the C C O O M M P P O O N N E E N N T T I I N N V V I I D D E E O O sockets (Y P ) of the set.

  • Page 18: When Connecting Hdmi Cable

    All manuals and user guides at all-guides.com EXTERNAL EQUIPMENT SETUP When connecting S-Video Connect the S-Video output of the DVD to the S-Video in put on the set. Connect the audio output of the DVD to the AUDIO in put on the set. AV-IN S-VIDEO When connecting HDMI cable...

  • Page 19: Vcr Setup

    All manuals and user guides at all-guides.com EXTERNAL EQUIPMENT SETUP VCR SETUP To avoid picture noise (interference), leave an adequate distance between the VCR and the set. If a user uses 4:3 picture format for a long time, an afterimage may remain on the sides of the screen for a short time.

  • Page 20: When Connecting With A Rca Cable

    All manuals and user guides at all-guides.com EXTERNAL EQUIPMENT SETUP When connecting with a RCA cable Connect the audio/video out sockets of the VCR to AV-IN AUDIO/VIDEO in sockets of the set. S-VIDEO Press the INPUT button to select AV. Press the PLAY button on the VCR.

  • Page 21: When Connecting With A D-Sub 15 Pin Cable

    All manuals and user guides at all-guides.com EXTERNAL EQUIPMENT SETUP PC SETUP This product provides Plug and Play capability, meaning that the PC adjusts automatically to the set's settings. When connecting with a D-sub 15 pin cable Connect the signal cable from the monitor output socket of the PERSONAL COMPUTER to the PC input socket of AUDIO IN (RGB/DVI)
  • Page 22 All manuals and user guides at all-guides.com EXTERNAL EQUIPMENT SETUP When connecting with a DVI cable Connect the DVI output of the PC to the D D V V I I - - D D I I N N jack on the set. AUDIO IN (RGB/DVI) Connect the audio cable from the PC to the A A U U D D I I O O...

  • Page 23: Back Cover For Wire Arrangement

    All manuals and user guides at all-guides.com EXTERNAL EQUIPMENT SETUP BACK COVER FOR WIRE ARRANGEMENT Tie cables together with a cable tie as shown in the illustration. Cable tie...
  • Page 24 All manuals and user guides at all-guides.com EXTERNAL EQUIPMENT SETUP RGB/DVI[PC] Horizontal Vertical Resolution Frequency(kHz) Frequency(Hz) 720x400 31.468 31.469 640x480 37.500 37.879 800x600 46.875 48.363 1024x768 60.123 67.500 1 152x864 63.981 1280x1024 79.976 64.674 1680x1050 65.290 75.000 1600x1200 66.587 1920x1080 HDMI[DTV] supported mode Horizontal Vertical...

  • Page 25: Initial Setting

    All manuals and user guides at all-guides.com EXTERNAL EQUIPMENT SETUP INITIAL SETTING This Function guides the user to easily set the essential items for viewing the TV for the first time when purchas- ing the TV. If will be displayed on the screen when turning the TV on for the first time. It can also be activated from the user menus.

  • Page 26: Watching Tv / Channel Control

    All manuals and user guides at all-guides.com WATCHING TV / CHANNEL CONTROL REMOTE CONTROL KEY FUNCTIONS When using the remote control, aim it at the remote control sensor on the set. POWER Turns your set on or off. POWER TV/PC Selects TV or PC mode.

  • Page 27: Turning On The Tv

    All manuals and user guides at all-guides.com WATCHING TV / CHANNEL CONTROL TURNING ON THE TV First, connect the power cord correctly. POWER TV/PC INPUT Turn on the power by pressing the power button on the product. PICTURE SOUND RATIO Press the TV/PC button on the remote control.

  • Page 28: Channel Selection

    All manuals and user guides at all-guides.com WATCHING TV / CHANNEL CONTROL CHANNEL SELECTION Press the C C H H + + or - - or NUMBER buttons to select a POWER programme number. TV/PC INPUT PICTURE SOUND RATIO VOLUME ADJUSTMENT Press the VOL + + or - - button to adjust the volume.
  • Page 29 All manuals and user guides at all-guides.com WATCHING TV / CHANNEL CONTROL QUICK MENU / FAVORITE CHANNEL SETUP Your set’s OSD (On Screen Display) may differ slightly from what is shown in this manual. Q.Menu (Quick Menu) is a menu of features which users might use frequently. A A s s p p e e c c t t R R a a t t i i o o : Selects your desired picture format.

