Arivia M4155
Arivia M3145
User's Manual
Before using the machine, please read this manual thoroughly. Be sure to keep this manual for future reference.
This manual may not be edited, modified or copied in whole or part without the written consent of the publisher.
■
Some parts of this manual are subject to change without prior notice.
■
The screen shots and the illustrations in this manual are used as examples. They may differ from yours depending
■
on the model, the software, or the OS.
Control Panel
Features of Control Panel
Pressing the Home button displays the Home
screen.
1.
Power/Power Saving button
The power switches on.
Note
When "Please wait..." is displayed, the machine
■
is warming up. The use of machine is not avail-
able during this time.
If the power does not switch on, confirm that
■
the power plug is inserted.
2.
Data indicator
This indicator blinks while data is being sent from the
machine or data is being received from the client com-
puter.
Also, this indicator lights up when documents are saved
in the machine or the fax is stored in a local folder.
3.
Status display lamp
The lamp lights up in green at an instant of operation
reception. When an error occurs, the lamp blinks in
orange.
4.
Login
The user is authenticated when the user enters the
User ID and logs in.
When the user is logged in with the administrator
rights, [Administrator] is shown in this area. While the
user is authenticated, tapping it logs out the user, and
the state becomes as unauthenticated.
5.
Opening menu
Tap this to open the menu for change and check the
settings of the machine.
Tap on [<] to close the menu.
Electronic user manuals are available on the official website.
Please go to the official website
Home Button
.
https://support-kbs.katun.com
© 2024 Katun Corporation. April 2024 GM1592E9-2 Edition 1
[Apps]
4
1
5
[Pause]
2
3
6.
Home Screen
Apps/Pins/Address Screens can be displayed.
• [Apps]: You can tap on any of the application icons
and use its functions.
• [Pins]: You can execute a job again using Job Direc-
tion History and the job direction history pinned by
the user with [Create Pin]. If you create a pin of the
job direction history, you can also directly activate a
job without opening an application.
• [Addresses]: You can register addresses and other
information. You can activate an application from a
registered address.
After activating an application, the selected address
is set as the destination of the application.
[Pins] [Addresses]
6
