VT+

Actionneurs électriques

Manuel d'Installation et d'Utilisation

Installation and Operation Manual

Installations- und Bedienungsanleitung

Manual de instalación y funcionamiento

Facteur de marche

Indice de protection

600Nm

50%

IP68

Duty cycle

Enclosure protection

Anticondensation

Positionnement

intégrée

POSI

Anticondensation

BLUETOOTH

Heater

Positioning

p.2

p.18

p.34

p.50

Battery

Backup

BBPR

Table of Contents

Need help?

Do you have a question about the VT+ and is the answer not in the manual?

Questions and answers

Summary of Contents for AXMART VT+

Page 1 Actionneurs électriques Manuel d’Installation et d’Utilisation Installation and Operation Manual p.18 Installations- und Bedienungsanleitung p.34 Manual de instalación y funcionamiento p.50 Anticondensation Positionnement Facteur de marche Indice de protection 600Nm intégrée Battery Backup IP68 POSI BBPR Anticondensation BLUETOOTH ® Duty cycle Enclosure protection Heater Positioning...
Page 2: Table Of Contents
Electronic boards  Operating modes  Wiring: modulating 3-point • On-off • Pulse control  Positioning function  AXMART ® Bluetooth ® function BBPR emergency battery system (option) ..............30 Codiﬁcation ........................31 Technical data ....................... 32 This product meets the European Directive 2012/19/UE about electrical and electronic equipment (DEEE). It mustn't be mixed with common waste.
Page 3: Transport And Storage
INTRODUCTION This manual has been made to guide you through the installation and use of our VT+ electric actuators. Please, read it carefully before using our products and be sure to keep it. DESCRIPTION These electric actuators have been designed to perform the control of a valve with 90° rotation. We cannot be held responsible for any other use.
Page 4: Dimensions
Dimensions : 600 and 1000Nm models Star (mm) Depth (mm) ISO 5211 connection Diameter (mm) M threated Depth (mm) Screw number DSBA3600 • Rév. 05/11/2020...
Page 5 Dimensions : 1500 and 2400Nm models Star (mm) Depth (mm) ISO 5211 connection Diameter (mm) M threated Depth (mm) Screw number DSBA3600 • Rév. 05/11/2020...
Page 6 Electric wiring: warnings  As stipulated in the applicable regulation, the connection to earth contact is compulsory for devices with working voltages exceeding 42V.  The actuator is being always under power, it must be connected to a disconnection system (switch, circuit breaker) to ensure the actuator’s power cut.
Page 7: Multipin Connector
Multipin connector 1 Seal 2 Removable connector 3 4 x M3x10 screws 4 4 x CHC M6x30 Stainless steel A2 screws 5 3 x ISO M20 x 1,5 cable glands 6 Connector cover To wire the actuator, unscrew the 4 CHC M6x30 screws, and the 4 M3x10 screws.
Page 8: Electronic Card
Electronic card High voltage card (SNBA050000) : 100V to 240V AC 50/60Hz and 100V to 300V DC Low voltage card (SNBA051000) : 24V o 48V AC 50/60Hz and 24V to 72V DC POWER SUPPLY 100V to 240V AC 50/60Hz and 100V to 300V DC 24V to 48V AC 50/60Hz and 24V to 72V DC TP/PE 1 Power supply terminal...
Page 9: Functioning Modes
® software. MART  Weekly scheduler (Bluetooth ® ) : thanks to AXMART ® , you can assign up to 20 repeatable tasks to each actuator. This mode requires a smartphone or a tablet with the ® software.
Page 10: Permanent Wiring
Permanent wiring Permanent wiring 3-modulating points ON/OFF 13 14 15 16 17 18 13 14 15 16 17 18 Open Close Open Neutral Phase AC 50/60Hz Neutral Phase AC 50/60Hz Wiring • VT+ models with pulse control A feedback signal ( 4-20mA or 0-10V) is available from terminal 9 10-11...
Page 11: Positioning Function
Positioning function Validation led (pos.1) Led de validation (pos. 2) Learning mode - closed position Learning mode - storage Learning mode - open position Feedback Setpoint signal signal Learning mode  Put the power on  With the « Next Mode » and « Ok Mode » buttons, select the learning mode (the APPR led is on) ...
Page 12 Positioning function: wiring Setpoint signal + Setpoint signal feedback + ( feedback - feedback + ( Neutral Phase AC 50/60Hz The 0-10V and 4-20mA feed- back signals are not available at the same time. DSBA3600 • Rév. 05/11/2020...
Page 13: Weekly Scheduling
Bluetooth function ® Actuator status Thanks to ® , it’s possible to access to all actuator parameters in real time. MART Actuator setup Thanks to , it’s possible to set mode : ® MART  Wiring type in case of wire functioning, ...
Page 14 BBPR function (option) The BBPR function provides the actuator operating into a predetermined security position (open or closed) in case of power failure. This position can be set in AXMART ® The factory default conﬁguration is "normally closed" BBPR option required ON/OFF mode...
Page 15: Codification
Codiﬁcation 1000 . 600 600 Nm 1000 1000 Nm 1500 1500 Nm 2400 2400 Nm A Star 36 F10/F12 B Star 46 F14 C Star 46 F12/F16 D Special Keyway bore Ø40 F12/F16 (VT1500-2400) 0 Standard 3 Long operating time 100V to 240V 50Hz/ 60Hz and 100V to 300V DC 24V to 48V 50Hz / 60HZ...
Page 16: Technical Data
Technical data: 600 and 1000Nm models VT600 VT1000 Implantation Housing: Aluminium + EPOXY coating Materials Drive: Steel + Zn treatment Shafts and screws : Stainless steel Sealing IP 68 Environment Both inside and outside (wet environments possible) Operating temperature -20 °C to +70 °C (BBPR: -10 °C to +40 °C) ...
Page 17 Technical data: 1500 and 2400Nm models VT1500 VT2400 Implantation Housing: Aluminium + EPOXY coating Materials Drive: Steel + Zn treatment Shafts and screws : Stainless steel Sealing IP 68 Environment Both inside and outside (wet environments possible) Operating temperature -20°C to +70 °C (BBPR: -10 °C to +40 °C) ...
