Summary of Contents for motogadget CAYO moto.dokk
- Page 1 Instruction Manual moto.dokk Smartphone Mounting System V1.0...
- Page 2 CAYO - a brand of motogadget. Thank you for choosing a quality product from motogadget. Our products are developed and manufactured in Germany. Please read the following instructions completely and observe them when handling the device. No warranty claims will be made for damage resulting from failure to follow these instructions and motogadget GmbH accepts no liability.
-
Page 3: Checking The Delivery
1. Checking the delivery Every motogadget product is delivered in perfect condition and has been tested for functiona- lity. Please check the goods you receive for transport damage. If there is any damage, please contact us immediately. Our general terms and conditions of business and delivery apply in this regard. -
Page 4: Technical Data
3. Technical data • Dimensions: diameter 52mm, depth 40mm • Weight: 60g (without bracket) • Input: USB-C inlet (5V / 9V / 12V) • Charging Power: max. 10W • Temperature range: 0°C - +40°C (32°F - 104°F) • Rating: IP65 4. -
Page 5: Wireless Charging
5. Wireless Charging The charging power can vary during operation. It depends on the charging standard of the attached phone and the charging power requested by the phone. At air temperatures of 35°C or higher, the charging power is reduced to prevent overheating. When the phone is in constant use with navigation, the screen on, and charging simultaneous- ly, there is a possibility that at high outside temperatures the phone will limit the battery charge to 80% to protect the battery from premature aging. -
Page 6: Installation
6. Vibration decoupling If the smartphone is attached directly to the motorcycle, the camera lens mount can be dama- ged by engine vibrations. Therefore, the moto.dokk mount is decoupled from the rest of the component by 3 elastic absorbers. The intensity and therefore harmfulness of the vibrations depends on the amplitude and frequency. - Page 7 2 Nm ø35 mm ø31 ,8 mm, 1 " ø28.6 mm, 1 " ø25,4 mm, 1 " ø22,2 mm, "...
- Page 8 2 Nm...
-
Page 9: Status Indicator
8. Connection Insert the supplied USB cable with the USB-C plug into the connection socket of the moto.dokk. The locking lugs on the plug ensure that it sits securely during operation. To release the plug connection, gently press the fl exible plug housing together at the side and pull out the plug. 9. - Page 10 10. Attaching the Phone Loosely hook the opening on the back of the smartphone case or the adhesive pad into the upper, movable locking lug of the moto.dokk. Pull the phone down and swing it onto the lower, fi xed locking lug.
- Page 11 Declaration of conformity motogadget GmbH hereby declares that the product conforms to the applicable EU directives. The full text of the EU declaration of conformity is available at the following internet address: https://manuals.motogadget.com/cayo-moto-dokk...
- Page 12 Please dispose of this product by returning it to the point of sale or to your local municipal collection point for recycling. By doing this you will help conserve the environment. Regulations PRODUCT INFORMATION: Manufacturer: motogadget GmbH Model: moto.dokk FCC ID: 2AIF8-CA10000 FCC COMPLIANCE STATEMENT: This device complies with part 15c of the FCC Rules.