  • Page 30: On Screen Menus Selection And Adjustment

    All manuals and user guides at all-guides.com WATCHING TV / CHANNEL CONTROL ON SCREEN MENUS SELECTION AND ADJUSTMENT Your set's OSD ( On Screen Display ) may differ slightly from what is shown in this manual. CHANNEL PICTURE Move Enter Move Enter Auto tuning...

  • Page 31: Auto Channel Tuning

    All manuals and user guides at all-guides.com WATCHING TV / CHANNEL CONTROL AUTO CHANNEL TUNING Use this to automatically find and store all available channels. When you start auto programming in digital mode, all previously stored service information will be deleted. CHANNEL CHANNEL Move...

  • Page 32: Manual Tuning

    All manuals and user guides at all-guides.com WATCHING TV / CHANNEL CONTROL MANUAL TUNING When selecting DTV or TV or CADTV or CATV input signal, you can view the on-screen signal strength monitor to see the quality of the signal being received. CHANNEL CHANNEL Move...

  • Page 33: Channel Edit

    All manuals and user guides at all-guides.com WATCHING TV / CHANNEL CONTROL CHANNEL EDIT A custom list can be created by toggling each channel on or off with the ENTER button. The channels in the Custom List are displayed in black and the channels deleted from the Custom List are displayed in gray.

  • Page 34: Picture Size (Aspect Ratio) Control

    All manuals and user guides at all-guides.com PICTURE CONTROL PICTURE SIZE (ASPECT RATIO) CONTROL This feature lets you choose the way an analog picture with a 4:3 aspect ratio is displayed on your set. RGB-PC input source use 4:3 or 16:9 aspect ratio. NOTE If a fixed image is displayed on the screen for a long time, the image could become imprinted on the screen and remain visible.
  • Page 35 All manuals and user guides at all-guides.com PICTURE CONTROL Set by program Zoom 1 Selects the proper picture proportion to match Choose Zoom 1 when you want to view the pic- the source’s image. ture without any alteration. However, the top and bottom portions of the picture will be cropped.

  • Page 36: Preset Picture Settings

    All manuals and user guides at all-guides.com PICTURE CONTROL PRESET PICTURE SETTINGS Picture Mode-Preset There are factory presets for picture settings available in the user menus. You can use a preset, change each set- ting manually. Q.Menu Aspect Ratio 16:9 Backlight Vivid Standard...
  • Page 37 All manuals and user guides at all-guides.com PICTURE CONTROL AUTO BRIGHT When ON is selected, this function adjusts the screen brightness automatically, depending on the surrounding environment, to provide optimal viewing conditions. When OFF is selected, this function is turned off. PICTURE PICTURE Move...
  • Page 38 All manuals and user guides at all-guides.com PICTURE CONTROL PRESET PICTURE SETTINGS Picture Mode-Preset PICTURE Move Enter Aspect Ratio : 16:9 Auto Bright : Off Vivid Picture Mode Picture Mode : Vivid : Standrad • Backlight Standrad Standard • Contrast Cinema Sport •...

  • Page 39: Auto Color Tone Control (Warm/Medium/Cool)

    All manuals and user guides at all-guides.com PICTURE CONTROL Auto Color Tone Control (Warm/Medium/Cool) Choose one of three automatic color adjustments. Set to warm to enhance warm colors such as red, or set to cool to see less intense colors with more blue. PICTURE PICTURE Move...
  • Page 40 All manuals and user guides at all-guides.com PICTURE CONTROL Auto Color Tone Control (6500K/9300K/sRGB)(RGB,DVI mode only) Choose one of two automatic color adjustments. PICTURE PICTURE Move Enter Move Enter Color Temperature Picture Mode : Standard Picture Mode : Standard 6500K •...

  • Page 41: Manual Picture Adjustment

    All manuals and user guides at all-guides.com PICTURE CONTROL MANUAL PICTURE ADJUSTMENT Picture Mode-User option PICTURE Move Enter Aspect Ratio : 16:9 Auto Bright : Off Vivid Picture Mode : Vivid Picture Mode : Standard (User) Standard(User) Standard • Backlight Cinema •...

  • Page 42: Picture Improvement Technology

    All manuals and user guides at all-guides.com PICTURE CONTROL PICTURE IMPROVEMENT TECHNOLOGY Fresh Contrast Optimizes the contrast automatically according to the brightness of the reflection. Fresh Color Adjusts the color of the reflection automatically to reproduce natural colors as close as possible. Noise Reduction Removes interference up to the point where it does not damage the original picture.

