Summary of Contents for GBD BARR500
- Page 1 BARR500 BARR500 - (524 - 526) Electromechanical barriers INSTRUCTIONS FOR INSTALLATION...
-
Page 3: Installation Warnings
The new 24 VDC automatic electromechanical barrier for easy system control with booms of up to 6 metres and high- speed opening. With a contemporary design and new technological solutions, BARR500 is the right answer to all these requirements. Designed for easy adaptation to the EN 12453 standards. -
Page 4: Warnings For The User
BARR500 WARNINGS FOR THE USER In the event of an operating fault or failure, cut the power upstream of the control unit and call Technical Service. Periodically check good functioning of the safety devices. Any repairs must be carried out by specialised personnel using original and certified materials. - Page 5 BARR500 TECHNICAL DATA OPERATOR BARR524 BARR526 Electric motor 24Vdc 1600 RPM 24Vdc 3350 RPM 220/230Vac, single-phase, 50-60Hz Supply voltage Motor power supply 24Vdc 24Vdc Power absorbed MAX 150W MAX 200W Operating temperature -20°C +60°C -20°C +60°C Degree of protection IP 44...
-
Page 6: Preliminary Warnings
BARR500 PRELIMINARY WARNINGS • There must not be obstacles of any kind in the range of action of the operator. • The foundation plinth must be laid in an area free of cables and ducts and such as to guarantee adequate hold of the plinth. - Page 7 BARR500 RIGHT-LEFT BOOM CONVERSION 1 - Unscrew the two locking grub screws 1 (13) and the two long grub screws 2 (13) that act as mechanical end stop. 2 - Release the operator with the wrench 3 (13) provided acting on the release rod 4 (13).
-
Page 8: Spring Installation
BARR500 SPRING INSTALLATION The BARR524 and BARR526 barriers are supplied without springs, which must be chosen based on the length of the boom and the accessories fitted on the boom. Once you have chosen the right springs for the specific installation, follow these simple instructions: 1 - Release the operator (see the section MANUAL MANOEUVRE) 2 - Move the boom into vertical position by hand. - Page 9 BARR500 Boom lenght (m) OPTIONALS AVAILABLE FOR BOOM OUTLINE 100x66 mm Boom Boom Lights Boom Edge Boom Edge Lights Boom End Foot Boom End Foot Lights Boom End Foot Edge Boom End Foot Edge Lights Boom Rack Boom Rack Lights...
-
Page 10: Control Unit Installation
BARR500 MECHANICAL END-STOP ADJUSTMENT The mechanical end-stops can be adjusted by acting on the two grub screws accessible through the holes 1 and 2 (26) in the support plate of the control unit container. To access the two long adjustment grub screws, completely unscrew the two short grub screws that lock the long grub screws. - Page 11 BARR500 ELECTRICAL LIMIT SWITCH ADJUSTMENT The electrical limit switches must always be adjusted with the operator disconnected from the mains. Remove the front cover to access the limit switch unit composed of: • A fixed stainless steel disc 1 (29) that must not be moved.
-
Page 12: Accessories Available
BARR500 BOOM SUPPORT COUPLING UNINSTALLATION If the spring is fitted and you think that the operator will need to be released after removing the boom coupling, first follow the Balancing device detachment procedure. The boom must be in horizontal position. -
Page 13: Maintenance
BARR500 BOOM LIGHTS (38) Two light tubes can be fitted on the standard boom profile to enhance boom visibility. Figure 38 shows the correct way to install the light tube. The power cable (1) runs through the hollow section of the boom where it is connected to the light tube (3) which in its turn is housed in the seats cut into the profile until terminating at the same side as the power cable (2). - Page 14 BARR500 CE Declaration of conformity The manufacturer: GI.BI.DI. S.r.l. Via Abetone Brennero, 177/B, 46025 Poggio Rusco (MN) ITALY Declares that the products: ELECTROMECHANICAL BARRIERS BARR524-526 Are in conformity with the following CEE Directives: • EMC Directive 2004/108/CE and subsequent amendments;...
-
Page 15: Extraordinary Maintenance
BARR500 EXTRAORDINARY MAINTENANCE Date: Date: Installer company stamp: Installer company stamp: Technician sign: Technician sign: Date Date Notes Notes Technician sign Technician sign Date: Date: Installer company stamp: Installer company stamp: Technician sign: Technician sign: Date Date Notes Notes Technician sign... - Page 16 BARR500 NOTE...
- Page 17 BARR500 NOTE...
- Page 18 GI.BI.DI. S.r.l. Via Abetone Brennero, 177/B 46025 Poggio Rusco (MN) - ITALY Tel. +39.0386.52.20.11 Fax +39.0386.52.20.31 E-mail: info@gibidi.com Numero Verde: 800.290156 w w w . g i b i d i . c o m...
