USER AND SERVICE INSTRUCTION
USER AND SERVICE INSTRUCTION
USER AND SERVICE INSTRUCTION
RTPM 125 – 150 – 175
RTPM 125
Please read the following instructions carefully before operating the machine and refer to them as
Please read the following instructions carefully before operating the machine and refer to them as
Please read the following instructions carefully before operating the machine and refer to them as
needed. If you do not understand a part of the user manual, please contact your MAJAR reseller or:
needed. If you do not understand a part of the user manual, please contact your MAJAR reseller or:
needed. If you do not understand a part of the user manual, please contact your MAJAR reseller or:
MANUAL
SPARE PART LIST
Professional Rotary Trimmer
Professiona
MAJAR S.A
1 Route de Montréal - CS30074
11890 CARCASSONNE Cedex 9
Phone 0033 / 4 68 25 38 16
Rotary Trimmer
01/2019
175
Advertisement
Table of Contents
Related Manuals for MAJAR RTPM 125
Summary of Contents for MAJAR RTPM 125
- Page 1 Please read the following instructions carefully before operating the machine and refer to them as needed. If you do not understand a part of the user manual, please contact your MAJAR reseller or: needed. If you do not understand a part of the user manual, please contact your MAJAR reseller or: needed.
- Page 2 SERIAL N°: ....In line with the goals of continuous improvement MAJAR reserves the right to change the machines without In line with the goals of continuous improvement MAJAR reserves the right to change the machines without In line with the goals of continuous improvement MAJAR reserves the right to change the machines without changing the sold machines.
-
Page 3: Technical Data
** The mentioned weights do not include possible options that can be mounted on the machine INSPECTION CHECKLIST The assembly, installation and commissioning of the machine is the MAJAR reseller’s responsibility. Please read carefully the use and care manual and the safety regulations. Make sure that the indicated points of the checklist had been verified before delivery and on delivery and amended if necessary before delivering the machine to the owner. -
Page 4: Safety Regulations
SAFETY REGULATIONS SAFETY REGULATIONS WARNING Some illustrations may show the machine without illustrations may show the machine without *Do not use the machine on too big slopes *Do not use the machine on too big slopes. protective screen or shield. Never use the machine protective screen or shield. -
Page 5: Safety Stickers
It is strictly forbidden to remove the safety stickers ans et symbols specifying danger. Missing or specifying danger. Missing or damaged stickers must be replaced immediately damaged stickers must be replaced immediately. Contact your MAJAR reseller. . Contact your MAJAR reseller. The information illustrated by these symbols must be necessarily respected. The The information illustrated by these symbols must be necessarily respected. - Page 6 EMPLACEMENT OF THE SAFETY STICKERS AND THE IDENTIFICATION PLATE CE Identification Plate.
- Page 7 MONTAGE OF ROTARY TRIMMER MONTAGE OF ROTARY TRIMMER MONTAGE OF ROTARY TRIMMER MONTAGE AFTER RECEPTION RECEPTION Guidange rod and cardan protection: 1) Place the guidance rod (1) using using 8 screws M14x40, 8 flat washers MN14, 8 washers W W and 8 nuts M14. 2) Place the protective covering of the the protective covering of the cardan (2) on the guidance rod using 2 screws M10x25...
-
Page 8: Installation And Commissioning
INSTALLATION AND COMMISSIONING INSTALLATION AND COMMISSIONING The installation and commissioning of the to The installation and commissioning of the tool are the responsibility of the MAJAR reseller. MAJAR reseller. The rotary slasher must be delivered fully mounted fully mounted, lubricated and adjusted to the normal operating conditions lubricated and adjusted to the normal operating conditions. - Page 9 • CARDAN SHAFT SETTING UP DANGER More detailed information in the specific manual of the cardan More detailed information in the specific manual of the cardan More detailed information in the specific manual of the cardan which is an initial part of the safety documentation to read carefully. In the event of a discrepancy with the initial part of the safety documentation to read carefully.
- Page 10 ADJUSTMENT AND USE ADJUSTMENT AND USE Check the tightening of the bolts (see table tightening torque at the end of the manual. Check the tightening of the bolts (see table tightening torque at the end of the manual. Check the tightening of the bolts (see table tightening torque at the end of the manual. Check the presence and fixation of safety equipment (carter, bol …).
- Page 11 • COVER ADJUSTMENT For a thick ploughing, lift moderately the For a thick ploughing, lift moderately the cover. For a thin ploughing, lower the cover the cover. Adapte the speed to suit your ploughing choice Adapte the speed to suit your ploughing choice. Place the corresponding link of the chain to the chosen height in the Place the corresponding link of the chain to the chosen height in the upper hook upper hook.
- Page 12 WARNING Always wear close Always wear close-fitting clothing to avoid to be snatched by the moving parts. fitting clothing to avoid to be snatched by the moving parts. Use safety footwear and protective equipment for eyes, ears Use safety footwear and protective equipment for eyes, ears and protection from the dust. and protection from the dust.
-
Page 13: Maintenance By User
MAINTENANCE BY USER MAINTENANCE BY USER DANGER Prior to maintenance or repair work on the machine, stop the engin Prior to maintenance or repair work on the machine, stop the engin Prior to maintenance or repair work on the machine, stop the engine, apply the handbrake and remove the key. - Page 14 , apply the handbrake and remove the key. DANGER When you replace the blades, you are required to change the locknuts. Contact your MAJAR reseller to When you replace the blades, you are required to change the locknuts. Contact your MAJAR reseller to When you replace the blades, you are required to change the locknuts.
-
Page 15: Malfunction And Remedy
MALFUNCTION AND REMEDY PROBLEME CAUSE REMEDE Transmission The rotor bearings are worn or Have the machine controlled by reseller system is noisy damaged and replace bearings The sprockets and bearings of the Have the machine controlled by reseller, gearbox are worn bend the belts or change chain tensioner... -
Page 16: Declaration C.e. De Conformite
DECLARATION C.E. DE CONFORMITE The letters CE on the identification plate of this machine certify that it is conforming to EC machine directive 2006/42/CE. The Director, Jean-Luc Checa... - Page 17 This guarantee does not oblige MAJAR or representative to reimburse labor costs or transport costs of the machine for reparation.
-
Page 18: Spare Part List
SPARE PART LIST According to Article L.111-3 of the Consumer Code and of the Decree implementing the Code N°2014-1482 of 9th of December 2014, the availability duration of indispensable spare parts for use of MAJAR material is 7 years. - Page 22 RTPM 125 Nb Reference Designation 082814 SHAFT CIRCLIP Ø45 082815 SHAFT CIRCLIP Ø50 186639 SPLINED SHAFT 186643 SMOOTH SHAFT 082631 SUPERIOR AXLE CAT.2 Ø25 081942 CRUTCH 082822P GEARBOX RF40 1.83 L600 082823P GEARBOX RF40 1.83 L700 082824P GEARBOX RF40 1.83 L800 082818 PLUGG + SEAL M12 X 1.5...
- Page 23 RTPM 125 Rep, Reference Designation 582643 PIN COUPLING 186648 REAR DEFLECTOR 9900546 LOCKNUT H M16 9900218 NUT H M16 075568 RING PIN Ø10 082675 FLAT SEAL Ø21 9960703 SCREW CC Ø10x25 9908052 CONTACT WASHER 016 9908016 WASHER MN 0 16...
- Page 24 1 Route de Montréal CS30074 11890 CARCASSONNE Cedex 9...