  • Page 43: Advanced - Black (Darkness) Level

    All manuals and user guides at all-guides.com PICTURE CONTROL ADVANCED - BLACK (DARKNESS) LEVEL When you view a film, this function adjusts the set to the best picture quality. This function works in the following mode: ATV, AV(NTSC-M), Component, HDMI PICTURE PICTURE Move...

  • Page 44: Advanced - Film Mode

    All manuals and user guides at all-guides.com PICTURE CONTROL ADVANCED - FILM MODE To set the product up for the best picture quality for viewing films. This feature operates only in TV, AV and Component 480i/1080i , HDMI 1080i mode. PICTURE PICTURE Move...

  • Page 45: Picture Reset

    All manuals and user guides at all-guides.com PICTURE CONTROL PICTURE RESET Settings of the selected picture modes return to the default factory settings. PICTURE PICTURE Move Enter Move Enter • Backlight • Backlight • Contrast • Contrast • Brightness • Brightness •...

  • Page 46: Selecting Resolution

    All manuals and user guides at all-guides.com PICTURE CONTROL SCREEN SETUP FOR PC MODE Selecting Resolution To view a normal picture, set the resolution to match what the PC is using. This function works in the following resolution in RGB[PC] mode. SCREEN Move MENU...

  • Page 47: Auto Configure (Rgb [Pc] Mode Only)

    All manuals and user guides at all-guides.com PICTURE CONTROL Auto Configure (RGB [PC] mode only) Automatically adjusts picture position and minimizes image instability. After adjustment, if the image is still not correct, your set is functioning properly but needs further adjustment. A A u u t t o o c c o o n n f f i i g g u u r r e e This function is for automatic adjustment of the screen position, clock, and phase The displayed image will be unstable for a few seconds while the auto configuration is in progress.

  • Page 48: Adjustment For Screen Position, Size, Phase

    All manuals and user guides at all-guides.com PICTURE CONTROL Adjustment for screen Position, Size, Phase If the picture is not clear after auto adjustment and especially if characters are still shaky, adjust the picture phase manually. This function works in the following mode: RGB[PC]. PICTURE SCREEN Move...

  • Page 49: Screen Reset

    All manuals and user guides at all-guides.com PICTURE CONTROL Screen Reset Returns Position, Size and Phase to the default factory settings. This function works in the following mode: RGB[PC]. PICTURE SCREEN Move Enter Move Prev. MENU • Contrast : 100 Resolution •...

  • Page 50: Sound Control

    All manuals and user guides at all-guides.com SOUND CONTROL AUTO VOLUME LEVELER AVL automatically remains on the same volume level if you change programmes. AUDIO AUDIO Move Enter Move Enter Auto Volume : Off Auto Volume : Off Auto Volume : Off Auto Volume : Off...
  • Page 51 All manuals and user guides at all-guides.com SOUND CONTROL BALANCE You can adjust the sound balance of the speakers to preferred levels. AUDIO AUDIO Move Enter Move Enter Auto Volume : Off Auto Volume : Off Balance Balance Balance Balance •...

  • Page 52: Preset Sound Settings - Sound Mode

    All manuals and user guides at all-guides.com SOUND CONTROL PRESET SOUND SETTINGS - SOUND MODE Sound Mode lets you enjoy the best sound without any special adjustment as the TV sets the appropriate sound options based on the program content. S S t t a a n n d d a a r r d d , M M u u s s i i c c , C C i i n n e e m m a a , S S p p o o r r t t , and G G a a m m e e are preset for optimum sound quality at the factory and are not adjustable.
  • Page 53 All manuals and user guides at all-guides.com SOUND CONTROL PRESET SOUND SETTINGS - SOUND MODE You can select your preferred sound setting; Standard, Music, Cinema, Sport and Game and you can also adjust the frequencies of the equalizer. Standard, Music, Cinema, Sport and Game are preset for optimum sound quality at the factory. AUDIO AUDIO Move...

  • Page 54: Sound Setting Adjustment - User Mode

    All manuals and user guides at all-guides.com SOUND CONTROL SOUND SETTING ADJUSTMENT - USER MODE Adjusting the audio equalizer. AUDIO AUDIO Move Enter Move Enter Auto Volume : Off Auto Volume : Off Balance Balance Sound Mode : Standard Sound Mode : Standard SRS TruSurround XT •...

