- Page 1 All-in-one Energy Storage System BR-AIO-LV-SR 11.77KWH+10KW BR-AIO-LV-SR 23.54KWH+10KW...
-
Page 2: Table Of Contents
Content 1. Safety Instructions ______________________________________________________________ 01 1.1 Safety precautions___________________________________________________________ 01 1.2 Equipment operating environment requirements ___________________________02 2. Product overview _______________________________________________________________03 2.1 Label Explanation ____________________________________________________________04 2.2 Battery box interface introduction __________________________________________05 2.3 Introduction to the inverter box interface ___________________________________06 2.4 Battery module unit _________________________________________________________07 2.5 Inverter module unit_________________________________________________________08 2.6 Appearance of the stacked battery system_________________________________ 10 2.7 Performance parameters of stacked battery system _______________________ 11... -
Page 3: Safety Instructions
BASENGREEN, YOUR RELIABLE POWER Thank you for purchasing the lithium battery products of Shenzhen BASENGREEN Technology Co., Ltd.! 1. Safety Instructions This manual will provide detailed product information and installation instructions for users of the All in one series products. Please read this manual carefully, and put this manual in a place where you can install, operate, and obtain it conveniently. -
Page 4: Equipment Operating Environment Requirements
BASENGREEN, YOUR RELIABLE POWER Disconnect power during operation It is strictly prohibited to install or remove the power cord while the power is on. Before installing or removing the power cord, the power switch must be turned off. Before connecting the cables, please confirm that the connecting cables and cable labels match the actual installation conditions. -
Page 5: Product Overview
BASENGREEN, YOUR RELIABLE POWER The battery operating environment should meet the following requirements: a. Comply with the technical specifications for equipment operation (temperature: 0℃~40℃, relative humidity: 0%~95%). b. Provide good ventilation and keep away from water, heat and flammable and explosive materials. -
Page 6: Label Explanation
BASENGREEN, YOUR RELIABLE POWER 2.1 Label Explanation The label contains the following information Guangdong Basen Green New Energy Co.,Ltd ALL IN ONE ENERGY STORAGE SYSTEM Max.PV array power PV INPUT MPPT Voltage Range Input Voltage Range MAINS / GENERATOR INPUT... -
Page 7: Battery Box Interface Introduction
BASENGREEN, YOUR RELIABLE POWER 2.2 Battery box interface introduction: ①: P- battery negative pole ②: P+ battery positive pole ③: RS485C port ④: RS485B port ⑥: RS485A/CAN port ⑤: RS232 port ⑦: ALM indicator light ⑧: Running lights ⑨: Ground wire interface ⑩: SOC capacity indicator... -
Page 8: Introduction To The Inverter Box Interface
BASENGREEN, YOUR RELIABLE POWER 2.3 Introduction to the inverter box interface: ①: PV1 Port ②: PV2 Port ③: DRY CONTACT PORT ④: RS485/CAN Port ⑤: WIFI Port ⑥: USB Port ⑦: Connection Port ⑧: Parallel Port ⑨: AC Input Breaker ⑩: Connect to P-battery negative pole... -
Page 9: Battery Module Unit
BASENGREEN, YOUR RELIABLE POWER 2.4 Battery module unit Battery module unit performance parameters Name Specification Remark Battery pack specifications and models 51.2V230AH Battery box series and parallel number 16 serial 1 parallel Battery box dimensions W750*D650*H253mm Battery box weight 103KG Battery box voltage range 43.2V-58.4V... -
Page 10: Inverter Module Unit
BASENGREEN, YOUR RELIABLE POWER 2.5 Inverter module unit Inverter Module Unit Performance Parameters SPI-10K-SP-EU Model BATTERY Battery Type Li-ion/ Lead-Acid/ User Defined Battery Voltage Range (V) 48Vdc Voltage Range 40~60Vdc Max.MPPT Charging Current 200A Max.Mains/Generator Charging 100A 120A Max.Hybrid Charging Current... - Page 11 BASENGREEN, YOUR RELIABLE POWER PV INPUT Num. of MPPT Trackers Max.PV Array Power 11000W Max.Input Current 22/22A Max.Voltage of Open Circuit 500Vdc MPPT Voltage Range 125~425Vdc UTIUTY/ GENERATOR INPUT Input Voltage Range 90~275Vac Frequency Range 50/60Hz Bypass Overload Current EFFICIENCY MPPT Tracking Effciency 99.9%...
