INFINITY LIVING PRE-CHARGED LINE SET

WITH DIYCOOL TECHNOLOGY

INSTALLATION

MANUAL

IMPORTANT NOTE:

Read this manual carefully before installing or operating your

system. Please be sure to save this manual for future reference.

Version Date: 06-26-24

Table of Contents

Need help?

Do you have a question about the EZ Connect Pre-Charged Line Set and is the answer not in the manual?

Questions and answers

Summary of Contents for Infinity Living EZ Connect Pre-Charged Line Set

Page 1 INFINITY LIVING PRE-CHARGED LINE SET WITH DIYCOOL TECHNOLOGY INSTALLATION MANUAL IMPORTANT NOTE: Read this manual carefully before installing or operating your system. Please be sure to save this manual for future reference. Version Date: 06-26-24...
Page 2: Table Of Contents
Table of Contents Safety Precautions ............... 1 Troubleshooting ................2 Accessories ................... 8 Preperation & Connecting Line Set to Indoor Unit ....9 Connecting Line Set to Outdoor Unit ........11 Wrapping & Insulating Line Set Connections ......14 Electrical & Gas Leak Checks ............. 15 Test Run ..................16...
Page 3: Safety Precautions
Safety Precautions Read Safety Precautions Before Operation and Installation Incorrect installation due to ignoring instructions can cause serious damage or injury. The seriousness of potential damage or injuries is classiﬁed as either a WARNING or CAUTION CAUTION WARNING WARNING This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Page 4 CAUTION Turn o the air conditioner and disconnect the power if you are not going to use it for a long time. • Turn o and unplug the unit during storms. • Make sure that water condensation can drain unhindered from the unit. •...
Page 5 WARNINGS FOR PRODUCT INSTALLATION 1. Installation must be performed by an authorized dealer or specialist. Defective installation can cause water leakage, electrical shock, or re. 2. Installation must be performed according to the installation instructions. Improper installation can cause water leakage, electrical shock, or re. (In North America,installation must be performed in accordance with the requirement of NEC and CEC by authorized personnel only.) 3.
Page 6: European Disposal Guidelines
WARNING for Using R32/R290 Refrigerant When ammable refrigerant are employed, appliance shall be stored in a well -ventilated area where the room size corresponds to the room area as speci ec for operation. For R32 frigerant models: Appliance shall be installed, operated and stored in a room with a oor area larger than 4m . Appliance shall not be installed in an unvertilated space, if that space is smaller than 4m .
Page 7: Troubleshooting
Troubleshooting SAFETY PRECAUTIONS If ANY of the following conditions occurs, turn o your unit immediately! The power cord is damaged or abnormally warm • You smell a burning odor • The unit emits loud or abnormal sounds • A power fuse blows or the circuit breaker frequently trips •...
Page 8 Issue Possible Causes The outdoor unit The unit will make di erent sounds based on its current operating mode. makes noises Dust is emitted from The unit may accumulate dust during extended periods of non-use, which will be either the indoor or emitted when the unit is turned on.
Page 9 Problem Possible Causes Solution Wait for the power to be restored Power failure The power is turned o Turn on the power The unit is not The fuse is burned out Replace the fuse working Replace batteries Remote control batteries are dead The Unit’...
Page 10: Accessories
Accessories The quick-connect line set comes with the following accessories. Use all of the installation parts and accessories to install the air conditioner. Improper installation may result in water leakage, electrical shock and re, or cause the equipment to fail. The items are not included must be purchased separately.
Page 11: Preperation & Connecting Line Set To Indoor Unit
Preperation & Connecting Line Set to Indoor Unit WARNING! IMPORTANT INFORMATION The EQ valves are only designed for • Follow the instructions fully when connecting one-time installation. Their seal cannot the line set to the indoor & outdoor units. The be guaranteed if they are installed more warranty of the equipment will only be valid if the line set is installed correctly as described in...
Page 12 STEP 2: Connect Line Set to Indoor Unit 1. DO NOT remove the plastic seals from the line set connection points of the indoor unit, or from the line set connectors, until immediately before connecting the line set to the indoor unit. 2.
Page 13: Connecting Line Set To Outdoor Unit
Connecting Line Set to Outdoor Unit STEP 1: Remove condenser water tray and STEP 2: Connect Line Set to Outdoor Unit ensure check valves are tight. 1. DO NOT remove the plastic seals from the 1. Remove water tray (if applicable) from the line set connection points of the outdoor outdoor unit as shown in the image below.
Page 14 8. Now, using leak detection spray or a soapy IMPORTANT! water solution in a spray bottle, spray the Before you continue, it is essential you read the connections. If any bubbles appear, it following instructions fully and carefully. indicates there is a leak and the connection 6.
Page 15 STEP 4: Opening the King Valves (dependent 4. Using the images below as a guide, remove upon type of unit & capacity) the cover on the bottom valve using an 1. Depending on your application, some open-ended wrench. 5. Then, insert a 5 mm Allen key into the valve multi-zone condensers are equipped with two and open it by turning it counter-clockwise additional main valves, referred to as King...
Page 16: Wrapping & Insulating Line Set Connections
Wrapping & Insulating Line Set Connections STEP 1: Install sound deadening pads over STEP 3: Bundle and tape line set, line set connectors communication cable, and condensate drain pipe (dependent upon on application 1. Once the system has been checked and no leaks are found, wrap all of the indoor air and type of installation being performed) handler line set connectors with the...
Page 17: Electrical & Gas Leak Checks
Electrical and Gas Leak Checks Before Test Run WARNING – RISK OF ELECTRIC SHOCK Only perform test run after you have completed ALL WIRING MUST COMPLY WITH LOCAL the following steps: AND NATIONAL ELECTRICAL CODES, Electrical Safety Checks – Conﬁrm that •...
Page 18: Test Run
Test Run DOUBLE-CHECK PIPE CONNECTIONS Test Run Instructions During operation, the pressure of the You should perform the Test Run for at least 30 refrigerant circuit will increase. This may minutes. reveal leaks that were not present during your Connect power to the unit. initial leak check.
Page 19 NOTES Page 17...
Page 20 Any instructions, designs, or speci cations contained in this manual for the products, systems, or any associated accessories covered within it, are subject to change without prior notice due to constant product improvement. Consult with the sales agency or manufacturer for details. All materials for In nity Living products are available on the company website.