  • Page 55: Audio Reset

    All manuals and user guides at all-guides.com SOUND CONTROL AUDIO RESET Settings of the selected Sound Mode return to the default factory settings. AUDIO AUDIO Move Enter Move Enter Auto Volume : Off Auto Volume : Off Balance Balance Sound Mode : Standard Sound Mode : Standard •...
  • Page 56 All manuals and user guides at all-guides.com SOUND CONTROL TV SPEAKERS ON/ OFF SETUP You can tun of the speakers when using external audio system. AUDIO AUDIO Move Enter Move Enter Auto Volume : Off Auto Volume : Off Balance Balance Sound Mode : Standard Sound Mode : Standard...

  • Page 57: Stereo/Sap Broadcast Setup

    All manuals and user guides at all-guides.com SOUND CONTROL STEREO/SAP BROADCAST SETUP For Analog only: This TV can receive MTS stereo programs and any SAP (Secondary Audio Program) that accompa- nies the stereo program if the station transmits an additional sound signal. Mono sound is automatically used if the broadcast is only in Mono.

  • Page 58: Time Setting

    All manuals and user guides at all-guides.com TIME SETTING CLOCK SETTING Auto Clock Setup The time is set automatically from a digital channel signal. The digital channel signal includes information for the current time provided by the broadcasting station. Set the clock manually if the current time is set incorrectly by the auto clock function. TIME TIME Move...

  • Page 59: Manual Clock Setup

    All manuals and user guides at all-guides.com TIME SETTING Manual Clock Setup If the current time setting is wrong, reset the clock manually. TIME TIME Move Enter Move Enter M M a a n n u u a a l l Year 2008 Clock...

  • Page 60: Auto On/Off Timer Setting

    All manuals and user guides at all-guides.com TIME SETTING AUTO ON/OFF TIMER SETTING The Off time function automatically switches the set to standby at a preset time. Two hours after the set is switched on by the on time function it will automatically switch back to standby mode unless a button has been pressed.

  • Page 61: Sleep Timer Setting

    All manuals and user guides at all-guides.com TIME SETTING SLEEP TIMER SETTING The sleep timer automatically switches the set off after the preset time has elapsed. TIME TIME Move Enter Move Enter Clock Clock Off Time : Off Off Time : Off On Time : Off...

  • Page 62: Auto Shut-Off Setting

    All manuals and user guides at all-guides.com TIME SETTING AUTO SHUT-OFF SETTING If the set is switched on and there is no input signal, it will switch off automatically after 10 minutes. TIME TIME Move Move Enter Enter Clock Clock Off Time : Off Off Time...

  • Page 63: Option Setting

    All manuals and user guides at all-guides.com OPTION SETTING ON-SCREEN MENUS LANGUAGE SELECTION The menus can be shown on the screen in the selected language. OPTION OPTION Move Enter Move Enter Language : English Language : English Language : English Language : English English...

  • Page 64: Input Label

    All manuals and user guides at all-guides.com OPTION SETTING INPUT LABEL Selects a label for each input source. OPTION OPTION Move Enter Move Enter Language : English Language : English Input Label Input Label Input Label Input Label Key Lock : Off Key Lock : Off...
  • Page 65 All manuals and user guides at all-guides.com OPTION SETTING KEY LOCK The set can be configured so that the remote control is required to control it. This feature can be used to prevent unauthorized viewing. OPTION OPTION Move Enter Move Enter Language : English...

  • Page 66: Analog Broadcasting System Captions

    All manuals and user guides at all-guides.com OPTION SETTING Analog Broadcasting System Captions Caption must be provided to help people with hearing loss watch TV. Select a caption mode for displaying cap- tioning information if provided on a program. Analog caption displays information at any position on the screen and is usually the program's dialog.

  • Page 67: Digital Broadcasting System Captions

    All manuals and user guides at all-guides.com OPTION SETTING Digital Broadcasting System Captions Choose the language you want the DTV/CADTV Captions to appear in. Other Languages can be chosen for digital sources only if they are included on the program. This function in only available when Caption Mode is set On.