-
Page 12: Appearance Of The Stacked Battery System
BASENGREEN, YOUR RELIABLE POWER 2.6 Appearance of the stacked battery system 11.7kWH 23.4kWH... -
Page 13: Performance Parameters Of Stacked Battery System
BASENGREEN, YOUR RELIABLE POWER 2.7 Performance parameters of stacked battery system Specification Name Remark Battery Type Lithium iron phosphate battery 51.2V230AH 51.2V460AH Product number 51.2V 51.2V Rated voltage 230Ah 460AH Rated Capacity 23.54kWh 11.77kWh Rated power W750*D650 W750*D650 Push stack size... -
Page 14: Installation Tools
BASENGREEN, YOUR RELIABLE POWER 3.2 Installation tools Tool Clamp ammeter Phillips screwdriver Electric batch Protective gloves Multimeter Socket wrench 3.3 Connection P- line P+ line RS485 line RS485A port is used for communication between the inverter box and the battery box, it can also use for communication with the upper monitor system. -
Page 15: Dip Switch Definition And Setting
BASENGREEN, YOUR RELIABLE POWER 4. DIP switch definition and setting Please refer to the table below to set the DIP switch for parallel connection. 4-BIT Dip Switch Position Address Illustration 1 2 3 4 1 2 3 4 1 2 3 4... -
Page 16: Inverter Setup Instructions
BASENGREEN, YOUR RELIABLE POWER 5. Inverter Setup Instructions 5.1 Description of settings 00: Exit 17: Battery equalization charging voltage 01: AC output source priority 18: Battery equalization charging duration 02: AC output frequency 19: Battery equalization charging delay time 03: AC input voltage range... -
Page 17: 08"-Battery Type
BASENGREEN, YOUR RELIABLE POWER Figure 1 Figure 2 Figure 3 Figure 4 5.2.2 “08”-Battery Type Press the “△” key to the “08” item, at this time, the “08” item keeps flashing, Press the “✓” key to confirm the setting of the “08” item (as shown in Fig. 5), there are lead-acid, lithium-ion, ternary, and other modes. -
Page 18: 32"-Rs485 Communication
BASENGREEN, YOUR RELIABLE POWER BASENGREEN, YOUR RELIABLE POWER Figure 5 Figure 6 5.2.3 “32”-RS485 communication Press the “△” key to the “32” item, at this time, the “32” item keeps flashing, press the “✓” key to confirm the setting of “32” items (as shown in Fig. 7). -
Page 19: Switch The Battery Communication Protoco
BASENGREEN, YOUR RELIABLE POWER 5.2.5 Switch the battery communication protocol Check the screen of the battery module, press the “menu” button, and press the “▽” key (as shown in Fig. 12) to reach the “CommType Set” part, then press the “ENTER” key to select 485-Pylon (as shown in Fig. -
Page 20: Battery Storage And Transportation Instructions
BASENGREEN, YOUR RELIABLE POWER 6. Battery storage and transportation instructions • According to the characteristics of the battery, the lithium battery pack should meet its storage environmental conditions during storage and transportation to maximize performance of protecting the battery. • During storage and transportation, lithium batteries should be properly protected to maintain an SOC level of about 50% to 70% to ensure that there is no short circuit or liquid entering the lithium battery pack or being immersed in liquid (such as water, oil, etc.) -
Page 21: Maintenance
BASENGREEN, YOUR RELIABLE POWER • It is necessary to check the battery voltage and connections before installation. It can be used only after everything is normal. • The battery is stored half-charged. If the battery has not been used for three months, it needs to be recharged once. -
Page 22: Revision Of Product Specifications
BASENGREEN, YOUR RELIABLE POWER 9. Revision of product specifications Our company reserves the right to interpret and revise this product specification without prior notice if the version is upgraded. 10. Configuration list Dimensions Weight Serial Item Name Quantity (width/depth/height)mm (KG) - Page 23 Need additional information? Just Contact BASEN! BASENGREEN YOUR RELIABLE POWER Fax: (+86)0755-84737145 Tex: (+86)130 0887 9993 Email: info@Basengroup.com Shenzhen Basen Technology Co., Ltd. Add: Room 303,Building 3, 1980 Culture and Technology Industrial Park, Donghuan Road,Longhua District,Shenzhen...
