Instruction Manual
Ugo Esteem Reclining Wheelchair
Adjustable removable
Head Rest
Attendant Push Handles
Attendant Brake
and Recline Levers
Hand Brake
Removable Arm Rest,
height adjustable with
slider
Stepper Tube and
Anti-tip Wheels
Lever to remove
elevated Foot Rest
Elevating Leg Rest
Hand Rim
Adjustable height
Foot Rest
Front Castor Wheel and Fork
Ugo Ltd, Unit 5 Vander House, Forde Close, Newton Abbot, Devon, TQ12 4FT
Telephone: 01803 872020 Fax: 01803 872121 Email:
info@ugo-on.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Esteem and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ugo Esteem

Summary of Contents for Ugo Esteem

  • Page 1 Lever to remove elevated Foot Rest Elevating Leg Rest Hand Rim Adjustable height Foot Rest Front Castor Wheel and Fork Ugo Ltd, Unit 5 Vander House, Forde Close, Newton Abbot, Devon, TQ12 4FT Telephone: 01803 872020 Fax: 01803 872121 Email: info@ugo-on.com...

  • Page 2: Table Of Contents

    7. Brake and Recline Operation 2. Introduction The Esteem reclining self-propelled wheelchair is designed for occasional or frequent use, and can be used indoors and outdoors. It can either be propelled by the user or pushed by a carer/attendant. The wheelchair is designed for a single user of up to 130kgs (20 stone), and is available in 2 widths;...
  • Page 3 1. Flip up/removable height and depth adjustable arm rests 2. Elevating leg rests 3. Double cross brace 4. Front castor wheel and fork assembly 5. Quick release rear wheel 24” 6. Stepper tube and anti-tippers 7. Push handles and atendant brake/recline levers (see below) 8.

  • Page 4: Arm Rest Adjustment

    4. Leg Rest Adjustment For optimum comfort it is important to attain the correct leg position. The leg rests have been designed so that they can be extended to suit the users’ leg length. Loosen the bolt on the side of the leg rest and adjust the leg rest as required, re-tighten the bolt and make sure they are secure.

  • Page 5: Brake And Recline Operation

    7. Brake and Recline Operation Brakes: To apply the parking brakes on the rear wheels, push the handle on the brake unit on each side until locked in place. To release the brake, pull the handle in the opposite direction. The brakes should always be applied when the wheelchair is stationary and also when the user is trying to ingress or egress the wheelchair or if the wheelchair is in the recline position.

  • Page 6: Using The Lap Belt

     Do not reverse down a gradient  Maintain proper balance at all times. Users should not move their centre of gravity out of the seating area.  Do not reach for items further than your arm will extend.  Be aware of hazards in your environment, such as narrow doorways, steps, household appliances, children’s toys etc.

  • Page 7: Care And Maintenance

    11. Care and maintenance  Before each use of the wheelchair the brakes and tyres should be checked.  The wheelchair should be stored in a dry environment and away from direct sunlight. When in storage the wheelchair can be folded up. ...

  • Page 8: Warranty

    13. Warranty Your Ugo branded product is warranted to be free of defects in materials and workmanship for one year from date of purchase. This device was built to exacting standards and carefully inspected prior to shipment. This warranty is an expression of our confidence in the materials and workmanship of our products and our assurance to the customer.