  • Page 68: Caption Option

    All manuals and user guides at all-guides.com OPTION SETTING Caption Option Customize the DTV/CADTV captions that appear on your screen. This function in only available when Caption Mode is set On. Custom OPTION OPTION Move Move Enter Enter Size A Standard Language : English Language...
  • Page 69 All manuals and user guides at all-guides.com OPTION SETTING POWER INDICTOR It helps you control LED when power is turned on. OPTION OPTION Move Enter Move Enter Language : English Language : English Input Label Input Label Key Lock : Off Key Lock : Off Caption...
  • Page 70 All manuals and user guides at all-guides.com OPTION SETTING DDC CI(Only RGB, DVI mode) DDC/CI (Display Data Channel Command Interface) is a communication protocol for communications between a PC and Monitor. DDC/CI makes it possible to adjust and setup detailed functions on the PC instead of the Monitor. On allows adjustments on the PC.
  • Page 71 All manuals and user guides at all-guides.com OPTION SETTING RTC(Only M2762D) If you set ON, you enable the response time control function. If you set OFF, you disenable the response time control function. OPTION OPTION Move Enter Move Enter Language : English Language : English...

  • Page 72: Parental Control / Ratings

    All manuals and user guides at all-guides.com PARENTAL CONTROL / RATINGS LOCK SYSTEM Enter the password, press ‘0’ , ‘0’ , ‘0’ , ‘0’ on the remote control handset. LOCK LOCK Move Enter Move Enter Lock System Lock System : Off : Off Lock System Lock System...

  • Page 73: Set Password

    All manuals and user guides at all-guides.com PARENTAL CONTROL / RATINGS SET PASSWORD LOCK LOCK Move Enter Move Enter Lock System : Off Lock System : Off Set Password Set Password Set Password Set Password Confirm Block Channel Block Channel Movie Rating Movie Rating Close...

  • Page 74: Block Channel

    All manuals and user guides at all-guides.com PARENTAL CONTROL / RATINGS BLOCK CHANNEL Blocks any programs that you do not want to watch or that you do not want your children to watch. This function is available in Lock System “On”. LOCK Move Enter...

  • Page 75: Movie Rating

    All manuals and user guides at all-guides.com PARENTAL CONTROL / RATINGS MOVIE RATING Blocks movies according to the movie ratings limits specified, so children cannot view certain movies. You can set the ratings limit by blocking out all the movies with the ratings above a specified level. Keep in mind that the movie ratings limit only applies to movies shown on TV, not TV programs, such as soap operas.

  • Page 76: Tv Rating-Children

    All manuals and user guides at all-guides.com PARENTAL CONTROL / RATINGS TV RATING-CHILDREN Prevents children from watching certain children's TV programs, according to the ratings limit set. The children rat- ing does not apply to other TV programs. Unless you block certain TV programs intended for mature audiences in the TV Rating - sub menu, your children can view those programs.

  • Page 77: Tv Rating-General

    All manuals and user guides at all-guides.com PARENTAL CONTROL / RATINGS TV RATING-GENERAL Based on the ratings, blocks certain TV programs that you and your family do not want to view. LOCK LOCK Move Enter Move Enter Lock System : Off Lock System : Off Set Password...

  • Page 78: Downloadable Rating

    All manuals and user guides at all-guides.com PARENTAL CONTROL / RATINGS DOWNLOADABLE RATING This function may become available in the future and will be available only for digital channel signal. This function operates only when TV has received Region5 Rating data. LOCK LOCK Move...

  • Page 79: Input Block

    All manuals and user guides at all-guides.com PARENTAL CONTROL / RATINGS INPUT BLOCK Enables you to block an input. LOCK LOCK Move Enter Move Enter Lock System : Off Lock System : Off Set Password Set Password Component Block Channel Block Channel RGB-PC Movie Rating...

  • Page 80: Troubleshooting

    All manuals and user guides at all-guides.com APPENDIX TROUBLESHOOTING T T h h e e o o p p e e r r a a t t i i o o n n d d o o e e s s n n o o t t w w o o r r k k n n o o r r m m a a l l l l y y . . Check to see if there is any object between the product and the remote control caus- ing obstruction.
  • Page 81 All manuals and user guides at all-guides.com APPENDIX N N o o A A u u d d i i o o . . Press the VOL + + or - - button. Sound muted? Press MUTE button. Picture OK but no sound Try another channel.
  • Page 82 All manuals and user guides at all-guides.com APPENDIX ‘ ‘ U U n n k k n n o o w w n n P P r r o o d d u u c c t t ’ ’ m m e e s s s s a a g g e e a a p p p p e e a a r r s s w w h h e e n n t t h h e e p p r r o o d d u u c c t t i i s s c c o o n n n n e e c c t t e e d d . . Install the product driver, which is provided with the product, or download it from the web site.

  • Page 83: Maintenance

    All manuals and user guides at all-guides.com APPENDIX MAINTENANCE Careful and regular cleaning can extend the amount of time you can enjoy your new set. Caution: Be sure to turn the power off and unplug the power cord before you begin any cleaning. Cleaning the Screen To keep the dust off your screen for a while, wet a soft cloth in a mixture of lukewarm water and a little fab- ric softener or dishwashing detergent.

