24'' Tumble Dryer

MVD420W

Congratulations on the purchase of your new Marathon Tumble Dryer !

To activate your Warranty, please register your appliance at www.stirlingmarathon.com

or by completing and mailing the enclosed Warranty Registration Card. We are confident

you will have years of hassle-free enjoyment and ask that you please retain the Use &

Care Guide for future reference and your safety.

Before installing please, read your Use & Care Guide carefully and pay special attention

to the Safety & Warning information outlined in the following pages.

For immediate assistance: 1-844-309-9777

www.stirlingmarathon.com

Table of Contents

Need help?

Do you have a question about the MVD420W and is the answer not in the manual?

Questions and answers

Summary of Contents for Marathon MVD420W

Page 1 24'' Tumble Dryer MVD420W Congratulations on the purchase of your new Marathon Tumble Dryer ! To activate your Warranty, please register your appliance at www.stirlingmarathon.com or by completing and mailing the enclosed Warranty Registration Card. We are confident you will have years of hassle-free enjoyment and ask that you please retain the Use &...
Page 2: Appliance Safety
MVD420W Appliance Safety Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. Icon Caption Description WARNING Risk of serious injury or death...
Page 3: Quick Start
MVD420W Quick Start Please check the user manual for detailed information . Separate your clothes according to their types, place into the machine and close the door. Select the suitable program for your laundry by rotating the adjustment knob. You can select additional functions for drying.
Page 4 MVD420W Primary considerations • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Page 5: Important Safety Instructions
MVD420W Important Safety Instructions This section contains safety instructions that will help protect you from risk of personal injury or property damage. Failure to follow these instructions will void any warranty. Electrical Safety • The appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by a utility.
Page 6 MVD420W Important Safety Instructions WARNING • Read all instructions before using the appliance. • Do not dry articles that have been previously cleaned in, washed in, soaked in, or spotted with gasoline, dry-cleaning solvents, or other flammable or explosive substances, as they give off vapours that could ignite or explode.
Page 7: Children's Safety
MVD420W Important Safety Instructions Children's Safety • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Page 8 MVD420W Underwear that contains metal reinforcements should not be put in the dryer. The dryer may be damaged if metal reinforcements come loose and break off during drying. Never stop a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated.
Page 9: Installing On Top Of A Washing Machine
MVD420W Important Safety Instructions IMPORTANT The clearance between the dryer and the floor should not be reduced with objects such as carpets, wood or panel, otherwise, sufficient air intake cannot be ensured for the machine. • Do not install the dryer in rooms where there is risk of freezing. Freezing temperatures negatively affect the dryers performance.Condensation that freezes in the pump and hose may cause damage.
Page 10: Installation
MVD420W Installation Install the clothes dryer according to the manufacturer’s instructions and local codes. WARNING RISK OF FIRE • Clothes dryer installation must be performed by a qualified installer. • Do not install a clothes dryer with flexible plastic venting materials. If flexible metal (foil type) duct is installed, it must be of a specific type identified by the appliance manufacturer as suitable for use with clothes dryers.
Page 11 MVD420W In products with a condenser unit, water accumulates in the water tank during the drying process. You must empty the accumulated water after each drying process. Instead of periodically emptying the water tank, as an option, you can also use a water drain hose to directly drain the water outside.
Page 12 MVD420W There is risk of fire and electric shock. • Your dryer is set to 208-240 V and 60 Hz. Operating your machine at low voltage values will shorten the service life and decrease the performance of your machine. • This appliance is supplied with a UL listed NEMA 14-30P 240V / 30A 4-wire supply cord, 5 ft.
Page 13 MVD420W 3. Remove the terminal block screws which are indicated by A and grounding screw which is indicated by B. Neutral ground conductor (central terminal) is provided in the dryer as a closed loop. 4. Connect the ground conductor (green wire) under the terminal B.
Page 14 MVD420W OVERVIEW 1. Upper tray 2. Control panel 3. Loading door 4. Ventilation grills 5. Plinth opening slot 6. Adjustable feet 7. Plinth 8. Type plate 9. Lint filter Drawer Cover...
Page 15: Preparing The Laundry
