- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. Four Seasons FS388 Owner's Manual Shop genuine replacement parts for Four Seasons FS388 Find Your Four Seasons Grill Parts - Select From 5 Models -------- Manual continues below --------...
- Page 2 USE AND CARE MANUAL For Model FS388LP Stop! Missing a part? DO NOT RETURN PRODUCT TO STORE The store where you made the purchase does not stock parts for this item. If you need parts, whether they are 1-800-229-5647 missing or damaged, please call Customer Service at Call us between 8:00 AM and 5:00 PM Eastern time, Monday through Friday or email us at saleshelp@sureheat.com FOR YOUR SAFETY:...
-
Page 3: General Safety Instructions
General Safety Instructions IMPORTANT SAFETY INFORMATION - Read this manual carefully before using your grill to reduce the risk of fire, burn hazard or other injury. - Extreme care should be used because of the high temperatures produced by this appliance. -
Page 4: For Your Safety
General Safety Instructions ▲ WARNING ▲ WARNING NOTE: DO NOT operate the main burners and DO NOT use the rotisserie in the rain. infrared back burner at the same time. This can cause warping of the roll top grill hood. WARNING ▲... -
Page 5: Grill Features
Grill Features 1. Roll top grill hood 10. Rear Infrared burner 2. Rotisserie kit 11. Side burner 3. Grilling/cooking surface 12. Electronic igniter: main burners, side burner, rear infrared burner and searing burner 4. Side shelf 13. Control Knob: Side burner 5. -
Page 6: Getting Started
Getting Started Self-tapping screw x 17 Phillips pan head screw x 2 Getting Started 1. Please follow the steps in the order that they are presented. 2. Assemble the grill where you plan to use it. 3. You may want to place an old towel or cloth at the assembly site to prevent nuts and bolts from becoming lost. -
Page 7: Grill Assembly
Grill Assembly STEP ONE a. Remove the four (4) wheel channel assembly nuts and two (2) bolts from the wheel channel assemblies. Note: The bolts are hand tightened to the wheel channels. b. Set the Cart Base (1A) on the floor and then lay the Wheel Channel left (1B) on the left side and the Wheel Channel Right (1C) on the right side of the cart base. - Page 8 Grill Assembly STEP TWO a. Place the Cart Side Left (2A) onto the two (2) wheel channel assembly bolts, make sure the large flange is toward the front of the cart base b. Secure the cart side left in place by hand tightening the wheel channel assembly nuts onto the wheel channel assembly bolts.
- Page 9 Grill Assembly STEP THREE a. Remove parts from inside grill hood and remove the power transformer package from the grill back, then tilt the Grill Head Assembly (3A) onto it's back. WARNING: Keep hands and fingers away from grill hood when moving Grill Head Assembly.
- Page 10 Grill Assembly STEP FOUR a. Secure the Power Transformer (4A) wire on the cart back with two pre-installed wire clips. b. Use four (4) self-tapping screws to secure the transformer on the cart base. Note: Slide the outlet plug out from the bottom hole on the cart back.
- Page 11 Grill Assembly STEP FIVE a. Place Cart Door Right (5A) on an angle over the right side door pivot. b. Tilt the top of the door toward the grill, while depressing the top door pivot pin above the door edge. c.
- Page 12 Grill Assembly STEP SIX a. Lay the Side Shelf Left Assembly (6A) on its side. Use one (1) supplied phillips pan head screw to attach one of the Handle Ends (6B) to the front of the shelf. Note: Be careful not to scratch the side of the shelf. b.
- Page 13 Grill Assembly STEP SEVEN a. On the inside bottom of the side burner assembly you will find the brass burner cap attached with tape. Remove and set aside. b. Feed the side burner gas supply hose assembly through the large square hole in the side of the cart. c.
- Page 14 Grill Assembly STEP EIGHT a. Remove two screws from the side burner valve assembly. b. Carefully insert the valve assembly into the cast side burner. You will need to angle the tube into the burner assembly. Make certain that the hose is pointing down when the valve is put in place.
- Page 15 Grill Assembly STEP NINE a. Place the Drip Pan (9A) on the drip pan guides underneath the grill head. b. Insert the Flavor Grids (9B) into the cut outs with triangle ridges facing up. Make sure the flavor grid with the long side is installed next to the bottom IR burner.
