- Page 1 No.21SS-0001-02 CoaXPress Camera Monochrome / Color CMOS 65Mpixel BC-GM65M6X4 (65M, Monochrome) BC-GC65M6X4 (65M, Color) Product Specifications BOPIXEL Corporation Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 1/21...
-
Page 2: Safety Precautions
Keep the camera and wiring cables away from noise sources. Due to the inherent characteristics of CMOS sensors, pixel defects may occur during transportation and storage. Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 2/21... -
Page 3: Table Of Contents
Trigger Source ..........................16 5.1.1 Software ..............................16 5.1.2 Line0-Line2 ..............................16 5.1.3 LinkTrigger ..............................16 Trigger Acquisition Mode ......................17 Exposure Mode .......................... 18 6 FRAME RATE CALCURATION ..................20 7 REVISION INFORMATION ..................21 Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 3/21... -
Page 4: Specifications
(*2) The effective range of pixel defect correction is as follows. Monochrome : Same as active pixel. Color : 9284(H) x 6940(V) (30(H) x 30(V) from four corners of the active pixel is out of the pixel defect correction guarantee range) Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 4/21... -
Page 5: Mechanical Specifications
Standard Compliancy EMS: EN55035:2017+A11:2020 LVD: EN62368-1:2014+A11:2017 RoHS RoHS Compliant (*1) Use in an installation environment where the [Device Temperature] (CMOS temperature sensor inside the camera) read by communication is 60℃ or less. Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 5/21... -
Page 6: Cmos Informaiton
No.21SS-0001-02 CMOS Informaiton Relative response Color Filter Array BC-GC65M6X4 (Color) (0,0) Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 6/21... -
Page 7: Camera Hardware Information
Open or External Pull Up (3.0 to 26.4V) ≦1.0V Open or External Pull Up (3.0 to 26.4V) ≦1.0V Opto IN+ (Opto IN+) – (Opto IN-) 3.0 to 26.4V ≦1.0V Opto IN- Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 7/21... -
Page 8: Gpio Line Circuit
No.21SS-0001-02 GPIO Line Circuit Opto IN Circuit ON/OFF delay > 3us Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 8/21... -
Page 9: Camera Dimensions
No.21SS-0001-02 Camera Dimensions 【F MOUNT STRAIGHT TYPE】 Unit : mm Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 9/21... - Page 10 No.21SS-0001-02 【M42 MOUNT STRAIGHT TYPE】 Unit : mm Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 10/21...
- Page 11 No.21SS-0001-02 【F MOUNT ANGLE TYPE】 Unit : mm Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 11/21...
- Page 12 No.21SS-0001-02 【M42 MOUNT ANGLE TYPE】 Unit : mm Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 12/21...
-
Page 13: Camera Operation
The setting items of the camera conform to SNFC of GenICam Standard Version. The items implemented in the camera are as follows. Please refer to SNFC of GenICam for details of the function except the original functions of BOPIXEL. 4.1.1... - Page 14 2) Formula2: OutValue = (InValue-BlackLevel)*BalanceRatio/2048+BlackLevel (Set 2048 for 0dBGain) (*3) If using with CXP3_X1, the black level in image unevenness becomes larger than other modes due to the CMOS characteristics.When using with CXP3_X1, please use the camera after pre-evaluation. Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 14/21...
-
Page 15: Original Functions Of Bopixel
Specifies the delay in microseconds (us) to apply LineDebounceTime after receiving IO[Line*] signal and before activating it. It is possible to provide an auxiliary tool for calculating Shading Gain and Center PosX/Yfrom the bitmap image. (*1) Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 15/21... -
Page 16: Image Acquisition And Camera Trigger Modes
When using the Line trigger, it is necessary to keep the voltage input range to the IO pin. 5.1.3 LinkTrigger A trigger is input from the Cable line of the grabber board. The trigger input method from LinkTrigger depends on the grabber board specifications. Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 16/21... -
Page 17: Trigger Acquisition Mode
Refer to [Horizontal Period depending on camera settings] 5.2.2 Horizontal Period depending on camera setting. CXP Link Horizontal Configuration Period(usec) CXP6X4 4.00 CXP3X4 / CXP6X2 8.00 CXP3X2 / CXP6X1 16.00 CXP3X1 32.00 Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 17/21... -
Page 18: Exposure Mode
The camera is exposed for the same period as the external trigger and outputs the video image. There is an upper limit to the timing at which a trigger can be input. Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 18/21... - Page 19 「Timed」 ：the trigger in this condition is ignored inside the camera and the next trigger is enabled. 「TriggerWidth」 ：Image output becomes abnormal, and in the worst case, it is necessary to turn off/on the power of the camera. Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 19/21...
-
Page 20: Frame Rate Calcuration
6 Frame Rate calcuration 1000000 / Horizontal Period / (Height + 42) [fps] (*1) Horizontal Period：Refer to 5.2.2 Horizontal Perioddepending on camera settings. (*1) Round down to the third decimal place. Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 20/21... -
Page 21: Revision Information
Add) EnableDigitalGainOffset 2022/2/9 1.3 Environmental Specifications Update) Standard Compliancy update 4.1.2 Original functions of BOPIXEL Delete）Shading Correction Mode Must Building 7F E3&W3, 17-1 Daimachi, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0834, Japan TEL.045-548-3566 FAX.045-548-3711 Copyright © 2021-2022 BOPIXEL Corporation All Rights Reserved. 21/21...
