TOWEL HEATERS
MANUAL
EN 60335-2-43:2002+A1:2005+A2:2008 (2021)
Copyright ©2021 Bygghemma Sverige AB. Original
content rights reserved. All product names, logos,
and brands are property of their respective owners.
Information contained within this document was
considered accurate at the time of publication, but
may be subject to revision.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FAS 012 C1V PSPS SS and is the answer not in the manual?

Questions and answers

Summary of Contents for Bathlife FAS 012 C1V PSPS SS

  • Page 1 TOWEL HEATERS MANUAL EN 60335-2-43:2002+A1:2005+A2:2008 (2021) Copyright ©2021 Bygghemma Sverige AB. Original Information contained within this document was content rights reserved. All product names, logos, considered accurate at the time of publication, but and brands are property of their respective owners. may be subject to revision.
  • Page 2 TABLE OF CONTENTS INNEHÅLLSFÖRTECKNING INNHOLDSFORTEGNELSE INDHOLDFORTEGNELSE SISÄLLYSLUETTELO Important Information/viktig information/viktig informasjon/vigtig informa- tion/tärkeää tietoa Tools/verktyg/verktøy/værktøjer/työkalut Specifications/specifikationer/spesifikasjoner/specifikationer/tekniset tiedot Tightening/åtdragning/stramning/kiristäminen Assembly/montering/montage/kokoonpano Instructions for use/användningsinstruktioner/instruksjoner for bruk/brugsan- visning/käyttöohjeet Maintenance/skötsel/vedlikehold/vedligeholdelse/hoito Copyright ©2021 Bygghemma Sverige AB. Original Information contained within this document was content rights reserved. All product names, logos, considered accurate at the time of publication, but and brands are property of their respective owners.
  • Page 3 If you have questions, please contact us. Om du har frågor, vänligen kontakta oss. Hvis du har spørsmål, om produktet eller manualen. Hvis du har spørgsmål, til dette produkt eller manual. Jos sinulla on kysyttävää, ota yhteyttä. For installation, hire a licensed and/or authorised professional. För installation, anlita licensierad och/eller auktoriserad fackman.
  • Page 4 Spirit-level Measure tape Drill Vattenpass Måttband Borr Penna Vaterpass Måletape Penn Vaterpas Målebånd Bore Vatupassi Iskuporakone Porakone Kynä Spanner Allen key Screw driver Wall drill bit Skiftnyckel Insexnyckel Skruvmejsel Väggborrbit Skiftenøkkel Unbrakonøkkel Skrutrekker Veggbor Skruenøgle Unbrakonøgle Skruetrækker Vægbor Ruuviavain Kuusiokolo Ruuvimeisseli Seinän pora Glue gun...
  • Page 5 MODEL SIZE (MM) POWER SUPPLY FAS 012 C1V PSPS SS 1600x100x102 234-240 Volts ac, 50Hz, 30 Watts FAS 012 C1V IBIB SS 1600x100x102 234-240 Volts ac, 50Hz, 30 Watts FAS 012 C1V PGPG SS 1600x100x102 234-240 Volts ac, 50Hz, 30 Watts...
  • Page 6 MODEL SIZE (MM) POWER SUPPLY RAM 040 R4V PSPS SS 550x400x100 234-240 Volts ac, 50Hz, 35 Watts RAM 060 R6V PSPS SS 900x600x100 234-240 Volts ac, 50Hz, 60 Watts Copyright ©2021 Bygghemma Sverige AB. Original Information contained within this document was content rights reserved.
  • Page 7 LÄGE MODEL SIZE (MM) POWER SUPPLY LGE 050 A7V PSPS SS 500x100x1200 234-240 Volts ac, 50Hz, 60 Watts LGE 050 A7V IBIB SS 500x100x1200 234-240 Volts ac, 50Hz, 60 Watts LGE 050 A7V PGPG SS 500x100x1200 234-240 Volts ac, 50Hz, 60 Watts Copyright ©2021 Bygghemma Sverige AB.
  • Page 8 LIST MODEL SIZE (MM) POWER SUPPLY LST 011 R2V PSPS SS 108x100x1200 234-240 Volts ac, 50Hz, 30 Watts LST 011 R2E IBIB SS 108x100x1200 234-240 Volts ac, 50Hz, 30 Watts LST 026 R4V PSPS SS 260x100x1200 234-240 Volts ac, 50Hz, 35 Watts LST 026 R4V IBIB SS 260x100x1200 234-240 Volts ac,...
  • Page 9 Drill Seal Plug Screw Borra Täta Plugg Skruva Bore Tetning Støpsel Skru Bore Forsegle Prop Skrue Porata Tiiviste Pistoke Ruuvi Concrete or other massive material Betong eller annan massiv konstruktion Betong eller annet massivt materiale Beton eller andet massivt materiale Betoni tai muu massiivinen materiaali 6 mm Wood beams, nogging pieces, or other base tested...
  • Page 10 Copyright ©2021 Bygghemma Sverige AB. Original Information contained within this document was content rights reserved. All product names, logos, considered accurate at the time of publication, but and brands are property of their respective owners. may be subject to revision.
  • Page 11 Copyright ©2021 Bygghemma Sverige AB. Original Information contained within this document was content rights reserved. All product names, logos, considered accurate at the time of publication, but and brands are property of their respective owners. may be subject to revision.
  • Page 12 See page 9 Se sidan 9 Se side 9 Se side 9 Katso sivu 9 Copyright ©2021 Bygghemma Sverige AB. Original Information contained within this document was content rights reserved. All product names, logos, considered accurate at the time of publication, but and brands are property of their respective owners.
  • Page 13 Copyright ©2021 Bygghemma Sverige AB. Original Information contained within this document was content rights reserved. All product names, logos, considered accurate at the time of publication, but and brands are property of their respective owners. may be subject to revision.