-
Page 16: Gas Requirements
Gas Requirements GENERAL INFORMATION ▲ Never attach an unregulated gas line to the appliance. Connection to WARNING an unregulated gas line can cause excessive heat or fire. Verify the type of gas supply to be used, either Natural Gas (N.G.) or Liquid Propane (L.P.), and make sure the serial plate agrees with that of the supply. -
Page 17: Gas Installation
Gas Requirements L.P. GAS INSTALLATION Four Seasons™ Gas Grills that are set to operate with L.P. gas come with a high capacity hose and regulator assembly. (Note: Only use the pressure regulator and hose assembly supplied with the grill or a replacement pressure regulator and hose assemblies specified by Four Seasons™). -
Page 18: Pre Operation Leak Testing
Pre Operation Leak Testing GENERAL INFORMATION Although all gas connections on the grill are leak tested prior to shipment, a complete gas tightness check must be performed at the installation site due to possible shifting during shipment, installation or excessive pressure unknowingly being applied to the unit. Periodically check the whole system for leaks and immediately check the system if the smell of gas is detected. -
Page 19: Lighting The Grill
Lighting the Grill Do not attempt to "Light" the grill if the odor of gas present!! BEFORE LIGHTING Fig. 20 Important! Before Lighting: ▲ WARNING • Check the gas supply line for cuts, wear or abrasion. • Always keep your face and body as far away from the grill as possible when lighting. - Page 20 Using the Grill and Side Burner GRILL LOCATION Do not use the grill in garages, breezeways, sheds or any enclosed area. Never operate the grill ▲ WARNING in enclosed areas as this could lead to a carbon monoxide buildup, which could result in injury or death.
-
Page 21: Using The Rotisserie Burner
Using the Rotisserie Burner The grill rotisserie system is designed to cook items from the back using infrared heat. The rotisserie burner is an infrared type which provides intense searing radiant heat. Preferred by chefs over other cooking methods, this intense heat sears in the natural juices and nutrients found in quality cuts of meats. -
Page 22: Rotisserie Lighting
Rotisserie Lighting ROTISSERIE LIGHTING Fig. 28 Open the lid. Push and turn the control knob for the rotisserie counter-clockwise to the “HIGH” position. Continue push the knob and wait 5 seconds. You’ll hear a snapping sound. If the burner does not light in 4 seconds, turn the control knob to "OFF"... -
Page 23: Grill Light Maintenance
Grill Light Maintenance The light bulb in your grill will need to be replaced ocassionally. Only use the light bulb supplied with the grill or a replacement lamp specified by Four Seasons™. Light bulb replacing instructions: 1, Disconnect the light wires from the transformer wires under the grill head assembly. -
Page 24: Bottom Infrared Cooking Tips
Bottom Infrared Cooking Tips Even with an expert chef, infrared cooking can be quite a challenge. If you follow these simple suggestions, you will soon be making juicier, more savory foods than you have ever experienced before. In general, foods will cook in less time then they would take an ordinary grill. If you rotate food regularly (about every 2 minutes), extreme charring is avoided. -
Page 25: General Maintenance
Care and Maintenance PROTECTION OF INFRARED BURNERS The burners of your grill are designed to provide a long life of satisfactory performance. However, there are steps you must take to prevent cracking of the burner's ceramic surfaces, which will cause the burners to malfunction. -
Page 26: Cooking Grates
Care and Maintenance DRIP TRAY The drip tray should be cleaned periodically to prevent heavy buildup of debris. NOTE: Allow the drip tray to cool before attempting to clean. Important: Do not leave the grill outside during inclement weather unless it is covered. Rain water can collect inside of the grill, the grill cart or the drip tray if left uncovered. -
Page 27: Troubleshooting Your Grill
Troubleshooting Your Grill GENERAL TROUBLE SHOOTING You should inspect the burners at least once a year or immediately if any of the following conditions occur: • The smell of gas. • Flames appearing mostly yellow. (some yellow at the tips is OK) •... - Page 28 Troubleshooting Your Grill Problem SOLUTION Grill will not light with a match or low heat with dial • Is your gas supply fully turned on? set to "High" position. • Is there gas in your L.P. tank? Check your gas level. •...
-
Page 29: Replacement Part List
Replacement Part List Hood Assembly Spit Rod & Forks FCBJ3308001 FCTG3307005 1 set 1 set Hood Handle Assy. Main Cooking Grates FCTG3307014 FCTG3307004 1 set 1 set Temp. Gauge Flavor Grids FCCS0007030 FCCS0007004 1 pcs 1 set Bread Warming Rack Main Burner Tube FCBJ3308003 FCBJ3308007... - Page 30 Replacement Part List Large Bezel Side Burner Grate FCCS0007033 FCTG2707026 1 pcs 1 pcs Large Knob Side Burner Right Assy. FCBJ3308002 FCBJ3308013 1 pcs 1 set Small Knob Side Burner Valve FCBJ3308006 FCBJ3308037 1 pcs 1 pcs Small Bezel Towel Bar FCTG3007026 FCTG3007020 1 pcs...
- Page 31 Back IR Igniter Wire FCCS0007044 Flex Line For Bottom IR FCBJ3308022 FCBJ3308032 Flex Line For Back IR 1 pcs FCCS0007036 Regulator w/ Hose FCCS0007038 Cart Door Magnet Catch FCBJ3308035 "Four Seasons" Logo Tank Barrier Bar FCBJ3308023 1 pcs Lamp Switch FCBJ3308024 1 pcs...
-
Page 32: Limited Warranty
LIMITED WARRANTY Sure Heat Mfg warrants that for 2 years from the date of purchase, the stainless steel panels will not break due to defects in material or workmanship. All other components of this grill are warranted free from defects in material and workmanship for one year from the date of purchase.