  • Page 84: Product Specifications

    All manuals and user guides at all-guides.com APPENDIX PRODUCT SPECIFICATIONS < < M M 2 2 2 2 6 6 2 2 D D > > Screen Type LCD Panel 21.53 inches Wide (546.86 mm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Visible diagonal size : 546.86 mm Pixel Pitch 0.248 (H) x 0.248(V) mm...
  • Page 85 All manuals and user guides at all-guides.com APPENDIX PRODUCT SPECIFICATIONS < < M M 2 2 3 3 6 6 2 2 D D > > Screen Type LCD Panel 23 inches Wide (584.2 mm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Visible diagonal size : 584.2 mm Pixel Pitch 0.265 (H) x 0.265 (V) mm...
  • Page 86 All manuals and user guides at all-guides.com APPENDIX PRODUCT SPECIFICATIONS < < M M 2 2 7 7 6 6 2 2 D D > > Screen Type LCD Panel 27 inches Wide (686 mm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Visible diagonal size : 686 mm Pixel Pitch 0.31 14 (H) x 0.31 14 (V) mm...

  • Page 87: Programming The Remote Control

    All manuals and user guides at all-guides.com APPENDIX PROGRAMMING THE REMOTE CONTROL The remote is a multi-brand or universal remote. It can be programmed to operate most remote-con- trollable devices of other manufacturers. Note that the remote may not control all models of other brands. Programming a code into a remote mode To find out whether your remote control can operate the component without programming, turn on the component such as a VCR and press the corresponding mode button (such as a D D V V D D or V V C C R R ) on the...
  • Page 88 145 147 VIDEOSONIC 047 048 REALISTIC 003 008 010 014 WARDS 003 013 017 024 LG (GOLDSTAR) 001 012 013 020 031 033 034 040 031 033 034 040 101 106 1 14 123 053 054 101 053 054 131...

  • Page 89: How To Connect

    All manuals and user guides at all-guides.com APPENDIX IR CODES 1. How to Connect Connect your wired remote control to the Remote Control port on the set. 2. Remote Control IR Codes Output waveform Single pulse, modulated with 37.917 KHz signal at 455 KHz Carrier frequency FCAR = 1/TC = fOSC/12 Duty ratio = T1/TC = 1/3...

  • Page 90: External Control Device Setup

    All manuals and user guides at all-guides.com APPENDIX EXTERNAL CONTROL DEVICE SETUP RS-232C Setup Connect the RS-232C (serial port) input jack to an RS-232C IN (CONTROL & SERVICE) external control device (such as a computer or an A/V control system) to control the product’s functions exter- nally.
  • Page 91 All manuals and user guides at all-guides.com APPENDIX Set ID Use this function to specify a set ID number. Refer to ‘Real Data Mapping’ . p p . . 9 9 3 3 OPTION OPTION Move Enter Move Enter Language : English Language : English...

  • Page 92: Transmission / Receiving Protocol

    All manuals and user guides at all-guides.com APPENDIX Command Reference List DATA DATA C C O O M M M M A A N N D D 1 1 C C O O M M M M A A N N D D 2 2 C C O O M M M M A A N N D D 1 1 C C O O M M M M A A N N D D 2 2 (Hexadecimal) (Hexadecimal)
  • Page 93 All manuals and user guides at all-guides.com APPENDIX 0 0 1 1 . . P P o o w w e e r r ( ( C C o o m m m m a a n n d d : : k k a a ) ) 0 0 6 6 .
  • Page 94 All manuals and user guides at all-guides.com APPENDIX 1 1 2 2 . . O O S S D D S S e e l l e e c c t t ( ( C C o o m m m m a a n n d d : : k k l l ) ) 1 1 8 8 .
  • Page 95 All manuals and user guides at all-guides.com APPENDIX Data5: Main/Sub Two/One Using Physical Step Part Channel Reserved Picture Channel Main NTSC Air No Use NTSC Cable ATSC Air ATSC Cable_std ATSC Cable_hrc ATSC Cable_irc ATSC cable_auto Reserved Reserved The table above lists the binary code which must be converted to Hexadecimal before sending.
  • Page 96 All manuals and user guides at all-guides.com P/NO : 3840TRL098E (0801-REV00)
  • Page 97 All manuals and user guides at all-guides.com...