MVD420W Preparing the laundry Sorting the Laundry to be Dried Follow the instructions on the labels of the laundry to be dried. Only dry items that have a statement/ symbol that indicates "they can be dried in a dryer". • Do not operate the product with load amounts and laundry types other than those given in 4.3.
Page 16: Load Capacity
MVD420W Preparing the laundry Risk of explosion and fire! Remove all objects from pockets such as lighters and matches. ATTENTION The drum of the dryer and the fabrics may get damaged. • The clothes may have become entangled during the washing process. Separate them from each other before placing them in the dryer.
Page 17: Using The Tumble Dryer
MVD420W Using the Tumble Dryer Control Panel 1. Program Selection Knob Use the program selection knob to select the desired drying program 2. Electronic Indicator and Display Symbol Symbol Meaning Symbol Symbol Meaning Water tank warning indicator Delay Timer Lint filter cleaning warning indicator Anti-crease 60‘...
Page 18: Program Selection And Consumption Table
MVD420W Using the Tumble Dryer Program Selection and Consumption Table Press the Start/Pause button to start the program. The Start/Pause LED that indicates that the program has started and the Drying LED will come on. Approximate Waching machine amount of...
Page 19: Auxiliary Functions
MVD420W Using the Tumble Dryer Auxiliary Functions The table that summarises the options that can be selected in programs is given below Option Description "Select the drying target suitable for your laundry to be dried. Select Extra Dry for thick and multilayer laundry that takes time to dry. Select Drying Level Regular Dry for regular, single-layer laundry.
Page 20: Starting The Program
MVD420W Using the Tumble Dryer Starting the Program The Start/Pause LED will flash during program selection.Press the Start/Pause button to start the program. The Start/Pause LED indicates that the program has started and the drying LED will come on. Program...
Page 21 MVD420W Using the Tumble Dryer OPTIONS ProgramS Drying Delay Buzzer Child Time Level Anti- Temperature Delicate Level Start Cancel Lock Drying Adjust wrinkle Level Normal Outdoor Towels Warm Refresh Air Fluff Time Drying Sanitize Baby Care Delicates Perm Press Bulky...
Page 22 MVD420W Using the Tumble Dryer Selection Stand By After 15 minutes without user action in selection mode, machine goes to energy-saving mode due to decrease energy consumption. When the knob position is changed in energy-saving mode the control dial LED should be on in every selection, nothing is shown on the display.
Page 23: Cleaning And Care
MVD420W Cleaning and Care IMPORTANT Do not use industrial chemicals to clean your dryer. Do not use a dryer that has been cleaned with industrial chemicals. Cleaning the Lint Filter IMPORTANT DO NOT FORGET TO CLEAN THE LINT FILTER AFTER EACH USE.
Page 24 MVD420W Cleaning and Care Emptying the Water Tank 1. Pull the drawer cover and carefully take out the tank. 2. Empty the water in the tank. 3. If there is lint accumulated on the discharge cap in the tank, clean it with water.
Page 25 MVD420W Cleaning and Care Cleaning the Humidity Sensor Inside the machine, there are humidity sensors that detect whether the laundry is dry or not. To clean the sensors: 1. Open the loading door of the machine. 2. If the machine is still hot due to the drying process, wait for it to cool down.
Page 26: Technical Specifications
MVD420W TECHNICAL SPECIFICATIONS Brand MARATHON Model name MVD420W *Height (A) Min: 845 mm / Max: 855 mm* Width (B) 596 mm Depth (C) 639 mm Door open dept (D) 1120 mm **Capacity (max.) 10 kg** Net weight (with glass door)
Page 27: Troubleshooting
Troubleshooting You can solve many common refrigerator problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling for service. PROBLEM REASON SOLUTION The surface of the lint filter might be Wash the filter with lukewarm water.
Page 28 Troubleshooting PROBLEM REASON SOLUTION Check the care labels on the Clothes have shrunk, felted or The program used might not be laundry items, select a suitable deteriorated. suitable for the type of laundry. program for the type of laundry. There might be lint accumulated on Clean the inner surfaces of the the inner surfaces of the loading Water leaking from the loading door.
Page 29: Energy Efficiency
Troubleshooting AUTOMATIC FAULT WARNINGS AND WHAT TO DO Your tumble dryer is equipped with a built-in fault detection system, indicated by a combination of flashing operation lights. The most common failure codes are shown below. ERROR CODE SOLUTION Contact the nearest authorised service agent. Empty the water tank, if problem does not solved, E03 / contact the nearest authorised service agent.
Page 30: How To Obtain Service
When operated and maintained according to the instructions in the Use & Care Guide, MARATHON a registered trademark of Stirling Marathon Limited agrees to repair this product for 2 years from the date of original purchase and/or agrees to pay for parts and service/labour required to correct defects in materials or workmanship.