  • Page 14 CONCEALED WIRE INSTALLATION INSTALLATION AV CONCEALED WIRE INSTALLASJON AV TEKNISK WIRE INSTALLATION AF TILKOBLET WIRE KYTKETYN JOHDON ASENNUS L PE N L PE N Copyright ©2021 Bygghemma Sverige AB. Original Information contained within this document was content rights reserved. All product names, logos, considered accurate at the time of publication, but and brands are property of their respective owners.
  • Page 15 EXPOSED WIRE INSTALLATION INSTALLATION AV EXPONERAD WIRE INSTALLASJON AV EKSPONERT WIRE INSTALLATION AF EKSPONERET WIRE ALTISTUVAN JOHDON ASENNUS L PE N L PE N Copyright ©2021 Bygghemma Sverige AB. Original Information contained within this document was content rights reserved. All product names, logos, considered accurate at the time of publication, but and brands are property of their respective owners.
  • Page 16 Copyright ©2021 Bygghemma Sverige AB. Original Information contained within this document was content rights reserved. All product names, logos, considered accurate at the time of publication, but and brands are property of their respective owners. may be subject to revision.
  • Page 17 Copyright ©2021 Bygghemma Sverige AB. Original Information contained within this document was content rights reserved. All product names, logos, considered accurate at the time of publication, but and brands are property of their respective owners. may be subject to revision.
  • Page 18 To avoid hazard with children, install bottom rail 600 mm from floor. And install no closer than 100 mm from wall corners or objects. Perform the same steps for other specifications product. För att undvika fara med barn, installera bottenskenan 600 mm från golvet. Och installera inte närmare än 100 mm från vägghörn eller föremål.
  • Page 19 To avoid hazard with children, install bottom rail 600 mm from floor. And install no closer than 100 mm from wall corners or objects. Perform the same steps for other specifications product. För att undvika fara med barn, installera bottenskenan 600 mm från golvet. Och installera inte närmare än 100 mm från vägghörn eller föremål.
  • Page 20 Timer knob with diamond pattern for setting the operation mode Timerratt med diamantmönster för inställning av driftläge Timerknapp med rutemønster for innstilling av driftsmodus Timerknap med diamantmønster til indstilling af driftstilstand Ajastinnuppi timanttikuviolla käyttötilan asettamiseen 12 H 6 LED lights for working time, display from bottom to top 10 H 6 LED-lampor för arbetstid, display från botten till toppen 6 lysdioder for arbeidstid, display fra bunn til topp...
  • Page 21 CONTINUOUS OPERATION MODE KONTINUERLIG DRIFTLÄGE KONTINUERLIG DRIFTSMODUS KONTINUERLIG DRIFTSMODUS JATKUVA KÄYTTÖTILA Press again to enter continuous operation mode. 6 lights will turn on and off from bottom to top (2-12 H) and repeat, there is always only one light on. Then the product starts to work.
  • Page 22 SINGLE TIMING MODE ENKEL TIDSLÄGE ENKEL TID MODUS NEM TID TILSTAND HELPPOAIKATILA 12-2-12 H 12-2-12 H In the standby state, rotate the knob clockwise or counterclockwise, and the setting time is sequentially from 2 hours to 12 hours. Clockwise and counterclockwise rotation can be set cyclically, the corresponding light to the time will turn on.
  • Page 23 For example, after setting for 6 hours, 6H, 4H, 2H three lights will turn on, and as the countdown, 6H, 4H, 2H lights will turn off in turn. After setting the time, press the knob, all the corresponding lights will flash once, and the device will start to work and enter the timing countdown mode. Till exempel, efter inställning i 6 timmar, kommer 6H, 4H, 2H tre lampor att tändas, och när nedräkningen släcks i tur och ordning 6H, 4H, 2H lamporna.
  • Page 24 CYCLE TIMING MODE CYKELTIDSLÄGE SYKKELTID MODUS CYKLINGSTID PYÖRÄYSAIKATILA 12-2-12 H 12-2-12 H In the standby state, rotate the knob clockwise or counterclockwise, and the setting time is sequentially from 2 hours to 12 hours. Clockwise and counterclockwise rotation can be set cyclically, the corresponding light to the time will turn on. I standbyläge, vrid ratten medurs eller moturs, och inställningstiden är sekventiellt från 2 timmar till 12 timmar.
  • Page 25 After setting the time, press the knob for 3 seconds, all the corresponding lights will flash twice, and the device will start to work and enter the cycle timing countdown mode. Efter att ha ställt in tiden, tryck på knappen i 3 sekunder, alla motsvarande lampor blinkar två gånger och enheten börjar arbeta och går in i nedräkningsläget för cykeltid.
  • Page 26 When the countdown is operating during the cycle timing mode, press the knob once will stop working and the device will enter the cycle standby state, the corresponding lights will keep flashing. Press the knob again to cancel the cycle timing function and all the lights will turn off. När nedräkningen är igång under cykeltimingsläget, tryck en gång på...
  • Page 27 If any part is broken, please contact us for service and repair it. Om någon del är defekt, kontakta oss för service och reparera den. Hvis noen del er ødelagt, kontakt oss for service og reparasjon. Hvis nogen del er brudt, Kontakt os for service og reparation. Jos jokin osa on rikki, ota yhteyttä...
  • Page 28 Copyright ©2021 Bygghemma Sverige AB. Original Information contained within this document was content rights reserved. All product names, logos, considered accurate at the time of publication, but and brands are property of their respective owners. may be subject to revision.
